Machine Modules
Issue 2: July 2007
Print Carriage
•
The Print Carriage module consists of
the following sub-assemblies:
– Print Carriage Motor (Node 7)
Issue 2: July 2007
– Print Carriage Motor (Node 7)
– Print carriage I/O Node 3
– Home Sensor
– Drive Belt
Print Carriage Tasks
•
Remove and refit print carriage belt
•
Remove and refit motor
Issue 2: July 2007
•
Remove and refit motor
•
Check print carriage home position
Objective 19: Complete activities in your workbook
