TS 566R SMART CONTROLLER FOR SPRAY VALVES User Guide Copyright © OK International
TS566R SMART CONTROLLER
FOR
SPRAY VALVES
User Guide
Copyright © OK International
2
CONTENTS
Page Number
1. Safety ………………………………………………………………… 3
2. Symbol Definitions ………………………………………………. 4
3. Specifications ……………………………………………….………. 5
4. Features ……………………………………………………………. 5
5. To Control Spray Valve………………………………….................…. 5
5.1 Connecting the unit…….……………………………………… 6
5.1.1 Login …………………………………………………… 6
5.1.2 Pressure Calibration.……………………………………. 7
5.1.3 Controlling mode ………………………………………. 8
5.2 Spraying ……………….……………………………............ 10
5.2.1 Pressure Adjustment …………………………………. 10
5.2.2 To Change Pressure Unit Display ………….………... 10
5.2.3 Spray Time Setting ……………………………………... 11
5.2.4 Manual/Purge Cycle ……………………………………. 12
5.2.5 Automatic Cycle ……………………………………… 12
5.2.6 Teach Mode Setting ……………………………………. 13
5.3 Stored Program in Memory Cell ……………………………. 14
5.3.1 To store dispense parameters …………………………… 14
5.3.2 To run in Continuous mode ……………………………. 14
5.3.3 To run in Single Sequence mode ………………………. 15
5.3.4 To run in Continuous Sequence mode ……………………17
5.3 Cycle Counter ………………………………………………... 17
5.4 To Change Password …………………………………………. 18
5.5 To Connect to Wi-Fi network ………………………………… 19
6. Internet of Thing (IoT) ………………………………………………... 21
7. Software Upgrade ……………………………………………………. 27
8. Troubleshooting ……………………………………………………. 29
9. Maintenance …………………………………………………………. 30
10. Warranty ……………………………………………………………... 30
11. I/O Configuration and End of Cycle Switch ………………………. 31
3
1. SAFETY
1.1 Intended Use:
WARNING: Use of this equipment in ways other than those described in this User
Guide may result in injury to persons or damage to property. Use this equipment
only as described in this User Guide.
OK International cannot be responsible for injuries or damages resulting from
unintended applications of its equipment. Unintended uses may result form taking
the following actions:
• Making changes to equipment that has not been recommended in the User
Guide
• Using incompatible or damaged replacement parts
• Using unapproved accessories or auxiliary equipment
1.2 Safety Precautions:
• Do not operate this unit in excess of maximum ratings/settings
• Always wear appropriate personal protective clothing or apparel
• The fluid may be toxic and/or hazardous. Refer to Material Safety Data Sheet
for proper handling and safety precautions
• Do not smoke or use open flame when flammable materials are being sprayed
• This equipment is for indoor use only
