YC8-KLM-000_MaintenancePartsList - 第12页

KLM-1207 Rev . :It had a change without the compatibility . Please be careful at the time of the parts ordering. Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。 No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Pa…

100%1 / 45
KLM-1207
1
2
13
30
10
23
7
18
32
9
28
33
34
8
24
25
29
15
14
6
27
20
8
5
11
31
22
16
12
19
12
21
35
4
26
6
6
3
17
* in case of "Built-in-Left"
* in case of "Built-in-Right"
3
1
Feeder Holder 14 Lanes
Feeder Holder Section
KLM-1207
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1 KLM-M3400-A0 FEEDER PLATE A14 1
"Built-in-Left"
/
Í
39
2 KLM-M3400-B0 FEEDER PLATE B14 1
"Built-in-Right"
/
Í
40
3 $TSS4-01 JOINT 1
41
4 $UKM4-01 JOINT 1
42
5 91312-03020 BOLT HEX,SOCKET HEAD 4
43
6 91312-04006 BOLT HEX,SOCKET HEAD 8
44
7 91312-04008 BOLT HEX,SOCKET HEAD 4
45
8 91312-04010 BOLT HEX,SOCKET HEAD 6
46
9 91312-05025 BOLT HEX,SOCKET HEAD 4
47
10 91312-06014 BOLT HEX,SOCKET HEAD 4
48
11 91312-06020 BOLT HEX,SOCKET HEAD 4
49
12 98702-03006 SCREW,FLAT HEAD 14
50
13 KHY-M3430-10 LABEL,FEEDER 60-12P 1
A0 : [1] <==> [14]
B0 : [15] <==> [28]
/
51
14 KHY-M372M-00 SCREW,STAD 28 /
Í
52
15 KHY-M66TE-00 HNS,F.CTRL - FDR. 14 /
Í
53
16 KKG-M371R-00 RAIL GUIDE 12P 1 8 Lanes /
54
17 KKG-M372R-00 GUIDE,FEEDER UNDER 2 /
55
18 KKT-M340C-00 PLATE,FRONT 1 /
Í
56
19 KKT-M340E-00 RAIL GUIDE 12P 1 6 Lanes /
57
20 KKT-M340G-00 SHAFT GUIDE 1 /
Í
58
21 KKT-M4476-00 FDR.CTRL.BOARD ASSY 1 B
Í
59
22 KLM-M3402-00 SLOPE,UNDER 2 /
Í
60
23 KLM-M3T0E-00 TAPE GUIDE 1 /
Í
61
24 98902-03004 SCREW BINDING HEAD 12
62
25 KLM-M3401-00 PLATE,FEEDER 12-14 1 /
Í
63
26 98902-03006 SCREW BINDING HEAD 4
64
27 99480-04012 PIN,PARALLEL 1 /
Í
65
28 KLM-M3404-00 STAND,FEEDER PLATE 2 /
Í
66
29 99480-06012 PIN,PARALLEL 2 /
Í
67
30 99480-06014 PIN,PARALLEL 1 /
Í
68
31 99480-06020 PIN,PARALLEL 4 /
Í
69
32 KLM-M3407-00 BASE,SIDE PLATE 2 /
Í
70
33 KLM-M340H-00 COVER 2 1 /
Í
71
34 KLM-M340J-00 PLATE,CONNECTOR 1 /
Í
72
35 KLM-M340K-00 COVER 1 1 /
Í
73
36
74
37
75
38
76
3
1
Feeder Holder 14 Lanes
Feeder Holder Section
KLM-1207
28
23
7
14
13
22
27
13
12
13
3
30
7
24
1
14
14
31
29
25
13
4
21
40
6
26
16
39
33
34
20
10
38
18
37
10
19
35
7
10
36
32
42
8
2
5
41
9
15
11
17
7
4
1
X-axis Neighbor
Moving-axis Section
