YC8-KLM-000_MaintenancePartsList - 第40页

KLM-1207 Rev . :It had a change without the compatibility . Please be careful at the time of the parts ordering. Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。 No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Pa…

100%1 / 45
KLM-1207
17
1
5
19
21
6
12,13,14
6
16
21
19
5
1
3,4
22
10
23
11
20
18
8
9
15
7
2
8
1
Control Box
Controller Section
KLM-1207
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1
91312-04006 BOLT HEX,SOCKET HEAD 4 39
2
97602-04308 SCREW PAN HEAD W/W 2 40
3
KHL-M4209-01 SYSTEM UNIT ASSY 1
Normal
B
r
41
4
KHL-M4209-21 SYSTEM UNIT ASSY. 1
"IT Option" applicable
B
r
42
5
KJJ-M411A-00 PLATE 2 /
43
6
KJJ-M411B-00 BRACKET 2 2 /
44
7
KJJ-M4120-00 BRACKET 2 FILTER 1 /
45
8
KJJ-M4140-10 DUMMY PANEL SERVO 1
"Main unit only" case
/
46
9
KHN-M5840-A2 SERVO BOARD ASSY 1
"ATS15 installed" case
B
r
47
10
KHN-M5803-C1 SERVO UNIT ASSY 1
B
r
48
11
KJJ-M5880-00 D.POWER BOARD ASSY 1
B
r
49
12
KHL-M441H-33 VISION BOARD ASSY 1
for F & R Multi-cameras,
"Main unit only" case
B
r
50
13
KHL-M441H-13 VISION BOARD ASSY 1
for Front Multi-camera
only
B
r
51
14
KHL-M441H-03 VISION BOARD ASSY 1
for F & R Multi-cameras,
"ATS15 installed" case
B
r
52
15
KJJ-M4119-00 BRACKET 1 FILTER 1 /
53
16
KHN-M4530-56 REMOTE IF BOARD ASSY 1
B
r
54
17
KHL-M4255-00 FLASH DISK 1
B
r
55
18
KJJ-M53A9-10 FILTER 1 /
56
19
KJJ-M53A9-20 FILTER 2 /
57
20
KJJ-M53E9-10 TAPE 1 /
58
21
KJJ-M53E9-20 TAPE 2 /
59
22
90166-12JA10 SCREW PAN HEAD 6 60
23
97602-04308 SCREW PAN HEAD W/W 6 61
24
62
25
63
26
64
27
65
28
66
29
67
30
68
31
69
32
70
33
71
34
72
35
73
36
74
37
75
38
76
8
1
Control Box
Controller Section
KLM-1207
8
6,11
16
12
10
6,11
39
13
14
9
4
3
15
19 - 30
5
31 - 38
17,18
40
1,2
7
9
1
Exterior / Etc.
Exterior-Etc Section
