24.1.ｶﾑﾎﾞｯｸｽ(DCPA)
24.1.Cam box(DCPA)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 DCPA1121 1 PULLEY ﾌﾟｰﾘ OT
2 DCPA0221 1 PULLEY ﾌﾟｰﾘ OT
3 DCPA0201 1 PULLEY ﾌﾟｰﾘ OT
4 DCPA0211 2 PULLEY ﾌﾟｰﾘ OT
5 DCPA0190 1 PULLEY ﾌﾟｰﾘ FE
6 DCPA0290 4 RING, LOCKING ﾘﾝｸﾞ 締結 OT
7 DGPA0011 1 INDEX ｲﾝﾃﾞｯｸｽ OT
8 DGPA0021 1 INDEX ｲﾝﾃﾞｯｸｽ OT
9 H30762 1 RING, LOCKING ﾘﾝｸﾞ 締結 ETP-K-17 OT
10 DCPA0230 1 PULLEY ﾌﾟｰﾘ AL
11 DCPA0240 1 PULLEY ﾌﾟｰﾘ AL
12 DCPA1260 1 PULLEY ﾌﾟｰﾘ FE
13 H4578A 1 BELT, TIMING ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ 580-5GT-15 OT
14 H4579A 1 BELT, TIMING ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ 710-5GT-55 OT
15 H4577A 1 BELT, TIMING ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ 360-5GT-25 OT
16 H4580A 1 BELT, TIMING ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ 960-5GT-40 OT
17 DCPA1080 1 SCALE ﾒﾓﾘ AL
18 K5203A SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M4X6L FE
19 DCPA0421 1 HOLDER, BEARING ﾎﾙﾀﾞ ﾍﾞｱﾘﾝｸﾞ FE
20 DCPA1100 1 NAMEPLATE, ARROW 銘板 矢印 FE
21 DCPA1110 1 NAMEPLATE, ARROW 銘板 矢印 FE
22 K5209A SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M4X8L FE
23 DCPA0480 2 COLLAR ｶﾗｰ FE
24 DCPA1070 1 DOG ﾄﾞｯｸﾞ FE
25 DCPA1620 1 COLLAR ｶﾗｰ FE
26 DCPA1600 1 COLLAR ｶﾗｰ FE
27 DCPA1590 1 COLLAR ｶﾗｰ FE
28 ADCPA8051 1 SHAFT, CAM ｼｬﾌﾄ ｶﾑ OT
29 DCPA0370 3 BOLT ﾎﾞﾙﾄ FE
30 DCPA1490 2 KEY ｷｰ FE
31 DCPA1551 1 HOUSING ﾊｳｼﾞﾝｸﾞ FE
32 DCPA1561 1 COVER ｶﾊﾞｰ FE
33 DCPA0070 4 PIN, LOCATING ﾋﾟﾝ 位置決め FE
34 ADCPA8012 1 SHAFT, CAM ｼｬﾌﾄ ｶﾑ OT
36 DCPA1170 1 RING ﾘﾝｸﾞ AL
37 DCPA1060 2 DOG ﾄﾞｯｸﾞ FE
38 DCPA1430 1 BKT BKT FE
39 DCPA1480 2 COVER 蓋 FE
40 DCPA1470 1 GEAR ｷﾞﾔ OT
41 DCPA1281 1 BKT BKT FE
48 DCPA0460 2 BOLT, POSITIONING ﾎﾞﾙﾄ 位置決め FE
49 DCPA0270 1 KEY ｷｰ FE
50 DCPA1540 1 SHAFT ｼｬﾌﾄ FE
51 DCPA1570 1 GEAR ｷﾞﾔ OT
52 DCPA1580 2 GEAR, PINION ｷﾞﾔ ﾋﾟﾆｵﾝ OT
CP-743ME,CP-742ME PARTS LIST
24 - 3
24.1.ｶﾑﾎﾞｯｸｽ(DCPA)
24.1.Cam box(DCPA)
24.1.ｶﾑﾎﾞｯｸｽ(DCPA)
24.1.Cam box(DCPA)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
53 DCPA0490 1 GEAR, BEVEL ｷﾞﾔﾍﾞﾍﾞﾙ OT
56 DCPA0500 1 KEY ｷｰ FE
57 DCPA0260 1 SCREW, ADJUSTING ﾈｼﾞ 調整 FE
60 DCPA0280 1 BKT, ADJUSTING BKT 調整 FE
61 DCPA0520 1 COLLAR ｶﾗｰ FE
62 DCPA0451 1 COVER 蓋 FE
64 DCPA1410 1 SHAFT ｼｬﾌﾄ FE
65 DCPA1440 1 HOUSING ﾊｳｼﾞﾝｸﾞ FE
66 DCPA1500 2 NUT ﾅｯﾄ FE
67 DCPA1520 2 COLLAR ｶﾗｰ CO
68 DCPA1530 2 SPRING ｽﾌﾟﾘﾝｸﾞ FE
69 DCPA1610 1 SPRING ｽﾌﾟﾘﾝｸﾞ FE
70 DCPA1420 1 SHAFT ｼｬﾌﾄ FE
71 DCPA1450 1 HOUSING ﾊｳｼﾞﾝｸﾞ FE
72 DCPA1510 4 BLOCK 駒 CO
73 DCPA1460 2 COVER ｶﾊﾞｰ OT
77 DCPA0300 1 PLATE ﾌﾟﾚｰﾄ FE
78 DCPA0320 1 BKT BKT FE
79 DCPA0330 2 BKT BKT FE
80 DCPA0390 1 SHAFT ｼｬﾌﾄ FE
81 DCPA1270 1 SHAFT ｼｬﾌﾄ FE
82 DCPA0340 1 BKT BKT FE
83 DCPA0380 3 COLLAR ｶﾗｰ FE
84 DCPA1290 1 BKT BKT FE
85 DCPA1150 1 HOLDER ﾎﾙﾀﾞ AL
92 DCPA0082 1 BKT, MOTOR BKT ﾓｰﾀ FE
93 DCPA0840 1 BKT BKT FE
100 DCPA1140 1 BKT BKT FE
111 DCPA0890 1 PLATE ﾌﾟﾚｰﾄ FE
112 DCPA0861 2 PIN, LOCATING ﾋﾟﾝ 位置決め FE
114 DCPA1640 1 PLATE ﾌﾟﾚｰﾄ FE
115 DGPA0060 1 SHAFT, CAM ｼｬﾌﾄ ｶﾑ FE
116 DCPA1200 1 SHAFT, CAM ｼｬﾌﾄ ｶﾑ FE
117 DCPA1310 1 BKT BKT 注1.Note.1 FE
118 DCPA1320 1 BKT BKT 注1.Note.1 FE
119 DCPA0430 2 HOLDER, BEARING ﾎﾙﾀﾞ ﾍﾞｱﾘﾝｸﾞ 注1.Note.1 FE
120 DCPA0440 1 HOUSING ﾊｳｼﾞﾝｸﾞ 注1.Note.1 FE
140 DCPA1031 1 BKT BKT FE
141 DCPA0400 1 SHAFT ｼｬﾌﾄ FE
142 DCPA0880 2 PIN, LOCATING ﾋﾟﾝ 位置決め FE
143 DCPA0870 2 PIN, LOCATING ﾋﾟﾝ 位置決め FE
146 S1012A 1
ｻｰｸﾘｯﾌﾟ RTW52 FE
147 H4189Y 2
ﾍﾞｱﾘﾝｸﾞ 6205ZZ FE
148 H4181A 6
ﾍﾞｱﾘﾝｸﾞ 6003ZZ FE
149 S1036A 3
ｻｰｸﾘｯﾌﾟ STW17 FE
CP-743ME,CP-742ME PARTS LIST
24 - 4
24.1.ｶﾑﾎﾞｯｸｽ(DCPA)
24.1.Cam box(DCPA)
24.1.ｶﾑﾎﾞｯｸｽ(DCPA)
24.1.Cam box(DCPA)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
153 H4232X 4 BEARING ﾍﾞｱﾘﾝｸﾞ HR32006XJP5 FE
154 S1039A 1
ｻｰｸﾘｯﾌﾟ STW25 FE
156 S40443 4 SENSOR, PHOTO ｾﾝｻ ﾌｫﾄ EE-SX770A OT
157 N1021Z 2 NUT, LOCK ﾅｯﾄ ﾛｯｸ MR30 FE
158 H4420T 1 BEARING, NEEDLE ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ GK35X40X26.8XS FE
159 H4356A 3
ﾍﾞｱﾘﾝｸﾞ ﾄﾞﾗｲ MB2525DU FE
160 H4349A 1
ﾍﾞｱﾘﾝｸﾞ ﾄﾞﾗｲ MB2015DU FE
161 H4346A 2
ﾍﾞｱﾘﾝｸﾞ ﾄﾞﾗｲ MB1815DU FE
162 N1019H 2
ﾅｯﾄ ﾌｧｲﾝU AN04 FE
164 S31207 2 SW, PHOTOELECTRIC SW 光電 EE-SX771A OT
165 K1001T 1 COUPLING ｶｯﾌﾟﾘﾝｸﾞ LAD-20C-4X6 OT
174 W1012A
ﾜｯｼｬ 皿         
M-5-L FE
182 H4193T 4 BEARING ﾍﾞｱﾘﾝｸﾞ 6305ZZ FE
183 DCPA0470 4 SEAL ｼｰﾙ FE
187 WPA1300 3 KEY ｷｰ FE
188 WPA0351 1 WASHER ﾜｯｼｬ FE
189 WPA1642 1 SPRING, PLATE ｽﾌﾟﾘﾝｸﾞ 板 FE
190 WPA1650 1 SCREW ﾈｼﾞ FE
191 WPA1681 1 BKT BKT FE
192 WPA1732 1 GUIDE ｶﾞｲﾄﾞ FE
194 WPA1771 2 SPRING, PLATE ｽﾌﾟﾘﾝｸﾞ 板 FE
195 WPA1750 1 PLATE ﾌﾟﾚｰﾄ FE
196 WPA1740 1 PLATE ﾌﾟﾚｰﾄ FE
198 S31970 1
SW ﾘﾐｯﾄ XCS-A501 OT
199 S31971 1
SW ﾘﾐｯﾄ XCS-Z01 OT
202 DCPA1090 1 SCALE ﾒﾓﾘ OT
205 DCPA0172 1 COUPLING ｶｯﾌﾟﾘﾝｸﾞ OT
209 H52680 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M02.5X015L FE
210 W1020H
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 2.5M/M FE
219 DCPA0850 1 BKT BKT FE
220 DCPA1250 1 GUIDE, RAIL ｶﾞｲﾄﾞ ﾚｰﾙ OT
221 DCPA1650 1 BKT BKT FE
222 DCPA1660 1 HANDLE ﾊﾝﾄﾞﾙ OT
223 DCPA1670 1 BKT BKT FE
224 SAM6452 1 MOTOR, AC SERVO ﾓｰﾀ ACｻｰﾎﾞ OT
225 SAM6503 1 MOTOR, AC SERVO ﾓｰﾀ ACｻｰﾎﾞ OT
227 H5274A
ﾎﾞﾙﾄ 六角穴        
M3X6L FE
228 H5275A
ﾎﾞﾙﾄ 六角穴        
M3X8L FE
229 H5276A
ﾎﾞﾙﾄ 六角穴        
M3X10L FE
232 H5287A
ﾎﾞﾙﾄ 六角穴        
M4X8L FE
233 H5288A
ﾎﾞﾙﾄ 六角穴        
M4X10L FE
234 H5289A
ﾎﾞﾙﾄ 六角穴        
M4X12L FE
235 H5290A
ﾎﾞﾙﾄ 六角穴        
M4X15L FE
237 H5299A
ﾎﾞﾙﾄ 六角穴        
M5X12L FE
238 H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L FE
CP-743ME,CP-742ME PARTS LIST
24 - 5
