24.1.ｶﾑﾎﾞｯｸｽ(DCPA) 24.1.Cam box(DCPA) 番号図番 & ｺｰﾄﾞ番号個数品名規格備考材質 No. Drg.No. & Code No. QTY Description Rating Remarks Materials 239 H5302A BOLT, HEX SOCKET ﾎﾞﾙﾄ六角穴 M5X20L FE 240 H5307A BOLT, HEX SOCKET ﾎﾞﾙﾄ …

24.1.ｶﾑﾎﾞｯｸｽ(DCPA)

24.1.Cam box(DCPA)

番号図番 & ｺｰﾄﾞ番号個数品名規格備考材質

No. Drg.No. & Code No. QTY Description Rating Remarks Materials

153 H4232X 4 BEARING ﾍﾞｱﾘﾝｸﾞ HR32006XJP5 FE

154 S1039A 1

CIR-CLIP

ｻｰｸﾘｯﾌﾟ STW25 FE

156 S40443 4 SENSOR, PHOTO ｾﾝｻﾌｫﾄ EE-SX770A OT

157 N1021Z 2 NUT, LOCK ﾅｯﾄﾛｯｸ MR30 FE

158 H4420T 1 BEARING, NEEDLE ﾍﾞｱﾘﾝｸﾞﾆｰﾄﾞﾙ GK35X40X26.8XS FE

159 H4356A 3

BEARING, DRY

ﾍﾞｱﾘﾝｸﾞﾄﾞﾗｲ MB2525DU FE

160 H4349A 1

BEARING, DRY

ﾍﾞｱﾘﾝｸﾞﾄﾞﾗｲ MB2015DU FE

161 H4346A 2

BEARING, DRY

ﾍﾞｱﾘﾝｸﾞﾄﾞﾗｲ MB1815DU FE

162 N1019H 2

NUT, FINE U

ﾅｯﾄﾌｧｲﾝU AN04 FE

164 S31207 2 SW, PHOTOELECTRIC SW 光電 EE-SX771A OT

165 K1001T 1 COUPLING ｶｯﾌﾟﾘﾝｸﾞ LAD-20C-4X6 OT

174 W1012A

WASHER, CONICAL

ﾜｯｼｬ皿

M-5-L FE

182 H4193T 4 BEARING ﾍﾞｱﾘﾝｸﾞ 6305ZZ FE

183 DCPA0470 4 SEAL ｼｰﾙ FE

187 WPA1300 3 KEY ｷｰ FE

188 WPA0351 1 WASHER ﾜｯｼｬ FE

189 WPA1642 1 SPRING, PLATE ｽﾌﾟﾘﾝｸﾞ板 FE

190 WPA1650 1 SCREW ﾈｼﾞ FE

191 WPA1681 1 BKT BKT FE

192 WPA1732 1 GUIDE ｶﾞｲﾄﾞ FE

194 WPA1771 2 SPRING, PLATE ｽﾌﾟﾘﾝｸﾞ板 FE

195 WPA1750 1 PLATE ﾌﾟﾚｰﾄ FE

196 WPA1740 1 PLATE ﾌﾟﾚｰﾄ FE

198 S31970 1

SW, LIMIT

SW ﾘﾐｯﾄ XCS-A501 OT

199 S31971 1

SW, LIMIT

SW ﾘﾐｯﾄ XCS-Z01 OT

202 DCPA1090 1 SCALE ﾒﾓﾘ OT

205 DCPA0172 1 COUPLING ｶｯﾌﾟﾘﾝｸﾞ OT

209 H52680 BOLT, HEX SOCKET ﾎﾞﾙﾄ六角穴 M02.5X015L FE

210 W1020H

WASHER, LOCK

ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 2.5M/M FE

219 DCPA0850 1 BKT BKT FE

220 DCPA1250 1 GUIDE, RAIL ｶﾞｲﾄﾞﾚｰﾙ OT

221 DCPA1650 1 BKT BKT FE

222 DCPA1660 1 HANDLE ﾊﾝﾄﾞﾙ OT

223 DCPA1670 1 BKT BKT FE

224 SAM6452 1 MOTOR, AC SERVO ﾓｰﾀ ACｻｰﾎﾞ OT

225 SAM6503 1 MOTOR, AC SERVO ﾓｰﾀ ACｻｰﾎﾞ OT

227 H5274A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M3X6L FE

228 H5275A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M3X8L FE

229 H5276A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M3X10L FE

232 H5287A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M4X8L FE

233 H5288A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M4X10L FE

234 H5289A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M4X12L FE

235 H5290A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M4X15L FE

237 H5299A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M5X12L FE

238 H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ六角穴 M5X15L FE

CP-743ME,CP-742ME PARTS LIST

24 - 5

24.1.ｶﾑﾎﾞｯｸｽ(DCPA)

24.1.Cam box(DCPA)

24.1.ｶﾑﾎﾞｯｸｽ(DCPA)

24.1.Cam box(DCPA)

番号図番 & ｺｰﾄﾞ番号個数品名規格備考材質

No. Drg.No. & Code No. QTY Description Rating Remarks Materials

239 H5302A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M5X20L FE

240 H5307A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M5X40L FE

241 H5320A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M6X10L FE

242 H5321A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M6X12L FE

243 H5322A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M6X15L FE

244 H5324A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M6X20L FE

245 H5326A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M6X25L FE

246 H5340A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M8X15L FE

247 H5341A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M8X20L FE

248 H5342A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M8X25L FE

249 H5343A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M8X30L FE

250 H5344A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M8X35L FE

251 H5345A BOLT, HEX SOCKET ﾎﾞﾙﾄ六角穴 M8X40L FE

252 H5360A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M10X25L FE

253 H5364A

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M10X45L FE

255 W1021A

WASHER, LOCK

ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 3M/M FE

256 W1022A

WASHER, LOCK

ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 4M/M FE

257 W1023A

WASHER, LOCK

ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 5M/M FE

258 W1024A

WASHER, LOCK

ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 6M/M FE

259 W1025A

WASHER, LOCK

ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 8M/M FE

260 W1026A

WASHER, LOCK

ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 10M/M FE

261 W1029A

WASHER, LOCK

ﾜｯｼｬｽﾌﾟﾘﾝｸﾞ 16M/M FE

262 W1042A WASHER, FLAT ﾜｯｼｬ平 4W-3 FE

264 W1046A WASHER, FLAT ﾜｯｼｬ平 4W-8 FE

265 W1047A WASHER, FLAT ﾜｯｼｬ平 4W-10 FE

266 W1010A

WASHER, CONICAL

ﾜｯｼｬ皿

M-3-L FE

267 W1011A

WASHER, CONICAL

ﾜｯｼｬ皿

M-4-L FE

268 W1013A

WASHER, CONICAL

ﾜｯｼｬ皿

M-6-H FE

269 W1014A

WASHER, CONICAL

ﾜｯｼｬ皿

M-8-H FE

270 W1052A WASHER, FLAT ﾜｯｼｬ平 8M/MX1.6X17(1W-8) FE

271 K5357T

SCREW, HEX SOCKET COUNTERSUNK

小ﾈｼﾞ六角穴皿

M3X8L FE

272 H5214A

BOLT, HEX

ﾎﾞﾙﾄ六角

M10X45L FE

274 N4027A

SCREW, HEX SOCKET SET

ﾈｼﾞ六角穴止め

M4X5L FE

275 N4036A

SCREW, HEX SOCKET SET

ﾈｼﾞ六角穴止め

M5X5L FE

276 W1012A WASHER, CONICAL ﾜｯｼｬ皿 M-5-L FE

277 K5208A SCREW, TRUSS 小ﾈｼﾞﾄﾗｽ M4X6L FE

279 N1083A NUT, HEX ﾅｯﾄ六角 M5 P=0.8 3ｼｭ FE

282 N1099T

NUT, HEX

ﾅｯﾄ六角

M16 P=1.5 FE

283 W1043A WASHER, FLAT ﾜｯｼｬ平 4W-4 FE

284 N1089A

NUT, HEX

ﾅｯﾄ六角

M8 P=1.25 FE

286 DCPA0510 1 COLLAR ｶﾗｰ FE

293 H2064A 2 PIN, SPRING ﾋﾟﾝｽﾌﾟﾘﾝｸﾞﾟ5X30L 重荷重用 FE

294 H5278T

BOLT, HEX SOCKET

ﾎﾞﾙﾄ六角穴

M3X18L FE

295 DGPA0030 1 BKT BKT FE

296 S2010K 1 ILLUMINATION LAMP 照明灯 FT1101-GL16(60Hz) 注2.Note.2 OT

CP-743ME,CP-742ME PARTS LIST

24 - 6

24.1.ｶﾑﾎﾞｯｸｽ(DCPA)

24.1.Cam box(DCPA)

24.1.ｶﾑﾎﾞｯｸｽ(DCPA)

24.1.Cam box(DCPA)

番号図番 & ｺｰﾄﾞ番号個数品名規格備考材質

No. Drg.No. & Code No. QTY Description Rating Remarks Materials

297 ADCPA8020 1 COVER, ACRYLIC ｶﾊﾞｰｱｸﾘﾙ OT

307 ADCPA8070 1 GUIDE, RAIL ｶﾞｲﾄﾞﾚｰﾙ OT

308 ADCPA8041 1 HANDLE ﾊﾝﾄﾞﾙ OT

309 DCPA1160 1 DOG ﾄﾞｯｸﾞ FE

310 DCPA1180 1 DOG ﾄﾞｯｸﾞ FE

311 S2010F 1 ILLUMINATION LAMP 照明灯 FT11001-GL15(50Hz) 注2.Note.2 OT

312 K52565 SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M4X6L . FE

注1.No.117,118,119,120は組み合わせ部品ですので同時に交換してください。

Note.1: No.117,118,119 and No.120 are used as set. If the replacement of one of the parts is necessary all must be replaced.

注2.(仕様選択部品)S2010M(60Hz),S2010H(50Hz)

Note.2:(Specified parts selection)S2010M(60Hz),S2010H(50Hz)

CP-743ME,CP-742ME PARTS LIST

24 - 7
