28.ｶﾊﾞｰ(後面,側面,D軸)(DGAF) 28.Cover(Rear,Side,D axis)(DGAF) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質 No. Drg.No. & Code No. QTY Description Rating Remarks Materials 95 W1021A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE 96 W1022A WASHER,…
28.ｶﾊﾞｰ(後面,側面,D軸)(DGAF)
28.Cover(Rear,Side,D axis)(DGAF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
47 DCAF0550 1 BKT BKT FE
48 DGAF0490 1 BKT BKT FE
49 DGAF0110 2 FRAME ﾌﾚｰﾑ FE
50 DGAF0890 1 BKT BKT FE
51 DGAF0910 1 BKT BKT FE
52 DGAF0252 1 RAIL ﾚｰﾙ AL
53 DGAF0282 2 RAIL ﾚｰﾙ AL
54 DGAF0900 1 BKT BKT FE
55 DGAF0920 1 BKT BKT FE
56 DGAF0242 1 RAIL ﾚｰﾙ AL
57 DGAF0360 1 BKT BKT FE
58 DGAF0370 1 BKT BKT FE
59 DCAF0630 22 BKT BKT FE
60 DCAF0940 1 BKT BKT FE
61 DCAF0410 1 BKT BKT FE
62 DCAF0400 4 BKT BKT FE
63 DGAF0510 2 BKT, SW BKT SW FE
64 DGAF0521 1 PLATE, SW ﾌﾟﾚｰﾄ SW FE
65 DGAF0350 1 BKT, SW BKT SW FE
66 DGAF0480 1 BKT, SW BKT SW FE
67 DGAF0531 1 PLATE, SW ﾌﾟﾚｰﾄ SW FE
68 DCAF0390 2 LOCATOR 当金 FE
70 DGAF0970 1 COVER 蓋 FE
71 DGAF0440 4 SLIDER ｽﾗｲﾀﾞ OT
72 T5005T 4 HANDLE 取手 THA-132-3-3473 OT
73 M1010K 8 MAGNET CATCH ﾏｸﾞﾈｯﾄｷｬｯﾁ TL-75-1181 OT
75 S3193K 4 SW, LIMIT SW ﾘﾐｯﾄ D4DL-1DFG-B OT
76 S3193N 4 SW, LIMIT SW ﾘﾐｯﾄ D4DS-K1 OT
77 H5274A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X5L FE
78 H5276A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X10L FE
79 H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L FE
80 H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X10L FE
81 H5289A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X12L FE
82 H5290A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X15L FE
83 H5297A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X8L FE
84 H5298A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X10L FE
85 H5299A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X12L FE
86 H5300A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L FE
87 H5301A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X18L FE
88 H5302A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X20L FE
90 H5322A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X15L FE
91 H5323A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X18L FE
92 H5324A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X20L FE
93 H5341A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M8X20L FE
94 H5342A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M8X25L FE
CP-743ME,CP-742ME PARTS LIST
28 - 4
28.ｶﾊﾞｰ(後面,側面,D軸)(DGAF)
28.Cover(Rear,Side,D axis)(DGAF)
28.ｶﾊﾞｰ(後面,側面,D軸)(DGAF)
28.Cover(Rear,Side,D axis)(DGAF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
95 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
96 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
97 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
98 W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
99 W1025A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M FE
100 W1041A WASHER, FLAT ﾜｯｼｬ 平 4M/MX0.8X9(1W-4) FE
101 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
102 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
103 W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6 FE
104 W1010A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-3-L FE
105 W1011A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-4-L FE
106 W1013A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-6-H FE
107 K5215A
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M5X10L FE
108 K51721 SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M3X5L FE
109 K5257A
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M4X8L FE
111 K5260A
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M5X8L FE
112 K5261A
SCREW, HEX SOCKET BUTTON
小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M5X10L FE
113 N1080A
NUT, HEX
ﾅｯﾄ 六角
M4 P=0.7 FE
114 W1046A WASHER, FLAT ﾜｯｼｬ 平 4W-8 FE
115 ADCAF8050 1 PLATE, ACRYLIC ﾌﾟﾚｰﾄ ｱｸﾘﾙ PL
116 DCAF0220 1 BKT BKT FE
117 ADGAF8050 2 PLATE ﾌﾟﾚｰﾄ OT
118 DGAF0420 2 BKT BKT FE
119 DGAF0311 1 BKT BKT FE
120 DGAF0320 1 BKT BKT FE
121 DGAF0330 1 BKT BKT FE
122 DGAF0340 1 BKT BKT FE
123 DGAF0220 1 FRAME ﾌﾚｰﾑ FE
124 DGAF0230 1 FRAME ﾌﾚｰﾑ FE
125 DGAF0450 1 BKT BKT FE
126 DGAF0460 2 COVER 蓋 FE
127 DGAF0470 2 COVER 蓋 FE
128 DGAF0850 1 BKT BKT FE
129 DGAF0860 1 BKT BKT FE
130 DCAF0670 4 BKT BKT FE
131 DGAF0500 1 BKT BKT FE
132 DGAF0542 8 BLOCK ﾌﾞﾛｯｸ FE
133 H5263C
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X16L FE
134 H5304A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X25L FE
136 H5295A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X35L FE
137 W1012A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-5-L FE
138 K5208A
SCREW, TRUSS
小ﾈｼﾞ ﾄﾗｽ M4X6L FE
139 ADCAF8071 2 BKT BKT OT
140 DCAF0781 2 BKT BKT FE
141 DCAF0790 2 PLATE ﾌﾟﾚｰﾄ PL
CP-743ME,CP-742ME PARTS LIST
28 - 5
28.ｶﾊﾞｰ(後面,側面,D軸)(DGAF)
28.Cover(Rear,Side,D axis)(DGAF)
28.ｶﾊﾞｰ(後面,側面,D軸)(DGAF)
28.Cover(Rear,Side,D axis)(DGAF)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
142 DCAF2010 2 BKT BKT FE
143 DCAF2020 2 BKT BKT FE
144 DCAF0980 2 SPACER ｽﾍﾟｰｻ FE
145 DCAF0990 2 BKT BKT FE
146 MPZ6220 8
WASHER
ﾜｯｼｬ FE
147 WWM0210 (1) SEAL ｼｰﾙ PL
148 H5137S 2 BOLT, STOPPER ﾎﾞﾙﾄ ｽﾄｯﾊﾟ UNST6-30 FE
149 A1002Z 2 LEG, RUBBER 脚 ｺﾞﾑ K18(No.7217) OT
150 W1040 WASHER, FLAT ﾜｯｼｬ 平 1W-3 FE
153 H5326A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M6X25L FE
154 DCAF2050 4 SEAL ｼｰﾙ PL
155 DCWM0250 1 SEAL ｼｰﾙ Japanese(Ref.32-7) PL
156 DCWM0450 1 SEAL ｼｰﾙ English(Ref.32-9) PL
157 DCWM0650 1 SEAL ｼｰﾙ French(Ref.32-11) PL
158 DGAF0930 1 BKT BKT FE
159 DGAF5940 2 BKT BKT FE
160 H5137S 2 BOLT, STOPPER ﾎﾞﾙﾄ ｽﾄｯﾊﾟ FE
161 N1086A NUT, HEX ﾅｯﾄ 六角 M6 P=1.0 FE
162 DCGC0470 1 DISPLAY, LIQUID CRYSTAL ﾃﾞｨｽﾌﾟﾚｲ 液晶 743E OT
163 ZG827DCEM9850 1 BOX, SERVO BOX ｻｰﾎﾞ 743E . OT
注1.注1の部品をｾｯﾄで購入することができます｡ADGAF8081ﾌﾚｰﾑで注文してください｡
Note.1:Note.1 items can be purchased separately or as set(ADGAF8081 Frame).
注2.注2の部品をｾｯﾄで購入することができます｡ADGAF8091ﾌﾚｰﾑで注文してください｡
Note.2:Note.2 items can be purchased separately or as set(ADGAF8091 Frame).
CP-743ME,CP-742ME PARTS LIST
28 - 6
