X 3 0 前側 後側 F r o n t S i d e R e a r S i d e 1 0 9 1 1 7 5 5 7 3 9 7 5 5 7 3 9 7 5 5 7 3 9 9 4 9 3 9 2 1 2 1 0 9 1 1 1 2 7 4 5 6 3 8 7 4 9 6 5 6 3 8 7 1 6 1 7 2 4 4 5 9 6 7 4 5 6 3 8 7 4 5 6 3 8 6 8 8 7 3 5 5 3 7 6 5 …
31.本体(DGAB)
31.Body(DGAB)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
52 H3018R 1 FILTER ﾌｨﾙﾀ FL-16 OT
53 H3018T 6 FILTER ﾌｨﾙﾀ FL-12 OT
54 H5302A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X20L FE
55 K5170R SCREW, HEX C/R COUNTERSUNK 小ﾈｼﾞ 十穴皿 M5X20L FE
56 N1082A
NUT, HEX
ﾅｯﾄ 六角
M5 P=0.8 FE
57 W1050A WASHER, FLAT ﾜｯｼｬ 平 5M/MX1.0X10(1W-5) FE
58 DCAB0370 12 SHEET, LEVELING ｼｰﾄ ﾚﾍﾞﾘﾝｸﾞ (H=900) FE
59 DCAB0380 12 SHEET, LEVELING ｼｰﾄ ﾚﾍﾞﾘﾝｸﾞ (H=912) FE
60 BB43880 12 SHEET, LEVELING ｼｰﾄ ﾚﾍﾞﾘﾝｸﾞ (H=920) FE
61 BB42950 12 SHEET, LEVELING ｼｰﾄ ﾚﾍﾞﾘﾝｸﾞ (H=980) FE
62 GGA8030 12 SHEET, LEVELING ｼｰﾄ ﾚﾍﾞﾘﾝｸﾞ (H=950) FE
63 GGA8040 12 SHEET, LEVELING ｼｰﾄ ﾚﾍﾞﾘﾝｸﾞ (H=965) FE
64 GGA8060 12 SHEET, LEVELING ｼｰﾄ ﾚﾍﾞﾘﾝｸﾞ (H=930,935) FE
65 DCAB0390 12 SHEET, LEVELING ｼｰﾄ ﾚﾍﾞﾘﾝｸﾞ (H=912) FE
66 DCAB0400 12 BLOCK, LEVELING ﾌﾞﾛｯｸ ﾚﾍﾞﾘﾝｸﾞ (H=930) FE
67 DCAB0410 12 BLOCK, LEVELING ﾌﾞﾛｯｸ ﾚﾍﾞﾘﾝｸﾞ (H=962,965) FE
68 DCAB0420 12 BLOCK, LEVELING ﾌﾞﾛｯｸ ﾚﾍﾞﾘﾝｸﾞ (H=980) FE
69 GXA2071 12 SHEET, LEVELING ｼｰﾄ ﾚﾍﾞﾘﾝｸﾞ (H=920) FE
70 WAB0601 12 BLOCK, LEVELING ﾌﾞﾛｯｸ ﾚﾍﾞﾘﾝｸﾞ (H=935) FE
71 GXA2121 12 BLOCK, LEVELING ﾌﾞﾛｯｸ ﾚﾍﾞﾘﾝｸﾞ (H=950) FE
72 WAB0721 12 PAD, ANTI-VIBRATION ﾊﾟｯﾄ 防振 OT
73 DGAB0018 1 BODY 本体 FE
77 H1137E 1 BAND, TIE ﾊﾞﾝﾄﾞ 結束 AB-14N OT
78 H1137D 1 BAND, TIE ﾊﾞﾝﾄﾞ 結束 AB-4N OT
79 K5210A SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M4X10L FE
80 DCAB0330 2 BKT, JOINT BKT ｼﾞｮｲﾝﾄ Option FE
81 DCAB0340 2 BKT, JOINT BKT ｼﾞｮｲﾝﾄ Option FE
82 DGAB0510 1 BKT, JOINT BKT ｼﾞｮｲﾝﾄ Option FE
83 DGAB0520 1 BKT, JOINT BKT ｼﾞｮｲﾝﾄ Option FE
84 DGAB0530 1 BKT, JOINT BKT ｼﾞｮｲﾝﾄ Option FE
85 DGAB0540 1 BKT, JOINT BKT ｼﾞｮｲﾝﾄ FE
86 H5391A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M12X40L FE
87 H5392A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M12X45L FE
88 H5395A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M12X50L FE
89 H5365A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M10X50L FE
90 W1027A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 12M/M FE
91 W1026A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 10M/M FE
92 W1048A WASHER, FLAT ﾜｯｼｬ 平 4W-12 FE
93 W1047A WASHER, FLAT ﾜｯｼｬ 平 4W-10 FE
CP-743ME,CP-742ME PARTS LIST
31 - 3
31.本体(DGAB)
31.Body(DGAB)
X30
前側
後側
Front Side
Rear Side
10
9
11
75
57
39
75
57
39
75
57
39
94
93
92
12
10
9
11
12
74
56
38
74
96
56
38
7
16
17
2
4
4
5
96
74
56
38
74
56
38
6
8
8
73
55
37
65
47
29
68
50
32
69
51
33
18
66
48
30
67
49
31
76
73
55
37
Reverse Panel Flow
90
85
80
91
86
81
88
83
78
87
82
77
89
84
79
32.1.銘板、シール(DGWM)
32.1.Nameplate,Seal(DGWM)
32.1.銘板、シール(DGWM)
32.1.Nameplate,Seal(DGWM)
32 - 1
CP-743ME,CP-742ME PARTS LIST
32.1.銘板,ｼｰﾙ(DGWM)
32.1.Nameplate,Seal(DGWM)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
2 DCWM0020 1 NAMEPLATE, PRESSURE 銘板 圧力 PL
4 DCWM0050 2 SEAL ｼｰﾙ PL
5 DCWM0060 1 NAMEPLATE, CAUTION 銘板 注意 PL
6 DCWM0071 1 SEAL, BAR CODE ｼｰﾙﾊﾞｰｺｰﾄﾞ PL
7 DCWM0081 1 SEAL, BAR CODE ｼｰﾙﾊﾞｰｺｰﾄﾞ PL
8 DCWM0091 2 SEAL, BAR CODE ｼｰﾙﾊﾞｰｺｰﾄﾞ (Option) PL
9 KPA0900 2 NAMEPLATE, CAUTION 銘板 注意 PL
10 KPA0920 2 NAMEPLATE, CAUTION 銘板 注意 PL
11 KPA0890 2 PIN ｼｰﾙ PL
12 YWM0090 4 NAMEPLATE, CAUTION 銘板 注意 PL
16 EEBR2850 1 SEAL ｼｰﾙ PL
17 EEBR1870 1 SEAL ｼｰﾙ PL
18 EEBR1892 1 SEAL ｼｰﾙ PL
29 DGWM0340 1 NAMEPLATE, SOL 銘板 SOL Japanese PL
30 DGWM0350 1 NAMEPLATE, SOL 銘板 SOL Japanese PL
31 DCWM0300 1 NAMEPLATE, SOL 銘板 SOL Japanese PL
32 DCWM0310 1 NAMEPLATE 銘板 Japanese PL
33 DCWM0322 1 GUIDE 銘板 SOL Japanese PL
37 DCWM0360 1 NAMEPLATE, SOL 銘板 SOL Japanese PL
38 IPK5480 1 SEAL ｼｰﾙ Japanese PL
39 IPK5580 1 SEAL ｼｰﾙ Japanese PL
47 DGWM0540 1 NAMEPLATE, SOL 銘板 SOL English PL
48 DGWM0550 1 NAMEPLATE, SOL 銘板 SOL English PL
49 DCWM0500 1 NAMEPLATE, SOL 銘板 SOL English PL
50 DCWM0510 1 NAMEPLATE 銘板 English PL
51 DCWM0522 1 NAMEPLATE, SOL 銘板 SOL English PL
56 IPK5490 1 SEAL ｼｰﾙ English PL
55 DCWM0560 1 NAMEPLATE, SOL 銘板 SOL English PL
57 IPK5590 1 SEAL ｼｰﾙ English PL
65 DGWM0740 1 NAMEPLATE, SOL 銘板 SOL French PL
66 DGWM0750 1 NAMEPLATE, SOL 銘板 SOL French PL
67 DCWM0700 1 NAMEPLATE, SOL 銘板 SOL French PL
68 DCWM0710 1 NAMEPLATE 銘板 French PL
69 DCWM0722 1 NAMEPLATE, SOL 銘板 SOL French PL
73 DCWM0760 1 NAMEPLATE, SOL 銘板 SOL French PL
74 IPK5500 1 SEAL ｼｰﾙ French PL
75 IPK5600 1 SEAL ｼｰﾙ French PL
76 DGPZ3011 1 NAMEPLATE 銘板 PL
92 EEBR2840 3 SEAL ｼｰﾙ PL
93 EEBR2820 3 SEAL ｼｰﾙ PL
94 EEBR2830 3 SEAL ｼｰﾙ PL
96 DCUK0710 1 SEAL ｼｰﾙ PL
CP-743ME,CP-742ME PARTS LIST
32 - 2
32.1.銘板,ｼｰﾙ(DGWM)
32.1.Nameplate,Seal(DGWM)
