R e f . 3 3 - 7 E E 1 2 % X 3 0 5 % 0 . 5 1 2 C D B A C B D 6 3 2 6 2 5 2 4 2 4 2 6 2 5 6 7 6 8 2 2 6 0 6 6 6 4 6 5 6 1 6 2 B D C 7 5 2 6 2 5 2 6 2 5 6 7 6 8 2 3 7 2 7 6 7 7 6 6 6 9 7 0 7 1 6 9 7 0 7 1 7 3 7 4 A 4 7 4 6 …
13.1.ﾌｨｰﾀﾞﾁｪｯｸｾﾝｻ(DGGZ)
13.1.Feeder check sensor(DGGZ)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
60 . SCREW, C/R PAN 小ﾈｼﾞ 十穴鍋 M4X6L FE
61 H5263E BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X15L FE
62 H5322A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X15L FE
63 H5326A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X25L FE
64 H5346A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X45L FE
65 W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M FE
66 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
67 W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
68 W1024A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 6M/M FE
69 W1042A WASHER, FLAT ﾜｯｼｬ 平 4W-3 FE
70 W1043A WASHER, FLAT ﾜｯｼｬ 平 4W-4 FE
71 W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
72 W1045A WASHER, FLAT ﾜｯｼｬ 平 4W-6 FE
73 W1051A WASHER, FLAT ﾜｯｼｬ 平 6M/MX1.6X12.5(1W-6) FE
74 W1010A
WASHER, CONICAL
ﾜｯｼｬ 皿
M-3-L FE
75 N1076A
NUT, HEX
ﾅｯﾄ 六角
M3 P=0.5 FE
76 N1080A
NUT, HEX
ﾅｯﾄ 六角
M4 P=0.7 FE
77 N1085A
NUT, HEX
ﾅｯﾄ 六角
M6 P=1.0 FE
78 N1081T
NUT, HEX
ﾅｯﾄ 六角
M4 FE
79 H5289A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12L FE
80 H5289A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X12L FE
81 DCGZ0690 1 RETAINER 押え FE
82 DGPZ1560 1 COVER ｶﾊﾞｰ CX.242∼ FE
83 DGPZ1420 2 BKT BKT FE
84 DGPZ1430 2 PLATE ﾌﾚｰﾄ FE
85 H5287A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8L FE
86 H5320A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M6X10L FE
87 DCWM0210 1 SEAL ｼｰﾙ Japanese(Ref.32-7) PL
88 DCWM0220 2 SEAL ｼｰﾙ Japanese(Ref.32-7) PL
89 DCWM0410 1 SEAL ｼｰﾙ English(Ref.32-9) PL
90 DCWM0420 2 SEAL ｼｰﾙ English(Ref.32-9) PL
91 DCWM0610 1 SEAL ｼｰﾙ French(Ref.32-11) PL
92 DCWM0620 2 SEAL ｼｰﾙ French(Ref.32-11) PL
93 DCWM0250 1 SEAL ｼｰﾙ Japanese(Ref.32-7) PL
94 DCWM0450 1 SEAL ｼｰﾙ English(Ref.32-9) PL
95 DCWM0650 1 SEAL ｼｰﾙ French(Ref.32-11) PL
96 DGPZ4011 1 COVER ｶﾊﾞｰ ∼CX.241 FE
97 H5298A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X10L FE
98 W1050A WASHER, FLAT ﾜｯｼｬ 平 5M/MX1.0X10(1W-5) . FE
CP-743ME,CP-742ME PARTS LIST
13 - 4
13.1.ﾌｨｰﾀﾞﾁｪｯｸｾﾝｻ(DGGZ)
13.1.Feeder check sensor(DGGZ)
Ref.33-7
E
E
12%
X30
5%
0.5 1 2
C D
B
A
C
B
D
63
26
25
24
24
26
25
67
68
22
60
66
64
65
61
62
B
D
C
75
26
25
26
25
67
68
23
72
76
77
66
69
70
71
69
70
71
73
74
A
47
46
45
59
58
57
56
35
35
35
35
31
27
42
42
42
40
42
37
37
37
37
36
28 29
30
30
32
29
38
39
39
39
39
41
34
34
34
34
33
44
51
50
54
55
55
53
49
48
43
52
7
10
12
15
8
9
17
13
11
20
16
21
21
19
14
2
6
1
18
5
4
3
78
13.2.フィーダベリファイ(DGGZ)
13.2.Feeder verification(DGGZ)
13.2.フィーダベリファイ(DGGZ)
13.2.Feeder verification(DGGZ)
13 - 5
CP-743ME,CP-742ME PARTS LIST
13.2.ﾌｨｰﾀﾞﾍﾞﾘﾌｧｲ(DGGZ)
13.2.Feeder Verification(DGGZ)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 ADGGZ4511 2 SENSOR ｾﾝｻ OT
2 DGGZ4020 2 BKT, SENSOR BKT ｾﾝｻ FE
3 H5299A 4 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12 FE
4 W1023A 4 WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M FE
5 W1044A 4 WASHER, FLAT ﾜｯｼｬ 平 4W-5 FE
6 DGGZ4030 2 COVER ｶﾊﾞｰ FE
7 K5170T 24 SCREW, C/R TRUSS 小ﾈｼﾞ 十穴ﾄﾗｽ M3X6 FE
8 DGGZ4040 2 COVER, PROTECTIVE ｶﾊﾞｰ 保護 FE
9 K5170T 8 SCREW, C/R TRUSS 小ﾈｼﾞ 十穴ﾄﾗｽ M3X6 FE
10 DGGZ4140 2 COVER, DUSTPROOF ｶﾊﾞｰ 防塵 S10用 PL
11 DGGZ4150 2 PLATE, INSULATING ﾌﾟﾚｰﾄ 絶縁 L10用 PL
12 DCGZ3050 2 COVER, DUSTPROOF ｶﾊﾞｰ 防塵 S30用 PL
13 DCGZ3140 2 PLATE, INSULATING ﾌﾟﾚｰﾄ 絶縁 L30用 PL
14 S40571 2 SENSOR ｾﾝｻ K96-P-FK-S10 ｾﾝｻ基板 OT
15 S40573 2 SENSOR ｾﾝｻ K96-P-FK-S30 ｾﾝｻ基板 OT
16 S4057H 2 SENSOR ｾﾝｻ K96-P-FK-L10 LED基板 OT
17 S4057M 2 SENSOR ｾﾝｻ K96-P-FK-L30R LED基板 OT
18 S32273 24 SPACER ｽﾍﾟｰｻ ESB-305 OT
19 S3227H 24 SPACER ｽﾍﾟｰｻ ASB-315 OT
20 S3227Z 12 SPACER ｽﾍﾟｰｻ C-305 OT
21 K5171D 12 SCREW, C/R TRUSS 小ﾈｼﾞ 十穴ﾄﾗｽ M3X12 FE
22 ADGGZ4520 1 SENSOR ｾﾝｻ D1側 OT
23 ADGGZ4530 1 SENSOR ｾﾝｻ D2側 OT
24 DGGZ4010 2 BKT, SENSOR BKT ｾﾝｻ FE
25 H5179G 4 BOLT, HEX ﾎﾞﾙﾄ 六角 M5X50 FE
26 N1082A 4 NUT, HEX ﾅｯﾄ 六角 M5 P=0.8 FE
27 DGGZ4110 2 PLATE ﾌﾟﾚｰﾄ FE
28 DGGZ4120 2 PLATE ﾌﾟﾚｰﾄ FE
29 H5287A 8 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X8 FE
30 W1022A 8 WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
31 DGGZ4130 2 COVER ｶﾊﾞｰ FE
32 K5202A 8 SCREW, C/R TRUSS 小ﾈｼﾞ 十穴ﾄﾗｽ M3X3 FE
33 DCGZ3120 2 COVER ｶﾊﾞｰ FE
34 K5170T 8 SCREW, C/R TRUSS 小ﾈｼﾞ 十穴ﾄﾗｽ M3X6 FE
35 S3227S 8 SPACER ｽﾍﾟｰｻ BSB-305-6 OT
36 S4057Z 2 SENSOR ｾﾝｻ K96-P-FK-R30 通信基板 OT
37 S3227W 8 SPACER ｽﾍﾟｰｻ BSB-319-6 OT
38 S4057T 2 SENSOR ｾﾝｻ K96-P-FK-R10 通信基板 OT
39 S3227L 8 SPACER ｽﾍﾟｰｻ ASB-319 OT
40 S3227Z 2 SPACER ｽﾍﾟｰｻ C-305 OT
41 K5171D 2 SCREW, C/R TRUSS 小ﾈｼﾞ 十穴ﾄﾗｽ M3X12 FE
42 S32273 8 SPACER ｽﾍﾟｰｻ ESB-305 OT
43 ADGGZ4540 2 SENSOR ｾﾝｻ OT
44 DGGZ4060 2 PLATE ﾌﾟﾚｰﾄ FE
45 H5291A 8 BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X18 FE
CP-743ME,CP-742ME PARTS LIST
13 - 6
13.2.ﾌｨｰﾀﾞﾍﾞﾘﾌｧｲ(DGGZ)
13.2.Feeder Verification(DGGZ)
