30.6.5.5 Combination Methods
These solder extraction
methods provide controlled combinations of heat, pressure,
vacuum, and airflow for the controlled removal of any sol-
der joint configuration. Advantages: This solder removal
method is easily manipulated, fully controllable and allows
a trained and skilled operator to easily remove solder and
components from most types of assemblies.
A. Solder Extraction (Continuous Vacuum) This method
uses a hollow soldering iron and tip to melt the solder and
after the solder is molten, the solder is sucked out of the
solder joint by an operator controlled vacuum pump. This
method can also be used for clinched leads, blindhlocked
holes, and auxiliary heating.
B.
Solder Extraction (Pressure Mode) This method uses a
hollow soldering iron and tip to melt the solder and after
the solder is molten, to blow it out of the solder joint by an
operator controlled vacuudpressure pump. This solder
extractor pressure method is suitable for removing solder
from blind or blocked component lead mounting holes.
30.6.5.6 Clip-and-Fix Method
In the clip-and-fix
method, the component leads of the component to be
removed are cut
off
at (or near) the component body. This
is generally not performed when the component to remove
is thought to be good. In some cases it may be desirable to
remove individual component leads with a small jet of hot
air. After solder melt the component lead is lifted
off
the
land.
30.6.6 Replacement of Surface Mounted Devices
The
general requirements and procedures for surface mounted
components are in IPC-A-610.
Prior to replacement, the surface mount component and the
land patterns on the printed board structure may have to be
hot air leveled, or pretinned and fluxed. The component
must then be precisely positioned on the land pattern and
stabilized (held in place) during solder reflow and cool
down.
CAUTION: Hot air leveling can cause undesirable over-
heating of the component, adjacent components, solder
joints, and the printed board structure.
It is not recommended, but hand soldering replacement
with a microscope aid can be successful.
6-3
