NPM Parts list(Mechanical 20090728) - 第350页
46-G デュアルコンベアステーション( 搬送部 ):NPM Dual Conveyor Station(Trannsport Unit):NPM パーツレイアウト Ki t N o . キット 品番 Kit N am e キット名称 N6 1010 048 6AA ｾｸｼｮﾝNo. PARTS LAYOUT Section No. - - O243 ( KN610100486AA-03-7 )
Ref
No.
Remarks
R
1
Q'ty
46-F
デュアルコンベアステーション(
搬送部
):NPM
Dual Conveyor Station(Trannsport Unit):NPM
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610100486AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
FRAME
1
3 N210122963AA
GUIDE
1
5 N210123023AA
GUIDE
1
6 N210105096AB
GUIDE
1
7 N210105097AC
PULLEY
1
8 N210092041AA
RING
1
9 N210088855AA
BRACKET
1
18 N210109955AA
BRACKET
1
19 N210105892AA
DOG
1
20 N210123035AB
BRACKET
1
24 N210123040AA
MOTOR
1
40 N510037232AA
S
DU13H713S-01
NUT
1
49 N510048038AA NSMT-04-4
T-BELT
1
50 N510051433AA
A
NSE7113A 4.5WX990.0LX0.65T
CAM-FOLLOWER
4
51 N510043608AA U-AS4-79
AMP
1
56 N510035086AA FX-101-PFS
CABLE-BEAR
1
57 N510044608AA TKP0250W20R37X15LINK
BOLT
4
58 N510017614AA
Hexagon socket Flat head bolt M4X10-10.9 A2J (Trivalent)
BRACKET
1
60 N510044606AA TKP0250W20-PIA
BRACKET
1
61 N510044607AA TKP0250W20-PKA
BOLT
4
74 N510017341AA
Hexagon socket head cap screw M3X8-10.9 A2J (Trivalent)
BOLT
2
75 N510017308AA
Hexagon socket head cap screw M3X12-10.9 A2J (Trivalent)
BOLT
10
77 N510017344AA
Hexagon socket head cap screw M4X10-10.9 A2J (Trivalent)
BOLT
1
78 N510017351AA
Hexagon socket head cap screw M4X16-10.9 A2J (Trivalent)
BOLT
5
80 N510017390AA
Hexagon socket head cap screw M5X12-10.9 A2J (Trivalent)
WASHER
4
82 N510018494AA
Round finish plain washer 3 10H A2J (Trivalent)
WASHER
10
83 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
5
84 N510018499AA
Round finish plain washer 5 10H A2J (Trivalent)
WASHER
2
86 N510018478AA
Small round-plain washer 3 10H A2J (Trivalent)
WASHER
4
87 N510018479AA
Small round-plain washer 4 10H A2J (Trivalent)
WASHER
2
88 N510020098AA Thick washer M3
WASHER
5
89 N510020099AA Thick washer M4
WASHER
2
92 N510018327AA Spring lock washer No.2 3 S A2J (Trivalent)
WASHER
4
93 N510018330AA Spring lock washer No.2 4 S A2J (Trivalent)
NUT
4
94 N510017855AA
Hexagon nut Type-1 Best class M4-6H-4T A2J (Trivalent)
SCREW
1
96 XXE5D8FT
Hexagon socket set screw Cup point M5X8-45H SOB
COLLAR
2
103 N510038859AA 87FNCLM-V5.0-D12.0-L10.0
BOLT
2
105 N510017398AA
Hexagon socket head cap screw M5X20-10.9 A2J (Trivalent)
O242
--
( KN610100486AA-03-6 )
46-G
デュアルコンベアステーション(
搬送部
):NPM
Dual Conveyor Station(Trannsport Unit):NPM
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610100486AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
O243
( KN610100486AA-03-7 )
Ref
No.
Remarks
R
1
Q'ty
46-G
デュアルコンベアステーション(
搬送部
):NPM
Dual Conveyor Station(Trannsport Unit):NPM
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610100486AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
FRAME
1
4 N210122964AA
GUIDE
1
5 N210123023AA
GUIDE
1
6 N210105096AB
GUIDE
1
7 N210105097AC
PULLEY
1
8 N210092041AA
RING
1
9 N210088855AA
BRACKET
1
18 N210109955AA
BRACKET
1
19 N210105892AA
DOG
1
21 N210123036AB
MOTOR
1
40 N510037232AA
S
DU13H713S-01
GREASE-NIPPLE
1
43 N560AMT6-130 A-MT6X1-Type(M6X1)
NUT
1
49 N510048038AA NSMT-04-4
T-BELT
1
50 N510051433AA
A
NSE7113A 4.5WX990.0LX0.65T
CAM-FOLLOWER
4
51 N510043608AA U-AS4-79
CABLE-BEAR
1
57 N510044608AA TKP0250W20R37X15LINK
BOLT
4
58 N510017614AA
Hexagon socket Flat head bolt M4X10-10.9 A2J (Trivalent)
BRACKET
1
60 N510044606AA TKP0250W20-PIA
BRACKET
1
61 N510044607AA TKP0250W20-PKA
BOLT
4
74 N510017341AA
Hexagon socket head cap screw M3X8-10.9 A2J (Trivalent)
BOLT
2
75 N510017308AA
Hexagon socket head cap screw M3X12-10.9 A2J (Trivalent)
BOLT
8
77 N510017344AA
Hexagon socket head cap screw M4X10-10.9 A2J (Trivalent)
BOLT
5
80 N510017390AA
Hexagon socket head cap screw M5X12-10.9 A2J (Trivalent)
WASHER
4
82 N510018494AA
Round finish plain washer 3 10H A2J (Trivalent)
WASHER
10
83 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
5
84 N510018499AA
Round finish plain washer 5 10H A2J (Trivalent)
WASHER
4
87 N510018479AA
Small round-plain washer 4 10H A2J (Trivalent)
WASHER
2
88 N510020098AA Thick washer M3
WASHER
2
89 N510020099AA Thick washer M4
WASHER
4
93 N510018330AA Spring lock washer No.2 4 S A2J (Trivalent)
NUT
4
94 N510017855AA
Hexagon nut Type-1 Best class M4-6H-4T A2J (Trivalent)
SCREW
1
96 XXE5D8FT
Hexagon socket set screw Cup point M5X8-45H SOB
COLLAR
2
103 N510038859AA 87FNCLM-V5.0-D12.0-L10.0
BOLT
2
105 N510017398AA
Hexagon socket head cap screw M5X20-10.9 A2J (Trivalent)
O244
--
( KN610100486AA-03-7 )
