1. Dispensing Uniform and precise application of a highly thixotropic material 2. Spraying Coating of large areas with a low splatter and mist spraying procedure 3. Jetting Pinpoint lacquer application of up to 120 minia…

100%1 / 24
TECHNOLOGY BENEFITS
› Greatest possible process reliability
› All-in-One lacquering and highly selective coating
› Flexible lacquering options thanks to multifunctional lacquer applicator
› Minimal maintenance
› Effective lacquering and drying in a line concept
› Quick, intuitive programming with dependable software tools
Selektive Conformal Coating Line
1. Lift station
2. Manual work station
3. Underoor return transport
4. Protecto
5. Turning station
6. Test station
7. RDS drying system
8. Removal conveyor
9. Lacquer prole inspection
10. Lift station
1.
2.
3. 4.
5.
7.
6.
8.
9.
10.
1. Dispensing
Uniform and precise application of a highly
thixotropic material
2. Spraying
Coating of large areas with a low splatter and
mist spraying procedure
3. Jetting
Pinpoint lacquer application of up to 120 minia-
ture dots per second through rapid opening and
closing of the valve
4. Curtain Coating
Spraying and fog-free coating of large surfaces
at very high process speed
1.
3.
2.
4.
Protecto Coating
Protecto
Coating
The Protecto conformal coating process from Rehm reliably protects sensitive electronic
modules with a protective lacquer from damage by corrosion or other environmental influences,
such as humidity, chemicals or dust. Coating the PCB after soldering secures the functionality of the
electronics, which may be used in end products of critical safety importance, such as in the automo-
tive, aviation or medical industries.
The multifunctional lacquer applicator and the patented Stream Coat
®
nozzles enable all standard
protective lacquers to be precisely applied by dispensing, spraying, jet or curtain coating, depending
on the application, even where the gaps between components are very small. With up to 4 coating
applicators, you can synchronise several modules simultaneously to apply the coating or directly
apply with up to 4 different materials without set-up time. Protecto is available as a production line
design with RDS lacquer dryer that will add flexibility and efciency to your production.
RSS Special Systems
Individual systems, adapted to
the needs of our clients.
Reel-to-Reel System
for continuous thermal
treatment of exible substrates
TECHNOLOGY BENEFITS
› Individual system solutions, adapted to your requirements
› Expert, high-quality mechanical engineering
› Skilled process consultation
› Flexible options for your manufacturing
› More than 25 years experience in the industry
Flexible
and
individual
