EVALUATION
1. Visual examination
2. Measurement of new pad width and spacing.
3. Electrical continuity measurement.
IPC-7721A
Number: 4.2.2
Revision:
Date: 2/98
Subject: Conductor Repair, Foil Jumper, Film Adhesive Method
Page3of4
Copyright Association Connecting Electronics Industries
Provided by IHS under license with IPC
Not for Resale
No reproduction or networking permitted without license from IHS
--``,``,-`-`,,`,,`,`,,`---
NOTES
IPC-7721A
Number: 4.2.2
Revision:
Date: 2/98
Subject: Conductor Repair, Foil Jumper, Film Adhesive Method
Page4of4
Copyright Association Connecting Electronics Industries
Provided by IHS under license with IPC
Not for Resale
No reproduction or networking permitted without license from IHS
--``,``,-`-`,,`,,`,`,,`---
OUTLINE
This procedure is used to repair short breaks or opens in conductors on printed wir-
ing boards. A parallel gap welder is used to weld a jumper ribbon across the dam-
aged conductor.
CAUTION
Welding current and voltages may affect component reliability on assembled printed
wiring boards.
CAUTION
The repaired section must not reduce the conductor width, spacings or current car-
rying capacity below the allowable tolerances.
REFERENCES
2.1 Handling Electronic Assemblies
2.2 Cleaning
2.6 Epoxy Mixing and Handling
PREPARATION
Prior to using any welding equipment, certain precautions should be taken. The
equipment should have electrodes cleaned, aligned and set for the proper board
thickness.
Test samples that have similar conductor widths, spacing, thickness, surface finish,
contour, etc. Observe and test the weld quality, alignment, discoloration, fusion and
the appearance of the base material in the area of the weld. Readjust the weld
equipment settings and repeat until acceptable results have been achieved.
The alignment of the welded ribbon to the conductor pattern should be within 0.050
mm. The weld bond strength should exceed the conductor/base material bond
strength.
TOOLS & MATERIALS
Cleaner
Cleaner Wipes
Epoxy
Knife
Kovar Ribbon
Liquid Flux
Microscope
Parallel Gap Welder
Ribbon - Gold Plated Kovar
Solder
Soldering Iron
Tweezers
7721A
Repair and
Modification of
Printed Boards and
Electronic Assemblies
Revision:
Date: 2/98
Conductor Repair,
Welding Method
Number: 4.2.3
Product Class: R, F, C
Skill Level: Advanced
Level of Conformance: High
