11. Thoroughly rinse the entire area with water. 12. Connect the gold plating probe to the power supply (+) or red jack. 13. Dip the plating probe into the gold plating solution. Wait a few seconds for the solution to sa…
BUSSING − Mechanical Probe, Individual Contacts (Option 3)
1. Each contact needing plating can be individually probed using the plating probe.
Touch the tip of the plating probe to the inboard edge of each contact or to the
connecting conductor as each solution is applied during the plating process.
BUSSING − Pin Fixture, Multiple Contacts (Option 4)
1. Make a mechanical connection to each contact using a pin fixture. The pin fix-
ture has spring loaded contact pins on centers matching the spacing of the
edge contacts to be plated. The contact pins make direct mechanical connec-
tion to the inboard tip of each contact, the connecting conductor trace or a
connecting plated through hole.
PROCEDURE − Plating Process
1. Place the printed wiring board on the board support so that the leading edge
overhangs the rinse tray.
2. Make the cathode connection (-) to the printed wiring board by using a plating
probe or probe clip. Connect the probe clip directly to the wire buss connection
or to the edge where conductive paint has been applied. The cable should be
connected to the (-) or black jack on the power supply.
3. Connect the plating probe to the power supply (+) or red jack. (See Figure 7.)
4. Set the output current on the power supply to setting recommended by the
equipment manufacturer.
5. Dip the plating probe into the electroclean plating solution. Wait a few seconds
for the solution to saturate the absorbent wrapping.
6. Swab the entire surface to be plated by brushing the surface with the saturated
plating probe. The plating probe should be moved back and forth briskly to pre-
vent burning and to provide even coverage. (See Figure 8.) Swab the area for
the time recommended by the equipment manufacturer.
7. Thoroughly rinse the entire area with water. Any burning or darkening of the
contacts may be removed with an abrasive pad. Saturate the abrasive pad and
the printed wiring board surface with water and lightly buff the contacts until all
evidence of the burning or discoloring is removed. Rinse the entire area with
water.
CAUTION
Do not allow the rework area to dry out between steps. The water coating pre-
vents oxidation.
8. Connect the nickel plating probe to the power supply (+) or red jack.
9. Dip the plating probe into the nickel plating solution. Wait a few seconds for the
solution to saturate the absorbent wrapping.
10. Swab the entire surface to be plated by brushing the surface with the saturated
plating probe. The plating probe should be moved back and forth briskly to pre-
vent burning and to provide even coverage. Swab the area for the time recom-
mended by the equipment manufacturer. Before rinsing, lightly buff the contacts
with an abrasive pad.
IPC-7721A
Number: 4.6.3
Revision:
Date: 2/98
Subject: Edge Contact Repair, Plating Method
Page4of6
Copyright Association Connecting Electronics Industries
Provided by IHS under license with IPC
Not for Resale
No reproduction or networking permitted without license from IHS
--``,``,-`-`,,`,,`,`,,`---
11. Thoroughly rinse the entire area with water.
12. Connect the gold plating probe to the power supply (+) or red jack.
13. Dip the plating probe into the gold plating solution. Wait a few seconds for the
solution to saturate the absorbent wrapping.
14. Swab the entire surface to be plated by brushing the surface with the saturated
plating probe. The plating probe should be moved back and forth briskly to pre-
vent burning and to provide even coverage. Swab the area for the time recom-
mended by the equipment manufacturer.
15. Thoroughly rinse the entire area with water.
16. Remove and discard all plating tape and thoroughly rinse the area with water.
Dry the area using a air sprayer or wipes.
17. Remove the wire or conductive paint used to buss the contacts.
CAUTION
Apply tape to protect the contacts from further contamination while removing
the buss connection.
16. Thoroughly rinse the entire area with deionized water or rinse the printed wiring
board in an aqueous water cleaning system.
EVALUATION
1. The rework area should be checked by measuring the thickness of the nickel
and gold to make sure they meet the minimum thickness requirement.
2. The plating bond may also be checked by doing a peel test using peel testing
tape.
3. Visually examine the rework area for color and luster.
