P240006 - 第172页
MODEL GXH-1 0909-004 170 架台下 C UNDERFRAME C Fig. BC-2 ケーブル R Cable R 165 164 163 162 152 167 167 173 171 168 168 154 169 169 166 See Fig.BR-7 Key No.674 See Fig.FB-2 Key No.176 See Fig.FB-2 Key No.198 178
MODEL GXH-1
1012-005
169
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
BC-1
51 6301330099 BRACKET 1 803BC-210-051 211F9224
52 6301270647 BRACKET 1 803BC-210-052 211F8378
53 6301270739
RAIL,WIRING 1 803BC-210-153 23N00099
54 6300911749
BRACKET,WIRING 3 803BC-210-154 23N10027
55 6301335704 TERMINAL
1 803BC-210-155 4J320221
56 6300697278 RELA
Y 4 -K75,-K76,-K77,-K78
803BC-210-156
4S200100
57 6300492422 BRACKET
,WIRING 4 803BC-210-157 23N10019
58 6300941418 EM-CONT
ACTOR 4 -K36,-K38,-K40,-K50
803BC-210-158
4S210086
59 6301257112
RESISTOR,SPECIAL 2 R01C,R01D 803BC-210-159 4R500008
60 6300635423
RELAY 3 -K60,-K71,-K72
803BC-210-160
4S200086
61 6300635430 SOCKET
3 803BC-210-161 4J120099
65 6301242293 UNIT
,POWER 1 G03,ADA750F-48
803BC-210-165
4U200255
70 4230252109 FUSE 250V 6.3A
8 F021D,F022D,F023D,F024D,
F021C,F022C,F023C,F024C
803BC-210-170
4S300023
71 4230228302 FUSE 250V 5A
4 F033,F034,F035,F036
803BC-210-171
4S300024
72 6300483833 MECH P
ARTS(MOUNTING BASES 6 226J0373
74 6301237138 UNIT,DRIVER 1
-A53(R) 803N--210-024 4U240429
75 6301237138
UNIT,DRIVER 2 -A63(C),-A63(D)
803BC-210-015
4U240429
81 6300007763 BOL
T,HEX-SCT 4 M5X16 221A0031
82 6300010220 W
ASHER 6 BW5 221H0005
83 411
1416705 WASHER SPR 5 6 SW5 221H0287
84 6300007756 BOL
T,HEX-SCT 2 M5X12 221A0030
91 411
1131400 SCR PAN 4X6 22 M4X6 PAN 221E0509
92 41
10423001 SCR PAN 4X10 10 M4X10 PAN 221E0500
93 41
11192104 WASHER V 4X9X0.8 32 FW4 F 221H0314
94 4110081706
WASHER SPR 4 32 SW4 F 221H0283
MODEL GXH-1
0909-004
170
架台下
C UNDERFRAME C
Fig. BC-2
ケーブル
R Cable R
165
164
163
162
152
167
167
173
171
168
168
154
169
169
166
See Fig.BR-7
Key No.674
See Fig.FB-2
Key No.176
See Fig.FB-2
Key No.198
178
MODEL GXH-1
1012-005
171
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
BC-2
152 6301269382 CORD 1 803N--210-252 4W202817
154 6301269511 CORD 1 803N--210-254 4W202823
162 6301269498 CORD 1
803N--210-262 4W202828
163 6301269504 CORD 1
803N--210-263 4W202829
164 6301269528 CORD 1
803N--210-264 4W202831
165 6301269535 CORD 1
803N--210-265 4W202832
166 6301269863 CORD 1
803N--210-266 4W202830
167 6301269351 CORD 2
803BC-210-251 4W202814
168 6301269399 CORD 2
803BC-210-253 4W202818
169 6301269764 CORD 2
803BC-210-255 4W202855
171 6301343860 CORD(X631B(DB-D)-X51
1A) 1 803NR-210-151 4W203086
173 6301343884 CORD(X531B(NC)-XX41
1A) 1 803NR-210-153 4W203088
178 6301343853 CORD(X631B8C)-X631A(D)) 1
803BC-210-258 4W203085
