MODEL GXH-1 0409-002 174 架台下 E UNDERFRAME E Fig. BE-1 一次電源 Main Power Supply 73 76 77 53 54 61 62 52 74 76 77 77 76 73 51 71 70 72 56 76 75 57 73 76 77 . . See Fig.BG-1 Key No.51 63
MODEL GXH-1
0503-003
173
Fig. BE
架台下
E UNDERFRAME E
MODEL GXH-1
0409-002
174
架台下
E UNDERFRAME E
Fig. BE-1
一次電源
Main Power Supply
73
76
77
53
54
61
62
52
74
76
77
77
76
73
51
71
70
72
56
76
75
57
73
76
77
.
.
See Fig.BG-1
Key No.51
63
MODEL GXH-1
1012-003
175
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
BE-1
51 6301268095 BRACKET 1 803BE-210-051 211F8349
52 6301268453 BRACKET 1 803BE-210-052 211F8353
53 6301286402
FILTER,NOISE 1 Z01 803BE-210-153 4F300082
54 6301286396
FILTER,NOISE 1 Z02 803BE-210-154 4F300081
56 6300835427
BREAKER 1 Q200 803BE-210-151 4S230066
57 6300835441
HANDLE 1 803BE-210-152 226C0141
61 4080310004 V
ARISTOR R.A.V-781BXZ-4 1 F200 803BE-210-251 4V320010
62 6301231303
FUSE,SPECIAL 3 F201,F202,F203
803BE-210-252
4S300006
63 6301231310 FUSE HOLDER 3
803BE-210-253 4J200032
70 6300007749 BOL
T,HEX-SCT 2 M5X10 221A0029
71 411
1416705 WASHER SPR 5 2 SW5 221H0287
72 411
1414107 WASHER V 5X10X1 2 FW5 221H0318
73 411
1131400 SCR PAN 4X6 10 M4X6 PAN 221E0509
74 41
10423001 SCR PAN 4X10 1 M4X10 PAN 221E0500
75 41
11132407 SCR PAN 4X30 2 M4X30 PAN 221E0570
76 41
10081706 WASHER SPR 4 13 SW4 F 221H0283
77 411
1192104 WASHER V 4X9X0.8 11 FW4 F 221H0314
