MODEL GXH-1 0909-001 222 部品認識部 RECOGNITION SECTION Fig. D-3 照明ユニット Lighting Unit 283 282 . 281 . 201 251 276 255
MODEL GXH-1
1012-005
221
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
D-2
154 6301270715 BRACKET 1 803D--210-054 211F8385
155 6301270777 BRACKET 1 803D--210-055 211F8387
156 6301327174
BRACKET 1 803D--210-056 211F9178
157 6301318905
BRACKET 1 803D--210-057 211F9038
161 6301235752
P.C.B,MOUNT 6 -U08,-U09 803D--210-061 4B111452
171
4110407803 SCR PAN 3X12 8 M3X12 PAN 221E0489
172 41
11130700 SCR PAN 3X16 24 M3X16 PAN 221E0491
174 41
10030001 SCR PAN 4X12 16 M4X12 PAN 221E0501
176 41
10864408 WASHER SPR 3 8 SW3 F 221H0280
177 4110081706
WASHER SPR 4 16 SW4 F 221H0283
179 6301256962 RELA
Y 4 -K73,-K74 803D--210-179 4S200153
180 6300492088
SOCKET 4 803D--210-180 4J120084
181 6300001020 BRACKET
,WIRING 4 803D--210-181 23N10001
186 411
1191909 WASHER V 3X7X0.5 8 FW3 F 221H0311
187 41
11192104 WASHER V 4X9X0.8 16 FW4 F 221H0314
188 6300010213 W
ASHER 16 BW4 221H0004
MODEL GXH-1
0909-001
222
部品認識部
RECOGNITION SECTION
Fig. D-3
照明ユニット
Lighting Unit
283
282
.
281
.
201
251
276
255
MODEL GXH-1
1012-002
223
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
D-3
201 6301267579 ASSY,LIGHTING UNIT 4 -A67(A), -A67(C),
-A68(B), -A68(D)
803B--210-201
0Z110006
251 6301258980
MECH PARTS(RUBBER LEGS) 8 803FC-210-251 226J1897
255 6301258843 BRACKET 4
803FC-210-055 211F8248
276 41
10418908 SCR PAN 3X6 8 M3X6 PAN 221E0497
281 6300007756
BOLT,HEX-SCT 8 M5X12 221A0030
282 411
1416705 WASHER SPR 5 8 SW5 221H0289
283 411
1414107 WASHER V 5X10X1 8 FW5 221H0320
