MODEL GXH-1 0503-001 58 カッタ部 B,C CUTTER SECTION B,C Fig. DD-2 駆動部 Driving Section 126 169 164 . 154 . 104 131 1 1 1 132 1 18 1 13 1 16 142 143 129 133 107 124 1 16 143 142 129 133 129 144 134 123 169 164 . 154 . 169 164 …
MODEL GXH-1
1012-003
57
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
2Unit/1Machine
1 6301370385 COVER 1 803DD-210-001 211A9793
2 6301370392 COVER 1 803DD-210-002 211A9794
3 6301370453
COVER 1 803DD-210-003 211A9799
5 6301370514
COVER 1 803DD-210-005 211A9803
6 6301375731
COVER 1 803DD-210-006 211A9871
8 6301374253
COVER 1 803DD-210-008 211A9840
10 6301373522
GUIDE,LINEAR 1 803DD-210-210 222L0740
14 6301366852 PLA
TE 1 803DD-210-014 211DA551
15 6301370309
PLATE 1 803DD-210-015 211DA584
17 6301370378
PLATE 2 803DD-210-017 211DA586
20 6301370026
BRACKET 1 803DD-210-020 211F9724
21 6301365596
BRACKET 1 803DD-210-021 211F9662
22 6301380407
BRACKET 1 803DD-210-022 211F9818
25 6301372648
BRACKET 1 803DD-210-025 211F9758
26 6301380421
BRACKET 1 803DD-210-026 211F9820
27 6301376202
BLOCK 1 803DD-210-027 211G4116
28
6301376219 BLOCK 1 803DD-210-028 211G4117
30
6301359847 BLOCK 1 803DD-210-030 211G4012
31 6301260068
NAME PLATE,INDEX 1 803DD-210-231 6P460124
32 6301370217 BLOCK 2
803DD-210-032 211G4069
33 6301370224
BLOCK 2 803DD-210-033 211G4070
36 6301380384
BASE 1 803DD-210-056 210A2400
37 6301371917 FRAME 1
803DD-210-057 210B3900
42 6301372600 SUPPOR
T 1 803DD-210-072 211K3068
47 6301372723
BOLT,HEX-SCT 62 803DD-210-232 221A0346
49 6301366906 GUIDE 1
803DD-210-049 212A2219
52 6300007527 BOL
T,HEX-SCT 5 M3X10 221A0007
53 6300007619 BOL
T,HEX-SCT 8 M4X8 221A0016
54 6300007619 BOL
T,HEX-SCT 8 M4X8 221A0016
55 6300007725 BOL
T,HEX-SCT 8 M5X6 221A0027
56 6300007763 BOL
T,HEX-SCT 8 M5X16 221A0031
57 4110505004
SCR TRS 3X6 10 M3X6 TRS 221E0529
58 41
10511708 SCR TRS 4X6 6 M4X6 TRS 221E0532
59 41
11408007 SCR TRS 5X6 11 M5X6 TRS 221E0536
61
4111412806 WASHER SPR 3 5 SW3 221H0281
62 411
1412905 WASHER SPR 4 8 SW4 221H0284
63 411
1416705 WASHER SPR 5 12 SW5 221H0287
65 411
1413902 WASHER V 3X7X0.5 5 FW3 221H0312
66 411
1414008 WASHER V 4X9X0.8 8 FW4 221H0315
67 411
1414107 WASHER V 5X10X1 12 FW5 221H0318
DD-1
MODEL GXH-1
0503-001
58
カッタ部
B,C CUTTER SECTION B,C
Fig. DD-2
駆動部
Driving Section
126
169
164
.
154
.
104
131
111
132
1
18
113
116
142
143
129
133
107
124
1
16
143
142
129
133
129
144
134
123
169
164
.
154
.
169
164
.
154
.
156
167
162
.
151
.
156
153
158
169
164
.
154
.
166
161
155
153
158
158
159
136
171
137
140
137
171
140
138
166
161
155
167
162
.
151
.
158
1
10
171
153
See Fig.DD-1
Key No.37
156
126
126
126
129
144
171
127
128
141
168
163
.
152
.
131
158
MODEL GXH-1
1012-003
59
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
2Unit/1Machine
104 6301371962 COVER 1 803DD-210-004 211A9823
107 6301370408 COVER 1 803DD-210-007 211A9795
110
6301370422 COVER 1 803DD-210-210 211A9797
111
6301366265 PLATE 1 803DD-210-011 211DA545
113
6301356013 COLLAR 1 803DD-210-073 216A1254
116 6301370316
PLATE 2 803DD-210-016 211DA585
118
6301370354 BRACKET 1 803DD-210-018 211F9732
123 6301370040
BRACKET 1 803DD-210-023 211F9726
124 6301370057
BRACKET 1 803DD-210-024 211F9727
126 6300820423
BEARING,RADIAL 4 803DD-210-201 222D0316
127 6300011425
BEARING,RADIAL 1 803DD-210-202 222D0021
128 6300011432
BEARING,RADIAL 1 803DD-210-203 222D0022
129 6300068948 BEARING,RADIAL
8 803DD-210-204 222D0100
131 6301244402 PULLEY
,TIMING 1 803DD-210-211 223Q0551
132 6301244419
PULLEY,TIMING 1 803DD-210-212 223Q0552
133 6301244563 PULLEY
,TIMING 2 803DD-210-213 223Q0554
134 6301363059 PULLEY
,TIMING 1 803DD-210-214 223Q0594
135 6301363066 PULLEY
,TIMING 1 803DD-210-215 223Q0595
136 6301356594 BEL
T,TIMING 1 803DD-210-216 223L0286
137 6301354378 BEL
T,TIMING 2 803DD-210-217 223L0285
138 6301002729 MOT
OR,AC-SERVO 1 -M63 803DD-210-218 4M150130
140 6300937039
SENSOR,PROXIMITY 2 -B6301,-B6302
803DD-210-220 23G20046
141 6301364926 SHAFT
1 803DD-210-041 213A1199
142 6301365244
SHAFT 2 803DD-210-042 213A1202
143 6301365251 SHAFT
2 803DD-210-043 213A1203
144 6301370293 SHAFT
2 803DD-210-044 213A1210
151 6300007503 BOL
T,HEX-SCT 4 M3X6 221A0005
152 6300007626 BOL
T,HEX-SCT 2 M4X10 221A0017
153 6300007732 BOL
T,HEX-SCT 8 M5X8 221A0028
154 6300007732 BOL
T,HEX-SCT 8 M5X8 221A0028
155 411
1129001 SCR PAN 2X10 4 M2X10 PAN 221E0479
156 41
10505004 SCR TRS 3X6 10 M3X6 TRS 221E0497
158 6300082296
SET SCREW 10 M4X4 SET 221C0027
159 6300304701
SET SCREW 2 M4X10 SET 221C0044
161 41
11412509 WASHER SPR 2 4 SW2 F 221H0276
162 411
1412806 WASHER SPR 3 4 SW3 221H0281
163 411
1412905 WASHER SPR 4 2 SW4 221H0284
164 411
1416705 WASHER SPR 5 8 SW5 221H0287
166 411
1413605 WASHER V 2X5X0.3 4 FW2 F 221H0307
167 411
1413902 WASHER V 3X7X0.5 4 FW3 221H0312
168 411
1415906 WASHER F 4X8X0.8 2 FWS4 221H0340
169 411
1414107 WASHER V 5X10X1 8 FW5 221H0318
171 6300081985 RING 6
221K0007
DD-2
