MODEL GXH-1 0409-002 70 ヘッド部 HEAD SECTION Fig. M-3 ノズル選択部 Nozzle Selecter 231 226 See Fig.M-4 Key No.310 253 202 221 257 222 217 21 1 241 251 232 220 247 252 253 254 261 256 255 244 258 . 262 . 263

100%1 / 252
MODEL GXH-1
1012-003
69
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
M-2
4Unit/1Machine
103 6301778198 MOTOR,AC-SERVO 1 -M33 803M--210-003 4M150293
115 6301264783 BLOCK(BLOCK) 1 803M--210-115 211G3486
118
6301273426 BRACKET 1 803M--210-118 211F8434
125
6301250311 CAM FOLLOWER 1 803M--210-015 222H0133
127 6301273433 GUIDE,LINEAR(KR-UNIT) 1
803M--210-017 222L0703
133 6301250878 SENSOR,PHOT
O 3 -B3102,-B3104,-B3105
803M--210-033
23G10087
135 6301271682 BRACKET
1 803M--210-135 211F8403
139 6301272740
BRACKET 1 803M--210-139 211F8424
143 6301274621
BRACKET 1 803M--210-143 211F8450
145 6301250588
COUPLING 1 803M--210-025 223C0203
151 6300123791 BOL
T,HEX-SCT 4 M2.5X5 221A0150
152 6300007473 BOL
T,HEX-SCT 3 M2.5X8 221A0002
153 6300138924 BOL
T,HEX-SCT 2 M2.5X10 221A0154
154 6300007480 BOL
T,HEX-SCT 2 M2.5X12 221A0003
155 6300007503 BOL
T,HEX-SCT 5 M3X6 221A0005
156 6300007527 BOL
T,HEX-SCT 4 M3X10 221A0007
157 411
1409905 NUT HEX 3 1 M3 221F0079
161 411
1416606 WASHER SPR 2.5 6 SW2.5 221H0279
162 411
1412806 WASHER SPR 3 10 SW3 221H0281
166 411
1415708 WASHER F 2.5X5X0.5 4 FWS2.5 221H0336
167 411
1413803 WASHER V 2.5X6.5X0.5 2 FW2.5 221H0310
168 411
1413902 WASHER V 3X7X0.5 10 FW3 221H0312
MODEL GXH-1
0409-002
70
ヘッド部
HEAD SECTION
Fig. M-3
ノズル選択部
Nozzle Selecter
231
226
See Fig.M-4
Key No.310
253
202
221
257
222
217
211
241
251
232
220
247
252
253
254
261
256
255
244
258
.
262
.
263
MODEL GXH-1
1012-004
71
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
M-3
4Unit/1Machine
202 6301273624 MOTOR,AC-SERVO 1 -M32 803M--210-002 4M150203
211 6301273440 GUIDE,LINEAR 1 803M--210-011 222L0704
217 6301262703
SPRING,COMP(SPRING,COMP) 1 803M--210-127 222M1306
220 6301271590 PULLEY,TIMING 1
803M--210-020 223Q0563
221 6301275482 PULLEY
,TIMING 1 803M--210-021 223Q0565
222 6301250427 BEL
T,TIMING 1 803M--210-022 223L0269
226 6301250601 BEARING,RADIAL
1 803M--210-026 222D0395
231 6301273877 SEAL
2 803M--210-031 226A0190
232 6300805369 SENSOR,PHOT
O 1 -B3101 803M--210-032 23G10059
241 6301265155
ROD(ROD) 1 803M--210-111 216C0720
244
6301251325 BLOCK 1 803M--210-114 211G3396
247
6301271576 PLATE 1 803M--210-117 211D9619
251
6301297064 BOLT,HEX-SCT 2 803M--210-201 221A0332
252 6301251646 BOL
T,HEX 2 221B0114
253 6300007466
BOLT,HEX-SCT 2 M2X6 221A0001
254 6300876659 BOL
T,HEX-SCT 1 M2X10 221A0245
255 6301251615 BOL
T,HEX-SCT 1 803M--210-203 221A0321
256 6301251622 BOL
T,HEX-SCT 1 803M--210-204 221A0322
257 6300364132 SET
SCREW 2 803M--210-205 221C0049
258 411
1409608 NUT HEX 2.5 1 M2.5 221F0077
261 411
1412608 WASHER SPR 2 1 SW2 221H0277
262 411
1416606 WASHER SPR 2.5 1 SW2.5 221H0279
263 411
1413803 WASHER V 2.5X6.5X0.5 1 FW2.5 221H0310
