7 P -S183-02 1006-002 Key No. P AR T No. P AR T NAME Q’ty REMARKS New Code NOTE 126 6301404721 P ANEL 1→0 831BB-1 10-406 21 1C1222 151 6301500218 P ANEL 1 831BBA1 10010-A001 21 1C1283 152 41 10418908 SCR P AN 3X6 8 831BB…
6
P -S183-02
1006-002
158
157
See Fig.BB-1
Key No.47
156
155
154
153
.
152
.
151
制御盤
CONTROL BOARD
Fig. BB-2
ドライバ
Driver
7
P -S183-02
1006-002
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
126 6301404721 PANEL 1→0 831BB-110-406 211C1222
151 6301500218 PANEL 1
831BBA110010-A001
211C1283
152 4110418908 SCR PAN 3X6 8
831BBA110010-A002
221E0497
153 4110864408 WASHER SPR 3 8
831BBA110010-A003
221H0280
154 4111191909 WASHER V 3X7X0.5 8
831BBA110010-A004
221H0311
155 6301500331 ASSY,CORD 1
831BBA110010-A005
0W201391
156 6301500348 ASSY,CORD 1
831BBA110010-A006
0W201392
157 6300911831 NAME PLATE,INDEX 1
831BBA110010-A007
6P460089
158 6300911848 NAME PLATE,INDEX 1
831BBA110010-A008
6P460090
160 4110022600 SCR FLT 3X6 6→0 831BB-110-700 221D0216
190 6300911831 NAME PLATE,INDEX 1→0 831BB-110-770 6P460089
191 6300911848 NAME PLATE,INDEX 1→0 831BB-110-771 6P460090
BB-2
8
P -S183-02
1006-002
See Fig.BB-4
Key No.301
N03-CN2
N03-CN3
N03-CN1
X1032
X1033
G04-CN2
10A
24A3
N03
See Fig.BB-2
Key No.155
See Fig.BB-2
Key No.156
制御盤
CONTROL BOARD
Fig. BB-7 I/O
ケーブル
I/O Cable
