FFB-45E
Feeder Holder
LF4-1911
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1
KHY-M371R-00 RAIL GUIDE 12P 2 A
39 91312-05010 BOLT HEX,SOCKET HEAD 4
2
KHY-M372M-00 SCREW,STAD 90 /
Í
40 91312-05012 BOLT HEX,SOCKET HEAD 19
3
KHY-M372P-00 SUPPORT,LEVER 45 /
Í
41 91317-08035 BOLT HEX,SOCKET HEAD 4
4
KHY-M372R-00 GUIDE,FEEDER UNDER 3 A
Í
42 92902-10200 WASHER,PLAIN 4
5
KHY-M372S-01 SPRING,SUPPORT 45 /
Í
43 92907-08200 WASHER,PLAIN 4
6
KHY-M66TE-00 HNS,F.CTRL - FDR. 45 /
Í
44 98707-03006 SCREW,FLAT HEAD 38
7
KV8-M3758-00 SEAL DUMP 1 /
Í
45 98902-03005 SCREW BINDING HEAD 2
8
LE6-M13E2-00 SCREW,TORX 4 /
Í
46 98902-04006 SCREW BINDING HEAD 9
9
LE6-M3402-02 BLOCK,BASE 1 /
Í
47 98907-03005 SCREW BINDING HEAD 30
10
LE6-M3402-12 BLOCK,BASE 1 /
Í
48 98907-03006 SCREW BINDING HEAD 5
11
LE6-M34AD-00 SHIM,RING 4 /
Í
49 99480-05012 PIN,PARALLEL 3
12
LE6-M350A-00 SPACER 5 /
Í
50
13
LE6-M350B-01 COVER 1 /
Í
51
14
LE6-M350C-01 SUPPORT,R 1 /
Í
52
15
LE6-M350D-01 SUPPORT,L 1 /
Í
53
16
LE6-M350E-00 ANGLE 6 /
Í
54
17
LE6-M3553-00 BRACKET,R 1 /
Í
55
18
LE6-M3554-00 BRACKET,L 1 /
Í
56
19
LE6-M3556-00 BOLT 2 /
Í
57
20
LF1-M3521-00 BANK,FRAME 1 /
Í
58
21
LF1-M3602-00 PLATE, POSITIONING 1 /
Í
59
22
LF1-M3603-00 SHAFT, GUIDE 2 /
Í
60
23
LF1-M3604-00 COVER, BOARD 1 /
Í
61
24
LF1-M3605-00 COVER,COUPLER 1 /
Í
62
25
LF1-M3606-00 RAIL GUIDE 12P 1 A
63
26
LF1-M3607-00 RAIL GUIDE 9P 1 A
64
27
LF1-M3608-00 GUIDE,FEEDER UNDER 1 A
Í
65
28
LF1-M36D1-00 PLATE,NAME(45) 2 /
Í
66
29
LF1-M71H2-00 XIO.SSI BOARD ASSY 1 /
Í
67
30
LF3-M3658-00 GUIDE,TAPE 1 /
Í
68
31 LF3-M3659-00 BRACKET,GUIDE 2
/
Í
69
32 $UK4M JOINT 1 70
33 $UP4 JOINT 1 71
34 90115-10J050
BOLT, HEX. SOCKET HEAD
4 72
35 90990-46J015 BOLT,THIN HEAD 6 73
36 91312-03006 BOLT HEX,SOCKET HEAD 16 74
37 91312-03018
BOLT HEX,SOCKET HEAD
10 75
38 91312-04006 BOLT HEX,SOCKET HEAD 15 76
3
2
FFB-45E
Feeder Holder
