LF4-191 1 Rev . :It had a change without the compatibility . Please be careful at the time of the parts ordering. Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。 No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. P…
LF4-1911
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1 LE6-M5F11-02 HOLDER,SHRINGE 3 E
39
2 LE6-M5F11-10 HOLDER,SYRINGE 1 E
40
3 LE6-M5F12-00 PLUG 4 E
41
4 LE6-M5F15-04 ADAPTER 4 E
42
5 LE6-M5F2A-02 TUBE 4 E
43
6 LE6-M5F2G-00 MAGNET 4 E
44
7 LE6-M5F2K-10 MAGNET ASSY.(30 I/E) 1 E
45
8 LE6-M5F2K-20 MAGNET ASSY.(30 M/E) 1 E
46
9 LE6-M5F2K-30 MAGNET ASSY.(30 SO.) 1 E
47
10 LE6-M5F2K-40 MAGNET ASSY.(30 EFD) 1 E
48
11 LE6-M5F2P-00 TAPE, MAGNET 1 E
49
12 LE6-M5F5L-03 CLAMP,TUBE 4 E
50
13 LE6-M5F5M-01 PLATE 4 E
51
14 LE6-M5FB0-01 SYRINGE COMMON ASSY 4 E
52
15 LE6-M5FF7-10 SET,SCREW 4 E
53
16 LF3-M5F20-10 SYRINGE UNIT(30 I/E) 1 E
54
17 LF3-M5F20-20 SYRINGE UNIT(30 M/E) 1 E
55
18 LF3-M5F20-30 SYRINGE UNIT(30 SO.) 1 E
56
19 LF3-M5F20-40 SYRINGE UNIT(30 EFD) 1 E
57
20 LF3-M5F5A-00 BLOCK,JOINT 4 E
58
21 LF3-M5FD0-00 JOINT ASSY(COMMON) 4 E
59
22 LG7-M71AK-20 O-RING (SO10) 2 E
60
23 LG7-M71AR-30 O-RING 4 E
61
24 LG9-M715M-00 BASE,MAGNET 1 E
62
25 LG9-M715M-50 BASE,MAGNET 1 E
63
26 LG9-M715M-71 BASE,MAGNET 1 E
64
27 LG9-M715N-00 BASE,MAGNET 1 E
65
28 LG9-M71AK-70 O-RING(SO) 1 E
66
29 LG9-M71AT-50 O-RING (SO16) 2 E
67
30 91312-03006 BOLT HEX,SOCKET HEAD 4 E
68
31 91312-03008 BOLT HEX,SOCKET HEAD 4 E
69
32 70
33 71
34 72
35 73
36 74
37 75
38 76
5
6
Syringe Unit
Head
