0003-002 8-2 ㇱຠ⇟ภ ㇱ ຠ ฬ ⠨ PART No. PART NAME REMARKS CT-5650L,PL-12 CT-5650L,PL-16 CT-5650L,PL-20 CT-5650L,PL-24 CT-5650L,PL-28 CT-5650L,PL-32 CT-5650L,PL-36 CT-5650HL-12 CT-5650HL-16 CT-5650HL-20 CT-5650HL-24 CT-5650H…
0003-002
8-2
ㇱຠ⇟ภ ㇱ ຠ ฬ ⠨
PART No. PART NAME REMARKS
CT-5650L,PL-12
CT-5650L,PL-16
CT-5650L,PL-20
CT-5650L,PL-24
CT-5650L,PL-28
CT-5650L,PL-32
CT-5650L,PL-36
CT-5650HL-12
CT-5650HL-16
CT-5650HL-20
CT-5650HL-24
CT-5650HL-28
CT-5650HL-32
CT-5650HL-36
66 630 039 3224 PIN,GUIDE 11111111111111 582T--01B-052
67 411 141 4008 WASHER V 4X9X0.8 11111111111111 FW4
68 411 141 2905 WASHER SPR 4 11111111111111 SW4
69 630 000 7640 BOLT,HEX-SCT 11111111111111 M4X14
70 630 044 1154 COLLAR 11111111111111 582T--01B-044
71 630 050 7911 LEVER(ASSY SWING ARM) 11111111111111
71 -1 630 051 8252 PIN,GUIDE 11111111111111 582T--01B-130
71 -2 411 141 4107 WASHER V 5X10X1 11111111111111 FW5
71 -3 411 141 6705 WASHER SPR 5 11111111111111 SW5
71 -4 411 141 0604 NUT HEX 5 11111111111111 M5-3
72 630 041 7586 PIN,LOCATE 11111111111111 582T--01B-015
73 411 141 3902 WASHER V 3X7X0.5 11111111111111 FW3
74 411 141 2806 WASHER SPR 3 11111111111111 SW3
75 630 000 7510 BOLT,HEX-SCT 11111111111111 M3X8
76 411 141 3902 WASHER V 3X7X0.5 11111111111111 FW3
77 411 141 2806 WASHER SPR 3 11111111111111 SW3
78 630 041 4714 PIN,LOCATE 11111111111111 582T--01B-011
80 630 039 4498 COLLAR 11111111111111 582T--01B-087
81 630 050 7959 LEVER(ASSY LEVER) 11111111111111
81 -1 630 007 1641 BEARING,RADIAL 11111111111111 582T--01H-016
82 630 041 7616 PIN,LOCATE 11111111111111 582T--01B-088
83 411 141 3902 WASHER V 3X7X0.5 11111111111111 FW3
84 411 141 2806 WASHER SPR 3 11111111111111 SW3
85 630 000 7510 BOLT,HEX-SCT 11111111111111 M3X8
91 630 050 7935 LEVER(ASSY RATCHET ARM) 11111111111111
92 630 057 2926 PIN,LOCATE 11111111111111 582T--01B-048
93 411 141 3902 WASHER V 3X7X0.5 11111111111111 FW3
94 411 141 2806 WASHER SPR 3 11111111111111 SW3
95 630 000 7534 BOLT,HEX-SCT 11111111111111 M3X12
96 411 141 3902 WASHER V 3X7X0.5 11111111111111 FW3
97 411 141 2806 WASHER SPR 3 11111111111111 SW3
ᢙ㊂
Q'ty
ᵈᗧ
NOTE
⇟
ภ
Key No.
0003-002
8-2
ㇱຠ⇟ภ ㇱ ຠ ฬ ⠨
PART No. PART NAME REMARKS
CT-5650L,PL-12
CT-5650L,PL-16
CT-5650L,PL-20
CT-5650L,PL-24
CT-5650L,PL-28
CT-5650L,PL-32
CT-5650L,PL-36
CT-5650HL-12
CT-5650HL-16
CT-5650HL-20
CT-5650HL-24
CT-5650HL-28
CT-5650HL-32
CT-5650HL-36
98 630 041 4714 PIN,LOCATE 11111111111111 582T--01B-011
99 630 000 7503 BOLT,HEX-SCT 11111111111111 M3X6
101 630 039 3019 LEVER(RATCHET CLICK) 22222222222222 582T--01B-016
102 630 010 6114 SPRING,TORSION 22222222222222 582T--01B-054
103 630 037 9327 PIN,LOCATE 11111111111111 582T--01B-053
104 411 141 0109 NUT HEX 3 11111111111111 M3-3
105 411 054 8506 NUT HEX 4 11111111111111 M4 F
106 411 113 2308 SCR PAN 4X25 11111111111111 M4X25 PAN
107 630 043 9205 SPRING,TENSION 11111111111111 582T--01B-055
108 630 041 2635 SPRING,TENSION 1111 1111 582UT-01R-003
108 630 041 8705 SPRING,TENSION 1 1 1 1 1 1 582UT-08R-003
111 630 039 3132 DISK(REEL DEVICE) 11111111111111 582T--01B-042
111 -1 630 041 7623 SPACER 11111111111111 582T--01B-081
111-2 630 057 2971 COLLAR 11111111111111 582T--01B-108
111 -3 630 037 2519 BOLT(BIND TAPPING) 44444444444444 582T--01H-013
111 -4 411 141 3704 WASHER V 2.5X6.5X0.5 44444444444444 FW2.5 F
111 -5 411 141 2707 WSHER SPR 2.5 44444444444444 SW2.5 F
111 -6 411 147 6105 SCR PAN 2.5X10 44444444444444 M2.5X10 PAN
112 630 010 6046 PIN,LOCATE 11111111111111 582T--01B-050
113 630 036 0967 BOLT(FLT HEX-SCT) 11111111111111 582T--01H-004
114 630 065 4455 DISK(REEL SOKET) 11111111111111 582T--01B-109
114-1 630 057 3008 COLLAR 11111111111111 582T--01B-082
114 -2 411 141 3704 WASHER V 2.5X6.5X0.5 44444444444444 FW2.5 F
114 -3 411 141 2707 WASHER SPR 2.5 44444444444444 SW2.5 F
114 -4 411 140 6201 SCR PAN 2.5X6 44444444444444 M2.5X6 PAN
115 630 039 3309 SPRING,FLAT 11111111111111 582T--01B-068
116 630 037 3042 MACHINE SCREW 22222222222222 582T--01H-006
ᢙ㊂
Q'ty
ᵈᗧ
NOTE
⇟
ภ
Key No.
