0003-003 4-2 ㇱຠ⇟ภ ㇱ ຠ ฬ ⠨ PART No. PART NAME REMARKS CT-2460L-08,12,16 CT-2461L-20,24 CT-2480L,PL-08,12,16 CT-2481L,PL-20,24 CT-2460TL-08,12,16 CT-2461TL-20,24 CT-2480TL,HL-08,12,16 CT-2481TL,HL-20,24 72 -2 630 067 553…
0003-003
4-2
ㇱຠ⇟ภ ㇱ ຠ ฬ ⠨
PART No. PART NAME REMARKS
CT-2460L-08,12,16
CT-2461L-20,24
CT-2480L,PL-08,12,16
CT-2481L,PL-20,24
CT-2460TL-08,12,16
CT-2461TL-20,24
CT-2480TL,HL-08,12,16
CT-2481TL,HL-20,24
39 411 141 2905 WASHER SPR 4 1 1 1 1 1 1 1 1 SW4
40 411 141 0307 NUT HEX 4 1 1 1 1 1 1 1 1 M4
41 630 039 4788 CHUTE 1 1 1 1 1 1 1 1 671P--01B-093
44 -1 411 119 1909 WASHER V 3X7X0.5 3 3 3 3 3 3 3 3 FW3 F
44 -2 411 086 4408 WASHER SPR 3 3 3 3 3 3 3 3 3 SW3 F
44 -3 411 162 1604 SCR PAN 3X20 3 3 3 3 3 3 3 3 M3X20 PAN
47 630 076 5168 LEVER 1 1 1 1 1 1 1 1 671P--01B-031
48 630 040 6986 SPRING,TORSION 1 1 1 1 1 1 1 1 671P--01B-057
49 630 039 4153 HOOK 1 1 1 1 1 1 1 1 671P--01B-032
50 411 152 8101 SCR TRS 3X6 1 1 1 1 1 1 1 1 671P--01H-007
51 630 041 1126 PIN,LOCATE 1 1 1 1 1 1 1 1 671P--01B-037
52 411 108 7103 SCR FLT 3X10 1 1 1 1 1 1 1 1 M3X10 FLT
56 630 050 7287 HOOK(ASSY HOOK) 1 1 1 1 1 1 1 1
57 411 141 3902 WASHER V 3X7X0.5 2 2 2 2 2 2 2 2 FW3
58 411 141 2806 WASHER SPR 3 2 2 2 2 2 2 2 2 SW3
59 630 000 7503 BOLT,HEX-SCT 2 2 2 2 2 2 2 2 M3X6
63 411 119 1909 WASHER V 3X7X0.5 1 1 1 1 1 1 1 1 FW3 F
64 411 086 4408 WASHER SPR 3 1 1 1 1 1 1 1 1 SW3 F
65 630 039 4757 PIN,GUIDE 1 1 1 1 1 1 1 1 671P--01B-086
66 630 039 3224 PIN,GUIDE 1 1 1 1 1 1 1 1 671P--01B-052
67 411 141 4008 WASHER V 4X9X0.8 1 1 1 1 1 1 1 1 FW4
68 411 141 2905 WASHER SPR 4 1 1 1 1 1 1 1 1 SW4
69 630 000 7602 BOLT,HEX-SCT 1 1 1 1 1 1 1 1 M4X6
71
630 077 6973 LEVER(SWING ARM ASSY) 1 1
71
630 077 6980 LEVER(SWING ARM ASSY) 1 1
71
630 061 2622 LEVER(SWING ARM ASSY) 1 1
71
630 062 6056 LEVER(SWING ARM ASSY) 1 1
71 -1
630 067 2701 ROLLAR 1 1 1 1 1 1 1 1 671P--01B-119
71 -2 411 000 9304 RING E 2 1 1 1 1 1 1 1 1 671P--01H-011
72 630 067 5528 PIN,LOCATE 1 1 1 1 1 1 1 1 671P--01B-015
72 -1 630 066 2276 ROLLER 1 1 1 1 1 1 1 1 671P--01B-121
ᵈᗧ
NOTE
ᢙ㊂
Q'ty
⇟
ภ
Key No.
0003-003
4-2
ㇱຠ⇟ภ ㇱ ຠ ฬ ⠨
PART No. PART NAME REMARKS
CT-2460L-08,12,16
CT-2461L-20,24
CT-2480L,PL-08,12,16
CT-2481L,PL-20,24
CT-2460TL-08,12,16
CT-2461TL-20,24
CT-2480TL,HL-08,12,16
CT-2481TL,HL-20,24
72 -2 630 067 5535 PIN,GUIDE 11111111 671P--01B-120
73 411 113 5408 SCR FLT 4X20 11111111 M4X20 FLT
76 411 141 3902 WASHER V 3X7X0.5 11111111 FW3
77 411 141 2806 WASHER SPR 3 11111111 SW3
78 630 041 4714 PIN,LOCATE 11111111 671P--01B-011
80 630 039 4498 COLLAR 11111111 671P--01B-087
81 630 050 7256 LEVER(ASSY LEVER) 1111
81 630 050 7416 LEVER(ASSY LEVER) 1111
81 -1 630 007 1641 BEARING,RADIAL 11111111 671P--01H-016
82 630 039 4504 PIN,LOCATE 11111111 671P--01B-088
83 411 144 3107 SCR FLT 3X5 11111111 671P--01H-014
91 630 061 2608 LEVER(RATCHET ARM ASSY) 11111111
92 630 039 4566 BUSH,LOCATE 11111111 671P--01B-048
93 411 002 2600 SCR FLT 3X6 11111111 M3X6 FLT
96 411 141 3902 WASHER V 3X7X0.5 11111111 FW3
97 411 141 2806 WASHER SPR 3 11111111 SW3
98 630 041 4714 PIN,LOCATE 11111111 671P--01B-011
101 630 039 3019 LEVER(RATCHET CLICK) 22222222 671P--01B-016
102 630 054 3650 SPRING,TORSION 22222222 671P--01B-054
103 630 037 9327 PIN,LOCATE 11111111 671P--01B-053
103 -1
630 060 3590 PIN,LOCATE 11111111 671P--01B-111
104
411 141 0109 NUT HEX 3 11111111 M3-3
105
411 054 6809 NUT HEX 3 11111111 M3 F
106
411 162 1604 SCR PAN 3X20 11111111 M3X20 PAN
107
630 039 5310 SPRING,TENSION 11111111 671P--01B-055
108 630 041 2635 SPRING,TENSION 1111 671P--01B-056
108 630 041 8705 SPRING,TENSION 1111 671K--01B-056
ᵈᗧ
NOTE
ᢙ㊂
Q'ty
⇟
ภ
Key No.
0108-003
4-2
ㇱຠ⇟ภ ㇱ ຠ ฬ ⠨
PART No. PART NAME REMARKS
CT-2460L-08,12,16
CT-2461L-20,24
CT-2480L,PL-08,12,16
CT-2481L,PL-20,24
CT-2460TL-08,12,16
CT-2461TL-20,24
CT-2480TL,HL-08,12,16
CT-2481TL,HL-20,24
111 630 039 3132 DISK(REEL DRIVE) 11111111 671P--01B-042
111 -1 630 039 4733 SPACER 11111111 671P--01B-081
111 -2 630 037 2519 BOLT(BIND TAPPING) 44444444 671P--01H-013
112 630 010 6046 PIN,LOCATE 11111111 671P--01B-050
113 411 002 2600 SCR FLT 3X6 11111111 M3X6 FLT
114 630 098 4477 ASSY,DISK 11111111
114 -1 630 050 7294 DISK(ASSY REEL SOCKET) 11111111
114 -2 630 039 3309 SPRING,FLAT 11111111 671P--01B-068
114 -3 630 037 3042 MACHINE SCREW 22222222 671P--01H-006
ᵈᗧ
NOTE
ᢙ㊂
Q'ty
⇟
ภ
Key No.
