0003-002 6-1 ㇱຠ⇟ภ ㇱ ຠ ฬ ஻ ⠨ PART No. PART NAME REM ARK S CT-3251L CT-3252L CT-3251TL CT-3252TL CT-3253L CT-3283L,PL CT-3283HL 39 411 041 8908 SCR PAN 3X6 2 2 2 2 2 2 2 M 3X6 PA N ᢙ㊂ Q' ty ᵈᗧ NOTE ⷗಴⇟ ภ Key No.

0108-007

6-1

ㇱຠ⇟ภ ㇱ ຠ ฬ ஻ ⠨

PART No. PART NAME REMARKS

CT-3251L

CT-3252L

CT-3251TL

CT-3252TL

CT-3253L

CT-3283L,PL

CT-3283HL

1 630 046 3217 FRAME(CASSETTE BODY) 1 1 1 1 1 582R--02B-001

1 630 046 3224 FRAME(CASSETTE BODY) 1 1 582S--01B-001

2 630 037 0294 PIN,LOCATE 1111111 582R--02H-004

4 630 039 3002 PLATE 2222222 582R--02B-070

5 630 039 3200 PIN,LOCATE 1111111 582R--02B-072

6 630 039 3187 PIN,LOCATE 1111111 582R--02B-071

7 411 141 4008 WASHER V 4X9X0.8 2222222 FW4

8 411 141 2905 WASHER SPR 4 2222222 SW4

9 411 141 0307 NUT HEX 4 2222222 M4

11 630 039 2838 BRACKET 1 1 1 582R--02B-003

11 630 054 4800 BRACKET 1 725N--01B-003

12 630 070 7601 BRACKET(GRIP) 1 1 1 1 582R--02B-004

13 411 054 8506 NUT HEX 4 2 2 2 1 M4 F

14 411 113 4708 SCR FLT 4X10 2 2 2 1 582R--01H-011

15 630 037 6616 BOLT(FLT HEX-SCT) 3 3 3 2 582R--01H-008

15 -1 411 113 5309 SCR FLT 4X16 1 1 1 M4X16 FLT

16 630 039 7086 TUBE,WIRING 1 1 1 582R--01H-003

16 630 039 7062 TUBE,WIRING 1 582S--01H-003

18 630 010 8248 PIN,LOCATE 1111111 582R--02B-005

19 630 039 3125 LEVER(LOCATE) 1111111 582R--02B-041

20 411 141 4701 WASHER V 10X21X2 1111111 FW10

21 411 000 7102 RING C 10 1111111 582R--01H-010

22 411 141 4503 WASHER V 8X17X1.6 1111111 FW8

23 411 141 3100 WASHER SPR 8 1111111 SW8

24 411 141 1007 NUT HEX 8 1111111 M8-3

25 630 010 5957 SPRING,COMP 1111111 582R--02B-076

26 630 039 3217 PLATE 1111111 582R--02B-051

28 411 141 2905 WASHER SPR 4 1111111 SW4

29 630 000 7602 BOLT,HEX-SCT 1111111 M4X6

36 630 010 6176 PLATE 2222222 582R--02B-051

38 411 086 4408 WASHER SPR 3 2222222 SW3 F

BLUE

RED

ᢙ㊂

Q'ty

ᵈᗧ

NOTE

⷗಴⇟

ภ

Key No.

0003-002

6-1
