Station Software 605.04 / Version Description Ausgabe 04/2015 Edition
11
Productivity lift
PCB width restricted to 216 mm with a
dual conveyor and to 460 mm with a
single conveyor.
Maximum permitted component height,
13 mm.
Cannot be used in combination with an
MTC2 at location 4 of an X2.
WDTL is not possible.
Vacuum tool
The station software offers no
possibility to configure the type of the
vacuum tool.
Table 4-1: Supported hardware options
Station Software 605.04 / Version Description Ausgabe 04/2015 Edition
12
5 SITEST
SITEST Version 605.xx incorporates all the functions for testing and setting the components of the
X- and D-series machines.
NOTICE
For a detailed description of the functions of SITEST, please refer to the online help
system for SITEST.
The following changes have been made in SITEST for software version 605:
– You can set-up the conveyor widths to ensure the compatibility to the SIPLACE X4i machines.
– As a service engineer you can set the position of the fixed conveyor side user-defined in the
Options and Configurations menu. The settings apply to the conveyor, not for the track.
– In the Options – Nozzle scan options menu you can configure the nozzle scan concerning
the closeness of the nozzle scan and the behavior of the machine in case of defects.
– Second row nozzle changer supported for D4 machines (also valid for D4i machines).
Station Software 605.04 / Version Description Ausgabe 04/2015 Edition
13
6 Service Tools
6.1 Automatic Error Report (Bug Report)
The "BugReporter" tool is used to automatically save all the data required for debugging in an error
report (bug report) each time the station is shut down. The "BugReporter" tool must be activated to
do this.
Activating the "BugReporter" tool:
► Double-click the BugReporter_Autrun_ON.reg file in the folder C:\WinBO folder.
► Then confirm the two dialog boxes which appear by clicking OK.
Deactivating the "BugReporter" tool:
► Double-click the BugReporter_Autrun_OFF.reg filed in the folder C:\WinBO folder.
► Then confirm the two dialog boxes which appear by clicking OK.
After the "BugReporter" tool has been activated, the "BugReporter" tool dialog box appears
automatically each time that the station is shut down. It is not possible to make any entries. The
fields are completed automatically.
The current error report is stored under C:\BugReport\Latest. Previous error reports are stored
under C:\BugReport\Archive. Since the Latest and Archive folders also contain the error reports
created manually by pressing ALT + CTRL + F10, the automatically generated error reports are
indicated by AutoLog_xxxxxxxxxx_x.zip in the file name. An error report can comprise several
files. If this is the case, the number in the file name is incremented automatically (e.g.
AutoLog_xxxxxxxxxx_2.zip).
6.1.1 Restrictions
When the "BugReporter" is activated, it may take up to 3 minutes longer to shut down the station.
