Station Software 605.04 / Version Description Ausgabe 04/2015 Edition
20
Modules
– Component reject conveyor (SIPLACE)
– Component reject conveyor (Component Express)
– Dip module
– Dip module for X tables (LDU_X)
Tray feeders
– MTC 2
– WPC 4
– Carrier 31 (manual waffle pack tray carrier)
– Carrier 51 (manual waffle pack tray carrier)
– Arbitrary Tray Feeder
FFI-feeders
– DDF 2
– Tray Stack
– RoadRunner (DataIO)
X-series feeders
– 8 mm X-feeder
– 2x8 mm X-feeder
– 12 mm X-feeder
– 16 mm X-feeder
– 24 mm X-feeder
– 32 mm X-feeder
– 44 mm X-feeder
– 56 mm X-feeder
– 72 mm X-feeder
– 88 mm X-feeder
– Linear feeders with X feeder adapters
– Label feeders with X feeder adapters
Station Software 605.04 / Version Description Ausgabe 04/2015 Edition
21
7.2 Digital Camera Systems
Digital CCD cameras are used as the camera systems.
7.2.1 Component Cameras
All heads are equipped with the standard cameras listed below. High-resolution cameras are
additionally available for the Twin Head, the P&P module and the 12-segment C&P head.
Component
camera
Camera
type
6-seg.
C&P head
12-seg
C&P head
C&P20
head
Twin
Head
P&P
module
C&P
6 x 6 digital
23
- -
(Default) -
-
C&P
18 x 18 digital
28
-
(Default) - -
-
C&P
27 x 27 digital
29
(optional)
(optional) - -
-
C&P
27 x 27 digital
30
(Default)
(optional) - -
-
C&P
16 x 16 digital
38
-
(optional) - -
-
Stat. P&P
55 x 45 digital
33
- - - (Default)
(optional)
Stat. P&P
16 x 16 digital
25
- - - (optional)
(optional)
Stat. P&P
32 x 32 digital
36
- - - -
(Default)
Table 7-1: Component cameras
7.2.2 PCB Cameras
PCB camera Camera type X-series D-series
28 digital 34
(Default)
(Default)
Multicolor 28 digital 24
(optional) -
Table 7-2: PCB cameras
Station Software 605.04 / Version Description Ausgabe 04/2015 Edition
22
7.3 Component Range
Component range for C&P20 head With standard type 23 component
camera
(C&P 6 x 6 digital)
01005 through 2220, Melf, SOT,
SOD
Component specification
max. Höhe ax height 4 mm
Min. lead pitch 0.25 mm
Min. ball pitch 0.4 mm
Min. ball diameter 0.2 mm
Min. dimensions 0.18 x 0.18 mm
Max. dimensions 6 x 6 mm (including component
tolerances)
Max. weight 1 g
Programmable placement force,
selectable level
1.5 ± 0.5 N
2.0 ± 0.5 N
3.5 ± 1 N
4.5 ± 1 N
Nozzle types 10 xx, 11 xx, 12 xx
Table 7-3: Component range for C&P20 head
