Station Software 605.04 / Version Description Ausgabe 04/2015 Edition
24
Component range for
Twin Head
With type 33 component camera
(Stat. P&P 55 x 45 digital)
With type 25 component camera
(Stat. P&P 16 x 16 digital)
0603 through SO, PLCC, QFP,
BGA, special components, bare
die, flip-chip
0201 through SO, PLCC, QFP,
sockets, connectors, BGA, special
components, bare die, flip-chip,
shield
Component specification
Max height 25 mm (higher on request) 25 mm (higher on request)
Min. lead pitch 0.3 mm 0.25 mm
Min. ball pitch 0.35 mm 0.14 mm
Min. ball diameter 0.2 mm 0.08 mm
Min. dimensions 0.5 x 0.5 mm 0.2 x 0.2 mm
Max. dimensions 55 x 45 mm (single measurement) 16 x 16 mm (single measurement)
When used with two nozzles
50 x 50 mm or 69 x 10 mm²
When used with one nozzle:
85 x 85 mm or 125 x 10 mm²
max. 200 x 125 mm (with
restrictions)
Max. weight 100 g
*)
100 g
*)
Programmable placement
force
1.0 N - 15 N
1.0 N - 30 N
**)
1.0 N - 15 N
1.0 N - 30 N
**)
Nozzle types 5 xx (standard)
4 xx + adapter
8 xx + adapter
9 xx + adapter
5 xx (standard)
4 xx + adapter
8 xx + adapter
9 xx + adapter
Distance between nozzles
on the two segments
70.80 mm 70.80 mm
Table 7-6: Component range for Twin Head
*)
If standard nozzles are used
**)
Valid for HFTH only
NOTICE for the 904 nozzle type:
For the 904 nozzle type the vacuum threshold value has been increased from 20% to
40%. For components drawing
more leak air due to their surface shapes, this may cause
a higher amount of error messages.
As workaround, it is possible to create a special nozzle in SIPLACE Pro, based on the
nozzle type 904, in which you enter lower vacuum values.
Station Software 605.04 / Version Description Ausgabe 04/2015 Edition
25
Component range
for P&P head
With type 36 component
camera
(Stat. P&P 32 x 32
digital)
With type 25 component
camera
(Stat. P&P 16 x 16
digital)
With type 33 component
camera
(Stat. P&P 55 x 45 digital)
0603 through SO, PLCC,
QFP, BGA, special
components, bare die,
flip-chip
0201 through SO, PLCC,
QFP, sockets,
connectors, BGA, special
components, bare die,
flip-chip, shield
0603 through SO, PLCC,
QFP, BGA, special
components, bare die, flip-
chip
Component
specification
Max height 18.80 mm 18.80 mm 18.80 mm
Min. lead pitch r 0.4 mm 0.25 mm 0.3 mm
Min. ball pitch 0.56 mm 0.14 mm 0.35 mm
Min. ball diameter 0.32 mm 0.08 mm 0.2 mm
Min. dimensions 0.8 x 0.,8 mm 0.2 x 0.2 mm 0.5 x 0.5 mm
Max. dimensions 32 x 32 mm (single
measurement)
16 x 16 mm (single
measurement)
55 x 45 mm (single
measurement)
85 x 85 mm or 125 x 10 mm
max. 200 x 125 mm (single
measurement)
Max. weight 100 g
*)
100 g
*)
100 g
*)
Programmable
placement force
1.0 N - 15 N 1.0 N - 15 N 1.0 N - 15 N
Nozzle typ 5 xx (standard)
4 xx + adapter
8 xx + adapter
9 xx + adapter
5 xx (standard)
4 xx + adapter
8 xx + adapter
9 xx + adapter
5 xx (standard)
4 xx + adapter
8 xx + adapter
9 xx + adapter
Table 7-7: Component range for P&P head
*)
If standard nozzles are used
Station Software 605.04 / Version Description Ausgabe 04/2015 Edition
26
8 SIPLACE Software Environment
8.1 SIPLACE Pro Programming System Version 11.2
The 11.2 software version of the SIPLACE Pro programming system supports SIPLACE machines
with station software version 605.
NOTICE
For a detailed description of the programming system, see the SIPLACE Pro version
description and the online help.
8.2 SIPLACE Operator Information System OIS Version 11.2
The 11.2 software version of the SIPLACE OIS monitoring system supports all machine types of
the X- and D-series.
NOTICE
A detailed description can be found in "Getting started with OIS" and the online help for
OIS.
8.3 SIPLACE Setup Center Version 6.3
The 6.3 software version of SIPLACE Setup Center supports all machine types of the X- and
D-series.
NOTICE
A detailed description can be found in the software description "Getting started with
Setup Center" and the online help for Setup Center.
8.4 SIPLACE Traceability Version 3.6 SP1
The 3.6 SP1 software version of SIPLACE Traceability supports all machine types of the X- and
D-series.
NOTICE
A detailed description can be found in the “Traceability User Guide".
