8 SIPLACE Software Environment
8.1 SIPLACE Pro Programming System Version 11.2
The 11.2 software version of the SIPLACE Pro programming system supports SIPLACE machines
with station software version 605.
NOTICE
For a detailed description of the programming system, see the SIPLACE Pro version
description and the online help.
8.2 SIPLACE Operator Information System OIS Version 11.2
The 11.2 software version of the SIPLACE OIS monitoring system supports all machine types of
the X- and D-series.
NOTICE
A detailed description can be found in "Getting started with OIS" and the online help for
OIS.
8.3 SIPLACE Setup Center Version 6.3
The 6.3 software version of SIPLACE Setup Center supports all machine types of the X- and
D-series.
NOTICE
A detailed description can be found in the software description "Getting started with
Setup Center" and the online help for Setup Center.
8.4 SIPLACE Traceability Version 3.6 SP1
The 3.6 SP1 software version of SIPLACE Traceability supports all machine types of the X- and
D-series.
NOTICE
A detailed description can be found in the “Traceability User Guide".
Station Software 605.04 / Version Description Ausgabe 04/2015 Edition
27
9 Restrictions
SIPLACE CA-series
The SIPLACE CA-series placement machines (SIPLACE CA3 and SIPLACE CA4) are not
supported by this station software version.
NOTICE
The SIPLACE X-series placement machines are still supported by this station software
version, but the support will be discontinued in future versions.
C&P20 head
– Can only be used in conjunction with X-feeders.
– Can only be used in conjunction with a second C&P20 head in placement areas with 2
gantries.
X-Feeders
– Are only available for tapes between 8 mm and 88 mm and can only be set up on X-series
component changeover tables.
X-Feeder adapters
– X-feeder adapters can only be used on component changeover tables of the X-series.
– The station software does not check the compatibility of the X feeder adapter with the current
head configuration. This check is carried out by SIPLACE Pro or by the operator.
– Splice sensors are not supported by the X-feeder adapter.
Bulk case feeders and surf tape feeders
– Cannot be set up on X-tables of the X-series and are thus not available for the C&P20 head.
Dip modules
– Cannot be set up on X-tables of the X-series and are thus not available for the C&P20 head.
FFI feeders
– Cannot be set up on X-tables of the X-series.
2D barcode reader
– The barcode for components cannot exceed 50 characters.
Station Software 605.04 / Version Description Ausgabe 04/2015 Edition
28
Whispering down the line (WDTL)
– Whispering is not supported for fiducial measurement of PCB sub panels.
– Whispering in mixed lines (with 40x, 50x, 60x) is not supported.
– Whispering of ink spots is not possible if the "Recovery placement" option is activated.
– Stations where both processing areas are set to "Transport through" interrupt the whispering of
ink spots.
– If station-wise download is used, "WDTL" must be specified for all jobs if you wish to whisper
the ink spots.
– WDTL is not possible in combination with the conveyor type "synchronous dual conveyor".
– WDTL is not possible in lines equipped with a productivity lift.
Manual tray
– If tray 51 is used on the permitted locations, the nozzle changer must be removed. (however,
the Jedec tray can be used without removing the nozzle changer).
Coplanarity sensor with 3D coplanarity sensor
– The coplanarity module only works in conjunction with the standard stationary component
camera for the Twin Head (type 33).
– Mixed operation between the type 37 (3D) and type 17 (2D) coplanarity sensors is not
supported.
– The coplanarity module can only be configured on location 3 of a SIPLACE X2 and X3 machine
with Twin Head.
– The optional Vision computer is required to operate the coplanarity module with the 3D
coplanarity sensor.
Dipping and coplanarity measurement
– For the component types with leads, the coplanarity measurement is only supported for those
with the lead type "Gullwing". The Gullwing leads must not have any notches.
– The component to be measured must have at least 5 connections.
– The maximum height for components to be measured is 17 mm.
– High-reflection leads can impact negatively on measurement
– Components which have both balls and leads cannot be measured.
– Coplanarity measurement is not possible in conjunction with dipping.
– Coplanarity measurement is not carried out at the placement angle. The component is
presented to the coplanarity laser at 0°.
– If "inching" (key switch) is enabled, it is not possible to guarantee that a 3D measurement will
be completed successfully, as the specified scan speed is not maintained.
– Coplanarity measurement impairs placement performance.
– The machine cannot measure components for which both dipping and coplanarity
measurement have been defined.
– The Twin Head cannot dip one component and carry out a coplanarity measurement on the
other in a single cycle.
Workaround: Describe the job using a placement sequence that specifies that the relevant
components must not be processed in a single cycle.
