Station Software 605.04 / Version Description Ausgabe 04/2015 Edition
29
MTC 2
– The MTC 2 can only be set up on locations 2 and 4 on SIPLACE D3 machines and on
machines of the SIPLACE X-series.
– The productivity lift cannot be used if the MTC2 is set up on location 4.
– It is only possible to use a Twin Head nozzle changer on a location at which an MTC2 is set up
– The component level indicator is not supported for the MTC 2.
WPC 4
– The WPC 4 can only be set up on a SIPLACE D1 / D1i, D3, X2 and X3 machine.
– The WPC 4 can only be set up on location 1 of the D1 / D1i machine.
– The WPC 4 can only be set up on location 2 of the X3 and D3 machine.
– The WPC 4 can only be set up on location 2 and 4 of the X2 machine.
– It is not possible to use a nozzle changer on location 1 if a waffle pack changer is set up.
– The component level indicator is not supported for the waffle pack changer.
– The WPC4 can only be used in the one-gantry placement area.
Synchronous dual conveyor
– It is not possible to configure the PCB conveyor to extra-wide with a synchronous dual
conveyor.
SITEST test software
– Flexible dual conveyor: In order to be able to switch from a dual to single conveyor, mechanical
adaptations must be made.
– Changing the position of the fixed edge: Minor mechanical conversion needs to be carried out
on D-series machines in order to convert the PCB conveyor from standard width to extra-width
and vice versa.
Fiducial patterns
– Asymmetric fiducial patterns (e.g. triangles) can currently only be used if the board is
processed at an orientation of 0° in the machine.
Omit components
– If recovery placement is triggered (e.g. in the event of a power failure or if the machine is
powered down due to a serious machine error during placement), no components may be
omitted during recovery placement.
Interruption of the safety circuit – graphical display of the cause of the error
– If the safety circuit of the machine is interrupted during production (e.g. component parts not
correctly docked), a window opens at the station computer GUI showing the cause of the
interruption (location of the fault) graphically. This window must be confirmed after the error has
been eliminated to allow the machine to continue processing. Unlike X series machines, D
series machines only provide limited facilities for displaying the precise location of the fault
graphically.
Station Software 605.04 / Version Description Ausgabe 04/2015 Edition
30
"Long PCB" option
– The "Long PCB" option is not supported on a SIPLACE D1 / D1i machine for placing
components higher than 8 mm. Higher components that were placed at the first stop unit could
lead to mechanical damage to the C&P head or incorrect placement at the second stop unit as
a result of interference boundaries.
– "Long PCB" option is not supported in combination with flexible dual conveyor.
Teaching/Changing the component shape
– Not released for barcode applications.
Changing the X feeder position
– Not released for barcode applications.
– The new feeder type must be an X feeder (8-88mm).
– The new position (track number) must be on the same table.
Auto recovery and manual recovery
– Not released for barcode applications.
– The "Auto recovery" and "Manual recovery" options must be activated.
Omitting components
– Not released for barcode applications.
– The "Auto recovery" and "Manual recovery" options must be activated.
Placement of 01005 components
– The sleeve is not recognized automatically.
– The nozzle peak position is not calculated and corrected.
– Only for C&P12 and C&P20 heads, the functionality is not supported for C&P6 heads.
– Special sleeves and special nozzles are necessary for C&P12 heads.
– On D4 / D4i machines, the placement of 01005 components is only possible on the placement
area 1.
– The feeders can only be set on the first 6 positions to the gantry root.
– The size of the boards is restricted to 230mm.
– The placement capacity will be reduced for approx. 22%.
Station Software 605.04 / Version Description Ausgabe 04/2015 Edition
31
Automatic pitch download on S feeders
– Surftape feeders are not supported.
– Feeders on X feeder adapter are not supported.
– No check of the current pitch. The pitch is set when the setup job is downloaded. If you replace
the feeder, the new feeder does not assume the current pitch value of SIPLACE Pro.
– The software does not detect if you change manually the pitch values on the feeder.
– The manual pitch download can only be performed table-wise, not feeder-wise.
– The automatic pitch download is also performed if the feeder is in the current setup but not
used in the current job.
– The manual pitch download button is always activated if there is any feeder in the setup for the
respective table even no S-Feeder is set.
– Supported feeders and the restrictions see software version description 604.01,
item no. [00195445-xx].
LDU_X dip module for X-tables
– The number of LDU_X dip modules per head is limited to one.
– The number of LDU_X dip modules per X4 machine is limited to four.
– Setup verification is not possible.
– The "Correct position" function is not available for the LDU_X dip module.
– For C&P 6/12 heads only "Dipping before Vision" is supported.
– Dipping with the C&P20 head is currently not supported.
– The area that effectively is usable for dipping components is given by SIPLACE Pro
– LDU_X dip modules cannot be placed on any track of the X table because of restrictions
concerning the accessibility with the twin head. The range of usable tracks for setting up
LDU_X dip modules is limited in SIPLACE Pro.
– If the medium in the flux reservoir is not sufficient, no message will be displayed. The display of
the level is currently not supported for the LDU_X dip module.
– The table provides an overview for which machines and placement heads the LDU_X dip
module can be used:
Twin Head C&P 6/12 C&P20 P&P
X-series (S-feeder) No No No No
X-series (X-feeder) Yes Yes No No
Emergency stop during automatic width adjustment
If an emergency stop is performed during the automatic width adjustment, the width is not correct
anymore. The desired width has to be redefined in the Manual Operations. Thereafter, it is set and
the production can be restarted.
Counting panels
When using dual lane conveyor, the total quantity of placed panels is assigned to the right board
and the left board gets a zero.
