1 Brief Description
This document describes the Version 605.04 operating software for SIPLACE
®
machines with the
following components
– Graphical user interface (GUI)
– Test software (SITEST)
– SIPLACE Vision
– Station computer (SC)
– Optional Vision computer (required for the 3D coplanarity sensor option)
– Service Tools (see chapter 6)
The software was specially developed for operating the following machines:
– SIPLACE X2
– SIPLACE X3
– SIPLACE X4
– SIPLACE D1 / D1i
– SIPLACE D2 / D2i
– SIPLACE D3
– SIPLACE D4 / D4i
Station Software 605.04 / Version Description Ausgabe 04/2015 Edition
6
2 Scope of Delivery
2.1 Software Components
605.04 software
Standard package: [00140003-xx] Software SIPLACE Station 605.04 Basic
– Software DVD
*)
– License/product certificate
– Software Installation Manual for Station Computer V605.04 German and English, item no.
[00197734-xx]
– 4 temperature warning labels, item no. [03031926-01]
– Packaging
Languages: [00140004-xx] SIPLACE foreign language software SC 605.04
– CD-ROM with software (language pack)
– License/product certificate
– Software Version Description for foreign languages V605.04 German and English,
item no. [00197735-xx]
– Packaging
*)
The standard applications are contained on the CD:
– Embedded software for conveyor
– Embedded software for axes
– Embedded software for component tables
– Embedded software for tape cutter
– Embedded software for heads
– Embedded software for MTC 2
– Embedded software for WPC 4
– Embedded software for vision modules
– Embedded software for I/O modules
– Embedded software for X-feeders
– Embedded software for digital pressure regulation valve
2.2 Hardware Components
– Station computer
– Vision computer (optional, required for the 3D coplanarity sensor option)
Station Software 605.04 / Version Description Ausgabe 04/2015 Edition
7
2.3 Languages
User interface for station computer and SIPLACE Vision:
The standard package contains German and English versions. Other languages contained in the
languages package are optional and available under item no. [00140004-xx].
The following table indicates which languages are available for the station software and SIPLACE
Vision:
Sprache Station software /
SIPLACE Vision
French X
Italian X
Spanish (Mexico) X
Portuguese (Brazil) X
Hungarian X
Czech X
Polish X
Russian X
Estonian X
Chinese (simplified) X
Chinese (traditional) X
Korean X
Japanese X
Thai
*)
X
Table 2-1: Languages
*)
Only available for GUIs (English online help)
SITEST user interface:
German and English are included on the software DVD.
