Station Software 605.04 / Version Description Ausgabe 04/2015 Edition

3 Upgrade to the 605.xx Software Version

A detailed description on upgrading to the 605.xx software version from different previous software

versions can be found in the Installation Manual to the station software, item no. [00197734-xx].

Station Software 605.04 / Version Description Ausgabe 04/2015 Edition

4 Features of the 605.04 Station Software Version

If not differently described, the features of the 601.xx – 605.03 SP5 station software versions are

also supported by the 605.04 station software version. The main features of the 605.04 station

software version are listed below.

Detailed information about the functions can be found in the online help for the station software.

4.1 Operating System Windows 7

As of this station software version, only the Windows 7 operating system is supported on the

station computer and Vision computer (see "Installation Manual Operating System Windows

Embedded Standard 7", item number [00197737-xx] and the Installation Manual to the station

software, item no. [00197734-xx]).

In Windows 7 the station computer has to be equipped with at least 2 GB memory. If necessary,

station computers in the field have to be exchanged or upgraded with a memory extension. Please

refer to the Technical Information TI2014-09E04.

4.2 Opening SIPLACE Vision Measurement Context Files

SIPLACE Vision measurement context files that have been created on a placement machine with

the 605.04 station software version can only be opened with Vision Teach Station as of the 5.1.2

version.

Station Software 605.04 / Version Description Ausgabe 04/2015 Edition

4.3 Supported Hardware Options with an Interface to the 605.04 Station Software

Feature X4 X3 X2 D1/

D1i

D2/

D2i

D3 D4/

D4i

Additional information

RF and PDA MC70 scanner

       Can be used on all X- and D-series

machines, the MTC 2 and the

SIPLACE Setup Center 3.3.

Sensor for reject bin

    Sensor for verifying that the reject bin

has been mounted correctly in order to

prevent potential head crashes

(particularly recommended if C&P20

heads are used).

2D PCB barcode reader

       "2 D Barcode" (hardware) option

required

MTC 2     For restrictions, see chapter 9

"WPC 4" waffle pack changer     For restrictions, see chapter 9

Manual tray        For restrictions, see chapter 9

Component reject conveyor        For restrictions, see chapter 9

Dip module

    Cannot be used on component

changeover tables of the X-series.

Dip module for X-tables (LDU_X)    For restrictions, see chapter 9

Coplanarity module with 3D coplanarity

sensor

  For restrictions, see chapter 9

X feeder adapter for linear feeders    For restrictions, see chapter 9
