4 Operation User manual Docking station for SIPLACE SX co mponent trolleys 4.2 Adjusting the conveyor height Edition 02/2018 72 T o set the conveyor height, proc eed as follows:  Loosen the locknut s on all base feet. …

100%1 / 116
User manual Docking station for SIPLACE SX component trolleys 4 Operation
Edition 02/2018 4.2 Adjusting the conveyor height
71
4.2 Adjusting the conveyor height
You need fork wrenches size SW22 and SW24 plus a spirit level.
4
Fig. 4.2 - 1 Adjusting the conveyor height
(1) X (floor to centering pin)
(2) Centering pin
4 Operation User manual Docking station for SIPLACE SX component trolleys
4.2 Adjusting the conveyor height Edition 02/2018
72
To set the conveyor height, proceed as follows:
Loosen the locknuts on all base feet.
Use the adjusting screws to set the size Y (see table).
Check whether the machine is horizontally level.
4
Machine height Size X Size Y Size Z
900mm 859mm 100mm 770mm
930mm 889mm 130mm 800mm
950 mm 909mm 150mm 820mm
User manual Docking station for SIPLACE SX component trolleys 4 Operation
Edition 02/2018 4.3 Docking and undocking the component trolley
73
4.3 Docking and undocking the component trolley
4
Fig. 4.3 - 1 Docking station
(1) Locking and unlocking of feeder modules (green button)
(2) Component trolley unlocking function (white button)
(3) Pneumatic cylinder for locking the component trolley
(4) Sensor for component trolley detection
(5) Feeder module tear down (black button)
2
1
3
4
5
