3. Label positions viii Safety instructions █ Label positions (machine internal) W arning/caution labels Machine internal HM head unit front No.13 [CAUTION] Strong magnetic field No.13 [CAUTION] Strong magnetic field No.…
3. Label positions
vii
Safety instructions
►
Warning/caution labels (rear)
No. Label Message Measures
2
Electrical shock hazard Do not touch power supply inside
cover.
3
The carrier tape could make contact
with the head,
possibly causing machine damage.
When a feeder is extracted from its
loaded position, be sure that the
feeder has been completely extracted
before pressing it back into its loaded
position.
4
Death, serious injury or equipment
malfunction
Observe precautions necessary due to
strong magnetic fields.
5
· Hands or fingers might be caught
between moving parts and covers,
causing injury.
· Hands or fingers might be pinched
by moving parts, causing injury.
Never place hands or fingers in
machine during operation such as
when handling tray magazines.
6
Injury from touching moving parts
during machine operation
Do not touch or tamper with safety
cover switches and do not operate
machine if any safety cover switches
were deactivated.
7
Injury from tape cutter Do not put hands into cutter unit while
power or air is supplied.
3. Label positions
viii
Safety instructions
█
Label positions (machine internal)
Warning/caution labels
Machine internal
HM head unit front
No.13 [CAUTION]
Strong magnetic field
No.13 [CAUTION] Strong magnetic field
No.12 [PROHIBITION] DO NOT touch
No.12 [PROHIBITION]
DO NOT touch
No.12 [PROHIBITION] DO NOT touch
No.12 [PROHIBITION]
DO NOT touch
No.12 [PROHIBITION] DO NOT touch
No.12 [PROHIBITION]
DO NOT touch
■ X-axis frame
■ X-axis frame
■ Y-axis linear scale
■ Z-axis linear
■ Y-axis linear guide
■ Fiducial camera
■ Scan camera unit
■ Scan camera
HM head unit rear
No.11 [CAUTION] Machine damaged
■ X-axis frame inner side
RM head unit front
Controller
No.12 [PROHIBITION] DO NOT touch
No.15 [WARNING]
Electrical shock hazard
No.9 [CAUTION]
Electrical shock hazard
No.12 [PROHIBITION] DO NOT touch
■ Fiducial camera
■ Side view camera
93013-YRM-10
3. Label positions
ix
Safety instructions
►
Warning/caution labels (machine internal)
No. Label Meassage Measures
9
Electrical shock hazard Do not touch while power is supplied.
11
Machine damage Make sure push-up pins are arranged
within specified area.
12
Adverse effects on component
mounting accuracy
Do not touch camera unit or apply
impacts to it.
13
Death, serious injury or equipment
malfunction
Observe precautions necessary due to
strong magnetic fields.
14
Unexpected accidents may occur if
safety mechanisms are disabled.
Do not remove or disassemble any
specified safety mechanism (protective
cover, safety cover, etc.).
15
Electrical shock hazard Before opening covers wait at least
100 seconds after turning power off.
