3. Maintenance list
pf-3
Introduction
3. Maintenance list
█
Maintenance list
The following maintenance interval and procedure codes are used:
Inspection
Cleaning
Lubrication
Replacement
53002-KMX-10
n
NOTE
Example: Icons
⇢
are shown at the field of "3 Mon." of HM head unit -> Valve -> Filter of the following table.
This means "clean the filter with a period of 3 month and replace it when it isn't cleaned enough".
Section Item Target Daily Weekly Monthly 3 Mon. 6 Mon. Over 1 year
Common
for each
head
Nozzle
Tip
⇢
Air path
Nozzle slide section
HM head
unit
Leaf spring
Nozzle mounting
condition
⇢
Valve
Filter
⇢
Ejector pit
2
year
Spline shaft
Exterior
Interior
(air path)
1
year
RM head
unit
Rotary
section
Filter
Nozzle shaft tip
Upper of nozzle
shaft
2
year
Inner of nozzle shaft When needed
Vacuum
switching
mechanism
Spool
2
year
R-axis and
N-axis
Scissors gear
2
year
Air line Blow valve
2
year
XY-axis
X-axis
Ball screw
Guide
Y-axis
Linear guide
Linear scale
3. Maintenance list
pf-4
Introduction
Section Item Target Daily Weekly Monthly 3 Mon. 6 Mon. Over 1 year
Conveyor
transfer
unit
Board
transfer unit
Sensor condition
check
Conveyor belt
1
year
⇢
PU-axis Ball screw
U-axis
Ball screw
1
year
Guide
1
year
W-axis
Ball screw
1
year
Guide
1
year
Hexagon spline
1
year
Recognition
equipment
Fiducial
camera
Camera lighting
Multi
camera
Protector glass
Camera lighting and
lens
Scan
camera
(HM)
Diffuser (prism)
Side view
camera
(RM)
Light (prism)
Base
section and
other
Feeder plate Plate
Tape cutter
Tape cutter Slope
and ejecting duct
Cover, front
and rear
Air intake fan filter
⇢
Cover,upper
surface
Fan filter
⇢
Machine
rear side
Air intake fan filter
⇢
Control box Air intake fan filter
⇢
Air filter and
mist filter
Filter
1
year
⇢
Feeder
exchange
carriage
(machine
side)
Clamp
Running surface for
carriage
Positioning hole on
machine side
Upper cover Positioning unit
Feeder
exchange
carriage
(carriage
side)
Feeder plate
Feeder plate and
clamp unit
Positioning
unit
Positioning pin on
carriage side
Cam follower
Carriage up/
down unit
Up/down shaft unit
1
