– 6 – M 3 Frame 2 Assy 1710-003 206-16 206-06 206-02 206-04 206-13 206-12 206-14 206-1 1 206-15 206-05 206-04 206-23 206-21 206-03 206-24 206-26 206-25 206-22 206 215 206-01 206-07 224 223 213 214 203 202 207-09 207-09 2…
– 5 –
Tape Feeder GD-38080,38083, GT-38080
1303-001
No.
Part No.
Part Name
Qty.
Detail
Yamaha Hitachi
GD-38080 GD-38083 GT-38080
101 KYD-MC10C-00 1016100L ASSY_FRAME1 1 1 1
101-01 KYD-MC103-00 1016B002 FRAME1 1 1 1
101-02 KYD-MC13M-00 216E1484 PIN_LOCATE 4 4 4
101-03 KYD-MC10T-00 016J0024 ASSY_HOOK 2 2 2
101-04 KYD-MC13L-00 216D0468 PIN_HINGE 1 1 1
101-05 KYD-MC13H-00 212A2190 GUIDE 1 1 1
101-06 90440-01J020 221KA002 ROHS_RING 2 2 2
101-07 91609-20020 221J0059 SPRING,PIN 1 1 1
101-08 90167-02JA06 221DA103 MACHINE SCREW 2 2 2 FLT M2.5L6
101-09 KYD-MC12R-00 1016B00P PIN_LOCATE 2 2 2
111 KYB-M940H-00 1016B005 SLIDE(BASE) 1 1 1
112 KYD-MC12P-00 1016B007 SPRING_COMP(F) 2 2 2
132 90990-01J147 221AA103 BOLT,HEX.S/H WW 2 2 2 M4L14 SW+FW
– 6 –
M
3 Frame 2 Assy
1710-003
206-16
206-06
206-02
206-04
206-13
206-12
206-14
206-11
206-15
206-05
206-04
206-23
206-21
206-03
206-24
206-26
206-25
206-22
206
215
206-01
206-07
224
223
213
214
203
202
207-09
207-09
201
209
210
219
222
217
208
204-02
204-03
208
205-01
219
205-03
210
204-01
211
211
212
205-02
218
207-04
207-10
220
221
207-08
207-03
207-07
207-03
207-05
207-06
207-11
207-11
216
207-01
207
204
205
207-02
207-12
207-20
– 7 –
Tape Feeder GD-38080,38083, GT-38080
1303-001
No.
Part No.
Part Name
Qty.
Detail
Yamaha Hitachi
GD-38080 GD-38083 GT-38080
201 KYD-MC104-00 1016B003 FRAME2 1 1 1
202 KYD-MC13M-00 216E1484 PIN_LOCATE 2 2 2
203 91609-30018 221J0061 SPRING PIN 1 1 1
204 KYD-MC12J-00 1016120P ASSY_TENSION(L) 1 1 1
204-01 KYD-MC11M-00 1016B203 ASSY_LEVER(L) 1 1 1
204-02 KYD-MC13S-00 221F0137 NUT_HEX 1 1 1 M3_3
204-03 KYD-MC13R-00 216F1000 PIN_GUIDE(BANE) 1 1 1
205 KYD-MC12K-00 1016120Q ASSY_TENSION(R) 1 1 1
205-01 KYD-MC11N-00 1016B204
ASSY_LEVER(R)
1 1 1
205-02 KYD-MC13S-00 221F0137 NUT_HEX 1 1 1 M3_3
205-03 KYD-MC13R-00 216F1000 PIN_GUIDE(BANE) 1 1 1
206 KYD-MC116-00 1016120R ASSY_BASE 1 1 1
206-01 KYD-MC11J-00 1016B200 BASE 1 1 1
206-02 KYD-MC118-00 1016120T ASSY LEVER(L) 1 1 1
206-11 KYD-MC11K-00 1016B201 ASSY_LEVER(L) 1 1 1
206-12 KYD-MC130-00 1016B209 GEAR(HIRA-1) 1 1 1
206-13 KYD-MC13P-00 216E1731 PIN_LOCATE 1 1 1
206-14 KYD-MC13F-00 211G5776 BLOCK(L) 1 1 1
206-15 90167-02JA06 221DA103 MACHINE SCREW 1 1 1 FLT M2.5L6
206-16 90166-12JA02 221DA008 MACHINE_SCREW 2 2 2
PAN M2.5L6 SW+FWS
206-03 KYD-MC119-00 1016120U
ASSY LEVER(R)
1 1 1
206-21 KYD-MC11L-00 1016B202 ASSY_LEVER(R) 1 1 1
206-22 KYD-MC130-00 1016B209 GEAR(HIRA-1) 1 1 1
206-23 KYD-MC13P-00 216E1731 PIN_LOCATE 1 1 1
206-24 KYD-MC13G-00 211G5777 BLOCK(R) 1 1 1
206-25 90167-02JA06 221DA103 MACHINE SCREW 1 1 1 FLT M2.5L6
206-26 90166-12JA02 221DA008 MACHINE_SCREW 2 2 2
PAN M2.5L6 SW+FWS
206-04 KYD-MC13T-00 222M1329 SPRING_COMP 2 2 2
206-05 KYD-MC138-00 1016B20Y PIN_LOCATE 1 1 1
206-06 KYD-MC139-00 1016B20Z PIN_LOCATE 1 1 1
206-07 KYD-MC13N-00 216E1489 PIN_LOCATE 1 1 1
207 KYD-MC117-01 ASSY_BASE 1 1 1
207-01 KYD-MC11A-01 ASSY_GEAR 1 1 1
207-02 KYD-MC12L-01 ASSY_GEAR 2 2 2
207-03 KYD-MC153-00 GERA ASSY 2 2 2
207-04 KYD-MC11X-00 211AC677 COVER(MAKI-2) 1 1 1
207-05 KYD-MC132-00 1016B20C PIN_LOCATE 1 1 1
207-06 KYD-MC137-00 1016B20K PIN_LOCATE 1 1 1
207-07 KYD-MC134-00 1016B20E SPACER 1 1 1
207-08 KYD-MC11R-00 1016B20M COVER 1 1 1
207-09 KYD-MC11S-00 1016B20N MOTOR_DC 2 2 2
207-10 90166-12J204 221DA060 MACHINE SCREW 1 1 1 PAN M2L4 SW+FWS
207-11 90990-01J135 221AA089 BOLT_HEX-SCT 4 4 4 M2.5L6 SW+FWS
207-12 KYD-MC152-00 COLLAR 1 1 1
207-20 KYD-MC154-00 BASE ASSY. 1 1 1
208 KYD-MC12X-00 1016B205 ROLLER(A) 2 2 2
209 KYD-MC135-00 1016B20F PIN_LOCATE 1 1 1
210 KYD-MC129-00 0926B201 SPRING_COMP 2 2 2
211 KYD-MC13Y-00 23G10088 SENSOR_PHOTO 2 2 2
212 KYD-MC12Y-00 1016B206 SPACER 1 1 1
213 KYD-MC12N-00 1016B004 COVER(FUTA) 1 1 1
214 KYD-MC13W-00 226J1891 MECH-P_MAGNET 1 1 1
215 90990-01J135 221AA089 BOLT_HEX-SCT 2 2 2 M2.5L6 SW+FWS
216 90990-01J136 221AA090 BOLT,HEX.S/H WW 2 2 2 M3L6 SW+FWS
217 90990-08J031 221DB031 SCREW,PAN HEAD 2 2 2 PAN M2L18
218 90990-02J037 221C0100 SET SCREW(SET SCREW) 1 1 1 SET M2L3
219 90440-01J025 221KB002 RING_E_025W 2 2 2 E RING2.5
220 KYD-MC11X-00 211AC677 COVER(MAKI-2) 1 1 1
221 90166-12J204 221DA060 MACHINE SCREW 1 1 1 PAN M2L4 SW+FWS
222 90171-02J026 221HA101 WASHER,PLAIN 2 2 2 FW2
223 KYD-MC13X-00 226J1909 MECH-P_CUTTER 1 1 1
224 90166-12J204 221DA060 MACHINE SCREW 1 1 1 PAN M2L4 SW+FWS
