– 1 1 – T ap e F ee der GD-38080 ,3808 3 , G T -38080 1303-001 No. Part No. Part Name Qty . Detail Y amaha Hitachi GD-38080 GD-38083 GT -38080 401 KYD-MC105-00 1016B10Q BASE_DRIVE 1 1 1 402 KYD-MC12G-00 10161 1 1J ASSY_S…
– 10 –
M
5 Driving Base Assy
1710-003
B
411
410
406-16
406-12
416
409
412
413
or
or
414
421
422
or
or
423
417
404
403
405
416
418
439
419
415
433
439
406-11
406-13
406-04
406-02
406-14
406-14
406-03
418
407-17
407-12
407-13
407-14
407-14
406-15
406-01
406-16
407-15
407-17
407-03
407-16
407-02
401
420
408
402
407-11
407-01
407
406
B
C
C
– 11 –
Tape Feeder GD-38080,38083, GT-38080
1303-001
No.
Part No.
Part Name
Qty.
Detail
Yamaha Hitachi
GD-38080 GD-38083 GT-38080
401 KYD-MC105-00 1016B10Q BASE_DRIVE 1 1 1
402 KYD-MC12G-00 1016111J ASSY_SPROCKET_L 1 1 1
403 KYD-MC12H-00 1016111M ASSY_SPROCKET_R 1 1 1
404 KYD-MC112-00 1016111G ASSY_GEAR(L) 1 1 1
405 KYD-MC113-00 1016111H ASSY_GEAR(R) 1 1 1
406 KYD-MC110-00 1016111E ASSY_GEAR(L) 1 1 1
406-01 KYD-MC10X-00 1016111C ASSY_GEAR(L) 1 1 1
406-11 KYD-MC10M-00 1016B10R BASE(L) 1 1 1
406-12 KYD-MC11D-00 1016B10W GEAR 1 1 1
406-13 KYD-MC13K-00 216A1147 COLLAR(BEARING) 1 1 1
406-14 90933-03J683 222D0377 BEARING,RADIAL 3 3 3
406-15 KYD-MC12S-00 1016B10X PULLEY_TIMING 1 1 1
406-16 90990-02J015 221C2018 SCREW,SET 2 3 3 SET M2L3
406-02 KYD-MC12C-00 0988031Y ASSY_MOTOR 1 1 1
406-03 KYD-MC13V-00 223L0270 BELT_TIMING 1 1 1
406-04 90990-01J141 221AA093 BOLT,HEX.S/H WW 2 2 2
407 KYD-MC111-00 1016111F ASSY_GEAR(R) 1 1 1
407-01 KYD-MC10Y-00 1016111D ASSY_GEAR(R) 1 1 1
407-11 KYD-MC10N-00 1016B10S BASE(R) 1 1 1
407-12 KYD-MC11D-00 1016B10W GEAR 1 1 1
407-13 KYD-MC13K-00 216A1147 COLLAR(BEARING) 1 1 1
407-14 90933-03J683 222D0377 BEARING,RADIAL 3 3 3
407-15 KYD-MC12S-00 1016B10X PULLEY_TIMING 1 1 1
407-16 KYD-MC13V-00 223L0270 BELT_TIMING 1 1 1
407-17 90990-02J015 221C2018 SCREW,SET 2 3 3 SET M2L3
407-02 KYD-MC12C-00 0988031Y ASSY_MOTOR 1 1 1
407-03 90990-01J141 221AA093 BOLT,HEX.S/H WW 2 2 2
408 KYD-MC12U-00 1016B117 SPROCKET_PIN 1 1 1
409 KYD-MC12V-00 1016B118 SPROCKET_BOLT 1 1 1
410 KYD-MC11B-00 1016B10N COVER(WORM-A) 1 1 1
411 KYD-MC11C-00 1016B10P COVER(WORM-B) 1 1 1
412 KYD-MC14R-00 0926B11N COLLAR 2 2 2
413 KYD-MC14S-00 0926B11P COLLAR 2 2 2
414 KYD-MC14T-00 0926B11Q COLLAR 2 2 2
415 KYD-MC13D-00 211AD849 COVER 1 1
415 KYD-MC122-00 4B111626 PCB(SENSOR) 1
416 90115-02J004 221A0121 BOLT,HEX-SCT 4 4 4 M2L4
417 90990-71J002 221E0049 BOLT,C/SUNK HEX.S/H 1 1 1 FLT M3L10B
418 90990-01J139 221AA092 BOLT,HEX.S/H WW 4 4 4 M3L8 SW+FW
419 90990-01J134 221AA083 BOLT,HEX.S/H WW 2 2 2 M2L8 SW+FW
420 KYD-MC14U-00 1016B11Y COLLAR 1 1 1
421 KYD-MC14V-00 1016B11V COLLAR 1 1 1
422 KYD-MC14W-00 1016B11W COLLAR 1 1 1
423 KYD-MC14X-00 1016B11X COLLAR 1 1 1
433 KYD-MC10P-00 1016B112 RUBBER_COVER 1 1 1
439 90990-01J141 221AA093 BOLT,HEX.S/H WW 3 3 3 M3L12 SW+FW
– 12 –
M
6 Suppressor Section
1710-003
See Fig.M-2
Key No.101-01
513
541
517
517-03
513-02
513-01
516
516
540
540
541
515
541
541
515
514
514
513
513-02
513-01
517
517-03
