63-B 2ノズルヘッド :NPM 2 NOZZLE HEAD:NPM パーツレイアウト Ki t N o . キット 品番 Kit N a me キット名称 N610157743AA ｾｸｼｮﾝNo. PARTS LAYOUT Section No. - - O209 ( KN610157743AA-05-2 )
Ref
No.
Remarks
R
1
Q'ty
63-A
2ノズルヘッド:NPM
2 NOZZLE HEAD:NPM
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610157743AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
BLOCK
2
1 N210082171AA
HANDLE
2
2 N210082172AA
BRACKET
1
3 N210085978AA
BRACKET
1
4 N210095812AA
COVER
1
5 N210120034AB
BRACKET
1
6 N210085982AE
CLAMPER
2
7 N210091686AA
NUT-PLATE
2
8 KXFB04N8A00
PLATE
1
9 N210122620AA
BRACKET
1
10 N210095814AA
BRACKET
1
11 N210147465AA
SCREW
4
12 N510045431AA
Cross recessed pan head machine screw with RPW M3X5-4.8 A2S
JOINT
1
13 N510066629AA KQ2U04-00A
SCREW
4
14 N510018251AA
Cross recessed Truss head machine screw M3X5-4.8 A2J (Trivalent)
SPACER
2
15 N510029469AA ASF-317E
SPACER
1
16 N510020146AA ASF-435E
SPACER
2
17 N510015573AA ASF-448E
COUPLER
1
18 N510057077AA MA-MS-PC4-06X08(CS33420-5)
BOLT
10
19 N510002011AA SRBS-M4X10
CUSHION
4
20 N610066203AA
SENSOR
1
21 N610078617AB
SENSOR
1
22 N610078618AA
O208
--
( KN610157743AA-05-1 )
63-B
2ノズルヘッド:NPM
2 NOZZLE HEAD:NPM
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610157743AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
O209
( KN610157743AA-05-2 )
Ref
No.
Remarks
R
1
Q'ty
63-B
2ノズルヘッド:NPM
2 NOZZLE HEAD:NPM
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610157743AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
PLATE
1
1 N210186137AA
JOINT
2
2 KXFB0APXA00
JOINT
2
3 KXFB0APZA00
MANIFOLD
1
4 N210113239AA
PLATE
1
5 N210085976AB
COVER
1
6 N210085977AD
BRACKET
1
7 N210097158AE
MOTOR
2
8 N510043456AA
S
P50BA2003BCS4D
PIN
4
9 N510020597AA MMS4-8
LINEAR-WAY
2
10 N510043367AA KR15QZ+0812-0006194(80012465M001)
BOLT
16
11 N986LH0306 LH0306
SCREW
5
12 N510018280AA
Cross recessed Truss head machine screw M4X6-4.8 A2S (Trivalent)
JOINT
4
13 N510066461AA KQ2L06-M5A
JOINT
1
14 N510066712AA KQ2S06-M5A
JOINT
2
15 N510066683AA KQ2H08-01AS
STEEL-BALL
4
16 KXF081WAA00 4.5mm
SPACER
2
17 N510015581AA CF-335E
BOLT
2
18 N510017331AA
Hexagon socket head cap screw M3X45-10.9 A2J (Trivalent)
SPACER
2
19 N510034273AA ASF-590E
SPACER
4
20 N510019890AA ASF-350E
SPACER
2
21 N510031805AA CB-530E
WASHER
2
22 N510033408AA 87FWSSB-D20.0-V5.0-T3.0
JOINT
2
23 N510066662AA KQ2L04-M5A
BOLT
2
24 N510017750AA
Hexagon head bolt Best class M5X45-6g 4T A2J (Trivalent)
VALVE
2
25 N510054501AA VQZ115R-5MOZ1-C6-X513
VALVE
2
26 N510054170AA VQZ115R-5LOZ1-M5-X550
BOLT
1
27 N510017514AA
Hexagon socket button head screw M3X8-10.9 A2J (Trivalent)
FAN
1
28 N510044729AA 109L0624H408
JOINT
1
29 N510066732AA KQ2Y06-M5A
JOINT
1
30 N510066792AA KQ2L04-06A
STEEL-BALL
1
31 N510029639AA 6.5mm
REGULATOR
1
32 N610074285AC
O210
--
( KN610157743AA-05-2 )
