1-6 AL VEG-ID 0809-002 Electrical Box Pickup Position Camera Control Unit (Power Supply for LED Illumination) Personal Computer for Data Writing (DELL Optiplex Series) Fig. A2 Side View of Personal Computer Box The jig i…
1-5
ALVEG-ID
3. Rough View of Device
Liquid Crystal Display
(DELL E176FP)
Micrometer
Mouse
Keyboard
Pickup Position
Master
Toggle Clamp
Measuring Jig
Adjustment Base
Pickup Position Camera
Personal Computer Box
LED Illumination
Micrometer Unit
(Measured Data Transfer Unit)
Fig. A1
The jig in the above inset photo might look different from the actual one.
0809-002
3. Rough View of Device
1-6
ALVEG-ID
0809-002
Electrical Box
Pickup Position Camera Control Unit
(Power Supply for LED Illumination)
Personal Computer for Data Writing
(DELL Optiplex Series)
Fig. A2 Side View of Personal Computer Box
The jig in the above inset photo might look different from the actual one.
