2. BASE FRAME ELECTRIC APPARATUS COMPONENTS (1)
1 1
7
8
9
6
5
1 0 1 2
3 4
1 4
2 1
2 2
2 2
1 8
1 8
1 6
1 7
1 7
1 6
2 7
2 8
2 6
2 5
2 9
2 1
1 2
4 8
4 4
4 5
4 3
4 9
4 6
4 6
1 5
4 7
2 3
2 0
3 8
4 0
4 1
3 9
4 2
3 2
3 7
3 3
3 6
3 5
3 4
3 0 3 1
5 3
5 1
5 2
5 0
1 3
1 9
2 4
2 4
- -
REF.NO NOTE PART NO D E S C R I P T I O N Qty
1 400-01559 MANIHOLD ASSY 1
2
#02
400-74094 MANIHOLD(1070C) ASSY 1
3 400-00546 AIR MANIFOLD UNIT (1)
4
#02
400-74095 AIR MANIFOLD UNIT(1070C) (1)
5 SL-6043092-TN BOLT (2)
6 PJ-0200000-03 PLUG ROUND 12 (1)
7 PJ-3091200-03 MANIFOLD (1)
8 PX-9500010-00 PLUG (3)
9 PJ-3040600-01 ELBOW (4)
10 PJ-3010600-03 REDUCER (2)
11 400-00549 AIR MANIFOLD BRACKET (1)
12
#02
PJ-3010600-03 REDUCER (1)
13 E2618-760-000 CAP (4)
14 SL-6052092-TN SCREW (2)
15 400-01561 TRANSFORMAR ASSY 1
16 WS-1220002-KN SPRING WASHER (4)
17 WP-1252210-SC WASHER 12.5X25.6X2.2 (4)
18 SL-6103542-TN SCREW M10 L=35 (4)
19 400-40378 TRANSFORMER(PSU) (1)
20 400-40379 TRANSFORMER(SERVO) (1)
21 400-00450 TRANS SCREW (4)
22 NM-6120001-SC NUT M12 (4)
23 400-01562 AC BR ASSY 1
24 E1038-871-000 PLATEN LOCK CAM SCREW (2)
25 400-00487 AC POWER BAR (2)
26 SL-6051292-TN BOLT (2)
27 400-00483 AC POWER BRACKET (1)
28 SL-4040891-SC SCREW M4 L=8 (2)
29 SL-6061292-TN SCREW (2)
30
#01
400-15595 MTC IF PANEL L ASSY(EN) 1
31 400-01558 MTC IF PANEL L ASSY 1
32 PJ-2300062-00 UNION (1)
33
#01
HK-0429900-7A CAP (1)
34 400-02104 MTC I/F(L) CABLE ASM (1)
35
#01
HK-0528905-0B DUST COVER (1)
36 400-02062 MTC POWER CABLE L ASM (1)
37 PX-9500010-00 PLUG (1)
38 400-00499 MTS IF PANEL (1)
39 SL-6061292-TN SCREW (2)
40 SL-4030881-SC SCREW M3 L=8 (4)
41 SM-4860501-SB SCREW M2.5 L=5 (2)
42 400-02115 HOURMETER ASM. (1)
43 400-01554 BREAKER ASSY 1
44 SL-4040891-SC SCREW M4 L=8 (2)
45 SL-4040891-SC SCREW M4 L=8 (4)
46 HA-0053200-10 CIRCUIT PROTECTOR (1)
47 400-00489 BRAKER BRACKET (1)
48 SL-4040891-SC SCREW M4 L=8 (3)
49 HA-0053200-00 CIRCUIT PROTECTOR (1)
50
#02
400-74093 HOURMETER 1070C ASM 1
51 400-00499 MTS I/F PANEL (1)
52 400-02115 HOURMETER ASM (1)
53 SL-6061292-TN SCREW (2)
- -
3. BASE FRAME ELECTRIC APPARATUS COMPONENTS (2)
M4 * 8
6 0
5 8
5 9
6 1
4 1
4 2 4 3 4 4
5 6 5 75 4 5 55 2 5 35 0 5 1
4 8
6 4 6 5
4 9 6 6
6 2 6 3
1 3 1 4
4 5
4 6
3 03 94 0
3 1
3 1
3 6
1 5
1 6
1 7
1 8
2 8
1 9
2 9
2 6
2 7
3 3 4 7
88
5
3
1 2
6 7
1 0
9
2
2
4
1 1
1
3 7
2 1
2 2 2 3
2 4
3 2
3 4
2 5 3 8
2 0
3 5
