- - RE F .NO N O TE PART NO D E S C R I P T I O N Q t y 1 400-46057 BM HOLDER 1 2 SL-603 06 92- T N S CREW M3 L=6 2 3 400-02267 BAD MARK SENSOR ASM 1 4 SM-6030602-TN H E X SCR EW M3 X 6 2 5 H D -001 3100-40 S ENSOR 1 6…
- -
52. BAD MARK READER COMPONENTS
5
7
8
6
9
2
1
4
3
- -
REF.NO NOTE PART NO D E S C R I P T I O N Qty
1 400-46057 BM HOLDER 1
2 SL-6030692-TN SCREW M3 L=6 2
3 400-02267 BAD MARK SENSOR ASM 1
4 SM-6030602-TN HEX SCREW M3 X 6 2
5 HD-0013100-40 SENSOR 1
6 E9638-729-000 FIBER LENS 1
7 HX-0029400-00 FIXED BASE 2
8 SL-4030691-SC SCREW M3 L=6 2
9 EA-9500B01-00 CABLE BAND 4
- -
53. COPLANARITY UNIT
1 3 5
2
3
6
7
8
9
8
9
2 1
2 2
2 0
1 9
1 8
1 7
1 6
2 7
1 0 1 1
2 3
1 5
4
1 3
1 4
2 6
2 9
3 0
3 1
3 2
3 3
3 4
3 6
3 8
3 7
5
1 2
2 4
2 5
2 3
2 8
2 8
