- - 23 . LIFTE R UN I T COMPONEN T S (2 ) 3 5 1 1 7 8 1 0 6 9 1 6 1 3 1 2 1 5 1 4 1 7 1 8 2 3 2 2 2 1 2 0 2 4 3 1 9 2 4 2 0 2 2 2 1 2 3 1 9 4 4 2 5 1 2 3 1 3 0 2 7 3 2 2 8 3 3 3 4 3 5 4 1 4 0 3 9 3 8 4 7 4 6 4 5 4 9 4 …
- -
REF.NO NOTE PART NO D E S C R I P T I O N Qty
1 400-00580 FRONT LIFTER UNIT 1
2 400-00582 LIFTER L UNIT (1)
3 400-00557 LIFTER SUPPORTER L (1)
4 400-00587 LIFTER BUSH COMBINATION (2)
5 SM-6041002-TN BOLT (8)
6 PA-6307503-00 AIR CYLINDER (1)
7 PC-0152030-00 SPEED CONTROLLER (2)
8 SL-6104042-TN BOLT (4)
9 WP-1052000-SC WASHER 10.5X18X2 (4)
10 400-00588 BANK LIFTER L (1)
11 400-00589 LIFTER CYLINDER SHAFT (1)
12 E2622-729-000 LIFTER THRUST COLLAR (1)
13 SM-1062052-TP SCREW M6 L=20 (1)
14 E2610-721-000 BANK LOCATE PIN B (1)
15 NM-6080003-SC NUT M8 (1)
16 WS-0820002-KN SPRING WASHER M8 (1)
17 SM-8060552-TP SCREW M6 L=5 (2)
18 400-00583 LIFTER R UNIT (1)
19 400-00558 LIFTER SUPPORTER R (1)
20 400-00587 LIFTER BUSH COMBINATION (2)
21 SM-6041002-TN BOLT (8)
22 PA-6307503-00 AIR CYLINDER (1)
23 PC-0152030-00 SPEED CONTROLLER (2)
24 SL-6104042-TN BOLT (4)
25 WP-1052000-SC WASHER 10.5X18X2 (4)
26 400-00590 BANK LIFTER R (1)
27 400-00589 LIFTER CYLINDER SHAFT (1)
28 E2622-729-000 LIFTER THRUST COLLAR (1)
29 SM-1062052-TP SCREW M6 L=20 (1)
30 400-00595 BANK LOCATE PIN C (1)
31 NM-6080003-SC NUT M8 (1)
32 WS-0820002-KN SPRING WASHER M8 (1)
33 SM-8060552-TP SCREW M6 L=5 (2)
34 SL-6082592-TN BOLT (4)
- -
23. LIFTER UNIT COMPONENTS (2)
3
5
1 1
7
8
1 0
6
9
1 6
1 3
1 2
1 5
1 4
1 7
1 8
2 3
2 2
2 1
2 0
2 4
3
1 9
2 4
2 0
2 2
2 1
2 3
1 9
4
4
2 5
1 2
3 1
3 0
2 7
3 2
2 8
3 3
3 4
3 5
4 1
4 0
3 9
3 8
4 7
4 6
4 5
4 9
4 2
4 4
4 3
5 1
5 2
5 4
5 3
5 6
5 5
3 7
6 1
1 8
2 5
2 9
3 6 5 0
2 6
2 6
6 2
6 2
6 3
6 5
6 4
4 8
6 6
5 9
5 8
5 7
6 0
- -
REF.NO NOTE PART NO D E S C R I P T I O N Qty
1
#01
400-59915 ROLLER GUIDE F ASSY 1
2
#02
400-59916 ROLLER GUIDE R ASSY 1
3 400-46580 ROLLER GUIDE F (2)
4
#02
400-46628 ROLLER GUIDE R (2)
5 E2631-729-0A0 BANK VALVE L ASM. (1)
6 E2631-729-000 BANK VALVE BRACKET (1)
7 PV-0105050-00 MECHANICAL VALVE (1)
8 SL-6042592-TN SCREW (2)
9 E2811-729-000 VALVE NUT PLATE (1)
10 PJ-3040405-05 ELBOW (1)
11 PX-0505010-00 SILENCER (1)
12 E2631-729-AA0 BANK VALVE R ASM. (1)
13 E2631-729-000 BANK VALVE BRACKET (1)
14 PV-0105050-00 MECHANICAL VALVE (1)
15 SL-6042592-TN SCREW (2)
16 E2811-729-000 VALVE NUT PLATE (1)
17 PJ-3040405-05 ELBOW (2)
18 SM-1051452-TN PLATE SCREW M5 L=14 (4)
19 E2777-721-0A0 BANK STOPPER ASM. (2)
20 E2777-721-000 BANK STOPPER (1)
21 E2778-721-000 STOPPER RUBBER (1)
22 E2779-721-000 STOPPER COLLAR (2)
23 SL-6031292-TN SCREW M3 L=12 (2)
24 SL-6051642-TN BOLT (4)
25 SM-1051052-TN SCREW M5 L=10 4
26 SM-0040801-SC SCREW 4
27 400-00585 SELECTOR ASSY 1
28 PV-0151170-A0 SELECTOR (1)
29 PV-0251030-00 CHECK VALVE (1)
30 PJ-3010651-03 HALF UNION 6XPT1/8 (1)
31 PJ-3040651-03 SWIVEL ELBOW (2)
32 PX-0551040-00 SILENCER (PT1/8) (1)
33 E2793-721-000 FL LABEL (1)
34 PJ-3080600-03 Y UNION 2
35 PJ-3040600-01 ELBOW 1
36
#01
BT-0600400-EC TUBE HOSE, BLUE 6.5
37
#02
400-26804 DS CONNECTOR BRACKET 1
38
#01
400-01770 BANK UP SENSOR(FL)ASSY 1
39 400-12012 BANK UP SENSOR STAY (1)
40 400-02167 BANK UP(F)SENS ASM. (1)
41 SM-4860801-SC SCREW M2.6 L=8 (1)
42
#01
400-12013 BANK UP SENSOR DOG 1
43 #01 SM-6050802-TN BOLT 2
44
#01
SM-1051452-TN PLATE SCREW M5 L=14 2
45 400-00565 DRIVER BRACKET SUPPORT C ASM. 1
46 400-00598 DRIVER BRACKET SUPPORT C (2)
47 SL-6051042-TN SCREW (4)
48 SL-6051242-TN SCREW (4)
49
#01
SL-6051092-TN BOLT 2
50
#02
BT-0600400-EC TUBE HOSE, BLUE 11.4
51
#02
400-01771 BANK UP SENSOR(RL)ASSY 1
52 400-02169 BANK UP(R)SENS ASM (1)
53 SM-4860801-SC SCREW M2.6 L=8 (1)
54
#02
400-12013 BANK UP SENSOR DOG 1
55
#02
SM-6050802-TN BOLT 2
56 #02 SM-1051452-TN PLATE SCREW M5 L=14 2
57
#01
400-00565 DRIVER BRACKET SUPPORT C ASM. 1
58 400-00598 DRIVER BRACKET SUPPORT C (2)
59 SL-6051042-TN SCREW (2)
60 SL-6051242-TN SCREW (2)
61
#02
SL-6051092-TN BOLT 2
62 SM-4861001-SC SCREW M2.6 L=10 8
63
#03
E1296-729-000 BANK SENSOR BRACKET(CE) 1
64
#03
SM-1051452-TN PLATE SCREW M5 L=14 2
65
#03
400-02287 B SW CABLE ASM(EN)(CE) 1
66
#01
400-26804 DS CONNECTOR BRACKET 1
