Appendix
1.3 Connection between machines
To exchange signals such as board request and operation status with the downstream or upstream machine, the
"NEXT INTERFACE" and "PREVIOUS INTERFACE" connectors located on the rear of the machine are used. The
"NEXT INTERFACE" connector connects to the downstream machine, and the "PREVIOUS INTERFACE"
connector connects to the upstream machine such as a loader.
1.3.1 PREVIOUS INTERFACE connector
When the following three conditions are met, the PREVIOUS INTERFACE circuit in the machine allows the next
board to be carried in. (ADVANCED GATE is selected.)
1. Machine is ready for carrying in a board (BUSY OUT: ON)
2. Board carry-in signal is input from the upstream machine. (BA IN [N0100421] : ON)
3. Automatic operation signal is input from the upstream machine. (UR IN [N0100422] : ON)
n
NOTE
• When the automatic operation signal (UR IN) from the loader turns off during transfer of a board, the machine
temporarily stops carrying in the board.
• When the board being carried in is detected by the entrance sensor, the BUSY OUT signal turns off.
• Carrying in the board is finished when both the BUSY OUT and BA IN turn off.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
7
12
4
8
1
14
11
3
BUSY OUT
(T01000E4)
+24V
+24V
LR OUT
(T01000E7)
UR IN
(N0100422)
BA IN
(N01000421)
Signal input during
board carry-in
Signal output to
request board carry-out
Signal output during
automatic operation
Signal input during
automatic operation
LE OUT
(T01000F3)
Signal input during
waiting for board
between machines
I/O BOARD
PREVIOUS INTERFACE circuit
This machine PREVIOUS INTERFACEUpstream
PREVIOUS INTERFACE
connector
AMP 206043-1
(14-pin receptacle)
53A04-N9-00
n
Board transfer signal specifications (PREVIOUS INTERFACE)
Pin No. Signal name Address I/O specifications Signal specifications
1 BUSY OUT T01000E4 Relay contact (zero voltage) output
Signal output during board carry-in
2 BUSY OUT T01000E4 Relay contact (zero voltage) output
3 +24V Input common (+24V)
Signal input of board carry-out
request
4 BA IN N0100421 Voltage input
5 NC (with dummy pins) (Prevents misinsertion.)
6 to 8 NC
9 +24V Input common (+24V)
Signal input during automatic
operation
10 UR IN N0100422 Voltage input
11 LR OUT T01000E7 Relay contact (zero voltage) output
Signal output during automatic
operation
12 LR OUT T01000E7 Relay contact (zero voltage) output
13 LE OUT T01000F3 No-voltage output
Signal output during waiting for
board between machines
14 LE OUT T01000F3 No-voltage output
A-4
Appendix
1.3.2 NEXT INTERFACE connector
When the following three conditions are met, the NEXT INTERFACE circuit in the machine allows the board to
be carried out.
1. Machine is ready for carrying out the board (BA OUT: ON)
2. Board carry-in signal is input from the downstream machine. (BUSY IN [N0100420] : ON)
3. Automatic operation signal is input from the downstream machine. (LR IN [N0100423] : ON)
n
NOTE
• When the automatic operation signal (LR IN) from the downstream machine turns off during transfer of a board,
the machine stops temporarily carrying out the PC.
• When the board being carried out is detected by the exit sensor, the BA OUT signal turns off.
• Carrying out the board is finished when both the BUSY IN and BA OUT turn off.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
BUSY IN
(N0100420)
+24V
+24V
UR OUT(T01000E6)
LR IN
(N0100423)
+24V
LE IN
(N0100424)
BA OUT
(T01000E5)
Signal output during waiting
for board between machines
I/O BOARD
GND GND
14
11
12
7
4
8
3
1
Signal output during board
carry-in
Signal input to request board
carry-out
NEXT INTERFACE circuit
NEXT INTERFACE
connector
NEXT INTERFACE
AMP 206043-1
(14-pin receptacle)
This machine
Downstream machine
Signal input during automatic
operation
Signal output during automatic
operation
53A05-N9-00
n
Board transfer signal specifications (NEXT INTERFACE)
Pin No. Signal name Address I/O specifications Signal specifications
1 +24V Input common (+24V)
Signal input during board carry-in
2 BUSY IN N0100420 Voltage input
3 BA OUT T01000E5 Relay contact (zero voltage) output
Signal output to request board
carry-out
4 BA OUT T01000E5 Relay contact (zero voltage) output
5 NC
6 NC (with dummy pins) (Prevents misinsertion.)
7 GND
8 NC
9 UR OUT T01000E6 Relay contact (zero voltage) output
Signal output during automatic
operation
10 UR OUT T01000E6 Relay contact (zero voltage) output
11 +24V Input common (+24V)
Signal input during automatic
operation
12 LR IN N0100423 Voltage input
13 +24V Input common (+24V)
Signal input during waiting for
board between machines
14 LE IN N0100424 Voltage input
A-5
Appendix
2. Maintenance parts
2.1 YSM40R main unit maintenance parts list
c
CAUTION
The parts (part Nos.) in this manual were described at the time of manual issue. The part Nos. are subject to change
without notice. Make sure to obtain the latest information on part names and part Nos. when purchasing.
n
NOTE
• The consumable part positions and the replacement procedure are described in this manual.
• See "2.1 Consumable parts" in Chapter 1 for nozzle consumable parts.
n
Consumable parts list
Position Name Part Name Part No. Note Qty
RS head unit
Air filter FILTER
KMB-M7070-00X 1 pc 18
*1
KMB-M3857-01X 1000 pcs per set -
*1
Packing assembly PACKING ASSY KMB-M70SP-00X
RS head vacuum line
replacement part
1
*1
Blow valve for ROD1/2 VALVE KMB-M7055-00X 2
*1
MU head unit
Nozzle leaf spring LEAF SPRING KG7-M7137-A0X 20
*1
Nozzle leaf spring mounting
screw
SCREW,PAN HEAD 90990-08J016 M2 x L2.5 20
*1
Air filter FILTER KLF-M7156-00X 10
*1
FL head unit
Nozzle leaf spring PLATE, SPRING KV7-M8171-00X 4
*1
Nozzle leaf spring mounting
screw
BOLT HEX,
SOCKETHEAD
90115-02J004 4
*1
Nozzle leaf spring mounting
washer
WASHER, PLAIN 90990-28J002 4
*1
Air filter FILTER KLF-M7156-00X 2
*1
Conveyor belt
Conveyor belt
BELT, CONVEYOR 1 KLF-M9110-00X [Lane 1] Length: 1180 mm 4
*2
BELT, CONVEYOR 2 KLF-M9117-00X [Lane 1] Length: 1256 mm 4
*2
BELT, CV1 KLF-M9177-01X
For extension conveyor
Length: 1524 mm
4
*3
Base
Controller filter
MEDIA FILTER KLA-M53A9-00X For system controller 1
FILTER KLA-M53A8-00X For servo controller 1
Ceiling fan filter FILTER,TOP COVER FAN KLF-M130J-00X 2
Conveyor I/O filter FILTER,CP,FAN KLF-M115J-00X 1
Rear base fan filter FILTER,REAR BASE FAN KLF-M131J-00X 1
Filter element (air filter) FILTER ELEMENT KLF-M8502-50X Air filter 1
Element assembly
(Oil mist filter)
MIST FILTER ELEMENT KLF-M8502-70X Oil mist filter 1
