A-14 Appendix 2.2 T ray component supply unit maintenance par ts list n Maintenance par ts list for cA TS Position Name Part Name Part No. Note Qty Stocker/pallet rail section R side resin screw for stocker pallet elevat…
A-13
Appendix
Position Name Part Name Part No. Note Qty
YSM40R-2
X-axis
X-axis duct
(all tables for
YSM40R-2)
X-axis cable duct GUIDE,X AXIS ASSY KKE-M2267-A0X Set of cable ducts 1
*1
Center tape for protecting
cable
TAPE,X DUCT KHY-M220A-00X 1
Outer periphery tape for
protecting cable
TAPE 2,X DUCT KHY-M220B-00X 1
Inner periphery tape for
protecting cable
TAPE 3,X DUCT KHY-M220C-00X 1
Harness mounting
bracket 2
BRACKET 2,TAPE KKE-M2269-00X 1
Tape support plate PLATE,NUT KKE-M226D-00X 1
Harness mounting
bracket 1
BRACKET 1,TAPE KHY-M2268-00X 1
Tape support plate 2 PLATE, NUT KGT-M2266-10X 1
Harness set in X-axis duct YSM40-2 X HNS SET KLF-M66W0-50X 1
X-axis
(For YSM40R-2)
X-axis ball screw BALL SCREW KMB-M2212-10X 1
X-axis support SUPPORT UNIT KHN-M2221-00X 1
X-axis spacer SPACER KHN-M224D-00X 1
X-axis lock nut 1 LOCK NUT KGS-M2628-00X 1
X-axis lock nut 2 LOCK NUT KG2-M9173-00X 1
X-axis spacer 2 SPACER KHN-M2248-00X 2
X-axis bearing BEARING 90933-01J000 2
*1
Required quantity per head unit
*2
Required quantity per machine (Lane 1 & 2)
*3
Required quantity per lane
*4
Required quantity per multi-camera
*5
Required quantity per ANC
*6
Required quantity per PU-axis unit
*7
Required quantity per feeder exchange carriage
*8
Required quantity per blow station
*9
Required quantity per bank
c
CAUTION
The parts (part Nos.) in this manual were described at the time of manual issue. The part Nos. are subject to change
without notice. Make sure to obtain the latest information on part names and part Nos. when purchasing.
A-14
Appendix
2.2 Tray component supply unit maintenance parts list
n
Maintenance parts list for
cATS
Position Name Part Name Part No. Note Qty
Stocker/pallet rail
section
R side resin screw for stocker
pallet elevator section
SCREW,GUIDE R KLS-M14C1-00X
Resin screw for stocker pallet
elevating
2
L side resin screw for stocker
pallet elevator section
SCREW,GUIDE L KLS-M14D1-00X
Resin screw for stocker pallet
elevating
2
Positioning guide for stocker
pallet elevator section
GUIDE,PALLET KLS-M14A3-01X
Positioning resin for stocker
pallet elevating
2
Pallet guide for stocker pallet
elevator section
GUIDE 2 KLS-M1440-00X Resin guide for stocker pallet 2
Guide hook GUIDE,HOOK 2 KLS-M1804-00X Hook pallet resin rail 2
Magazine supply pallet guide GUIDE,CARD KLS-M1909-00X Magazine supply pallet resin rail 2
Tape cutter in cATS
section
12-position tape cutter upper
blade in cATS
CUTTER,UPPER 12 KLS-M3T03-00X
Tape cutter upper blade
(12-position)
1
12-position tape cutter lower
blade in cATS
CUTTER,LOWER 12 KLS-M3T05-00X
Tape cutter lower blade
(12-position)
1
12-position tape cutter
damper in cATS
SHOCK ABSORBER KLF-M3T22-00X Damper 1
Damper mounting block STAY,DAMPER KLF-M3T23-00X Damper stay 1
Stocker section
Pallet positioning cylinder CYLINDER 20 KLS-M1405-00X Pallet positioning cylinder 1
Pallet elevating guide cylinder CYLINDER 15 KLS-M1406-00X Pallet elevating guide cylinder 1
Stocker screw guide drive
pulley 1
PULLEY KLS-M14C4-00X Stocker screw guide drive pulley 2
Stocker screw guide drive
pulley 2
PULLEY 2 KLS-M14B5-00X Stocker screw guide drive pulley 3
Stocker idler pulley PULLEY KLS-M14E2-00X Stocker idler pulley 6
Stocker idler pulley 2 PULLEY 1 KLS-M14B4-00X Stocker idler pulley 1
Stocker drive pulley PULLEY 3 KLS-M1418-00X Stocker drive pulley 1
A-15
Appendix
Position Name Part Name Part No. Note Qty
Hook section
Hook motion valve VALVE 1 KH2-M7101-00X Air valve 1
Hook 1 cylinder
CYLINDER HOOK1
ASSY.
KLS-M653M-00X Hook 1 cylinder 1
Hook 2 cylinder
CYLINDER HOOK2
ASSY.
KLS-M653M-10X Hook 2 cylinder 1
Hook driven pulley 1 PULLEY KLS-M1813-00X Hook driven pulley 1
Hook driven pulley 2 PULLEY KLS-M1822-00X Hook driven pulley 1
Hook idler pulley PULLEY KLS-M1808-00X Hook idler pulley 1
Hook drive pulley DRIVEN PULLEY2 KLS-M1852-00X Hook drive pulley 1
Latch section
Latch motion valve VALVE KLS-M1901-00X Air valve 1
Latch cylinder CYLINDER 2 KLS-M19A9-00X Latch cylinder 2
Drawer stage Shutter cylinder CYLINDER KLS-M19C1-00X Shutter cylinder 1
AZ-axis
AZ-axis pulley PULLEY KLS-M1715-00X BS pulley 1
AZ-axis drive pulley PULLEY 1 KLS-M1716-00X AZ-axis drive pulley 1
Tape cutter in cATS
section
Tape cutter motion valve
CUTTER VALVE
ASSY.
KLF-M3T0V-00X Air valve 1
Tape cutter cylinder
CYL.,TAPE CUTTER
12
KLS-M3T08-00X Cutter cylinder 1
12-position feeder
bank in cATS
12-position feeder guide rail
(rear)
RAIL GUIDE 12P KHY-M371R-00X Guide rail (rear) 1
Guide rail mounting bolt SCREW, FLAT HEAD 98702-03006 Bolt 10
12-position feeder guide rail
(center)
GUIDE,FEEDER
UNDER
KHY-M372R-00X Guide rail (center) 1
12-position feeder guide rail
(front)
GUIDE,FEEDER
UNDER
KLF-M375X-00X Guide rail (front) 1
Guide rail mounting bolt
SCREW, BINDING
HEAD
98902-03006 Bolt 26
This table shows the required quantity per cATS.
c
CAUTION
The parts (part Nos.) in this manual were described at the time of manual issue. The part Nos. are subject to change
without notice. Make sure to obtain the latest information on part names and part Nos. when purchasing.
