2 Operational safety User Manual SIPLACE CF 2.3 Laser classif ication Software Version S R.408.xx 03/2006 US Edition 38 2 W arning la bel (num ber per WPC: 4) 2.3 La ser classification PLEAS E NOTE: 2 Module s in las er …
User Manual SIPLACE CF 2 Operational safety
Software Version SR.408.xx 03/2006 US Edition 2.2 Warning labels
37
2.2.7 Warning labels on the waffle-pack changer
2
Fig. 2.2 - 12 Warning labels on the waffle-pack changer
2
Warning label WPC 80F, item no. 00321262-02 (number per WPC: 1)
WARNING!
Remove IC vision illumination unit before
docking or undocking the machine!
> DANGER OF A CRASH <
Move the waffle-pack changer only over flat
and level floors!
The waffle-pack storage unit must be in its
LOWEST POSITION before transportation!
> DANGER OF OVERTURNING! <
2 Operational safety User Manual SIPLACE CF
2.3 Laser classification Software Version SR.408.xx 03/2006 US Edition
38
2
Warning label (number per WPC: 4)
2.3 Laser classification
PLEASE NOTE: 2
Modules in laser classes 1 and 1M are not identified.
2.3.1 Laser class 1
2
2
2
2
2
DANGEROUS VOLTAGES!
The identified parts are under mains voltage.
Disconnect the machine from the main power supply before
servicing it!
NAFTA region: RISK OF ELECTRIC SHOCK OR BURN!
All installed camera systems and the whole machine when ready for operation
are assigned to laser class 1.
The laser classes are determined according to DIN EN 60825-1:2001.
User Manual SIPLACE CF 2 Operational safety
Software Version SR.408.xx 03/2006 US Edition 2.4 Safety instructions for operating the machine
39
2.4 Safety instructions for operating the machine
2.4.1 Safety instructions for docking and undocking the component trolley
2
Fig. 2.4 - 1 Safety instructions on the component trolley
