1 2 3 4 5 6 000JC061080 BRACKET 1 7 8 KXFW1B4AA00 MANIFOLD 2 9 KXFW1B5AA00 MANIFOLD 4 10 KXFW1B6AA00 MR-UNIT 1 11 KXFW1B7AA00 REGULATOR 1 12 KXF02A2AA00 MANIFOLD KM12-08-03-10 1 13 KXF09VBAA00 JOINT KQZD06-03S 1 14 KXF02…
1
2
3
4
5
6 000JC061080 BRACKET 1
7
8 KXFW1B4AA00 MANIFOLD 2
9 KXFW1B5AA00 MANIFOLD 4
10 KXFW1B6AA00 MR-UNIT 1
11 KXFW1B7AA00 REGULATOR 1
12 KXF02A2AA00 MANIFOLD KM12-08-03-10 1
13 KXF09VBAA00 JOINT KQZD06-03S 1
14 KXF02EEAA00 JOINT KQX06-08 3
15 KXF02CRAA00 PLUG KQP-06 8
16 KXF02CMAA00 JOINT KQL12-03S 1
17
18 KXF07M8AA00 BOTTLE 5-010-03 1
19
20
21
22 KXF09XFAA00 SPACER CF-418 2
23 KXF089MAA00 RING R4×0.5 4
24 000JC061480 BRACKET 1
25
26
27
28
29
30
NO
番号
ＭＯ機番
ユニット名称
本体部:CM202-D
UNIT NAME
PART NUMBER
品番 部品名 型式 数量 ﾗﾝｸ 備考
Main body:CM202-D
PART LIST
MODULE NUMBER
パーツリスト
000JC0M0000
1-C
UNIT NUMBER
ユニットＮｏ.
PART NAME TYPE Q'TY RANK REMARKS
− −12 06 0001−（ ）
