Cable trees Page 71 / 71 22.11.2021 Pos. Item no. Description Part marking 55 03050689-01 CABLE SET TRAILING CABLE 1P 00320872-01 CABLE CLIP D=6.5MM H3P, POLYAMIDE STANDARD PARTS 84 03014437-01 CABLEHOLDER/ C+P SPARE PAR…
Cable trees
Page 69 / 71 22.11.2021
Pos. Item no. Description Part marking
00365726-01 CABLE PCB CONVEYOR SIDE PANEL
D
00368322-02 CABLE: POWER SUPPLY HUB POWER
24V DC
00369722-01 CABLE: CERAMIC SUBSTRATE
CENTERING
00370136-01 TWISTED PAIR CABLE RJ45 KAT. 5E
5M GY
00372329-01 CABLE: DISTRIBUTOR PCB
BARCODE READER
SPARE PART
03002163-01 CABLE: AXIS UNIT X21 *
03002164-01 CABLE: AXIS UNIT X22 *
03003448-01 CABLE: TEST ACCESS SPARE PART
03003549-02 CABLE HF: EXTENSION BALLAST
RESISTOR
Spare
00332896-01 CABLE: CONTROL UNIT -CUTTER
LEFT VALVE
SPARE PART
00334380-01 CABLE: CONTROL UNIT-CUTTER
RIGHT VALVE
SPARE PART
03006597-02 CABLE: HF VISION FLASH SPARE PART
03020656-03 CABLE POWER/DATA EDIF
UNLOCKING BAR
SPARE PART
03022092-01 CABLE X-SERIES / COMPONENTS
CARRIAGE GROUNDING L=400MM
03010623-01 CABLE: COMPUTER - HUB
03010619-01 CABLE: SVGA EXTENSION 1M STANDARD PARTS
03010615-01 CABLE: SVGA EXTENSION, 0.3M SPARE PART
03051895-02 SET OF CABLES 1 FOR BOX-PC X
SERIES
03051749-01 CABLE: MONITOR 1 – VIDEO
MULTIPLEXER
03051750-01 CABLE: MONITOR 2 – VIDEO
MULTIPLEXER
03051751-01 CABLE: KEYBOARD 1 – USB-HUB
03051752-01 CABLE: KEYBOARD 2 – USB-HUB
03051753-01 CABLE: TOUCH SCREEN 1 – USB-
HUB
03051754-01 CABLE: TOUCH SCREEN 2 – USB-
HUB
03051757-02 CABLE: POWER SUPPLY VIDEOMUX-
USB-HUB-SWITCH
Cable trees
Page 70 / 71 22.11.2021
Pos. Item no. Description Part marking
03003439-01 CABLE HF: VISIONCONTROL IC-
CAMERA 2
03003440-01 CABLE: VISION CONTROL FC
CAMERA 2
Spare
03009826-01 CABLE: MODULE/ 1-WIRE CAT5
DISTRIBUTOR
03003449-01 CABLE: VISION CONTROL IC-
CAMERA 1
03003450-01 CABLE: VISION CONTROL FC-
CAMERA 1
03009839-01 CABLE: MODULE/ 1-WIRE CAT5
DISTRIBUTOR
6 03014280-01 GROUND STRAND 2.5QMM 2XKR
M5 L=0.7M
1 03022237S03 TRAILING-CABLE UNIT SIPLACE X-
SERIES 2PU
SPARE PART
23 03021065S03 TRAILING-CABLE UNIT SIPLACE X-
SERIES 2PG
SPARE PART
44 03022236S03 TRAILING-CABLE UNIT SIPLACE X-
SERIES 1P
SPARE PART
00320872-01 CABLE CLIP D=6.5MM H3P,
POLYAMIDE
STANDARD PARTS
84 03014437-01 CABLEHOLDER/ C+P SPARE PART
03041623-02 CABLE SET FOR 1-WIRE X-SERIES
03041626-01 CABLE: 1-WIRE
INTERFACE/DISTRIBUTOR
SPARE PART
03041627-01 CABLE:1-WIRE DISTR.-1-WIRE HUB
CAT5 G1-2
Spare Part
03041628-01 CABLE:1-WIRE DISTR.-1-WIRE HUB
CAT5 G3-4
SPARE PART
03041629-01 CABLE: 1-WIRE-DISTR.-1-WIRE CAT5
GANTRY
SPARE PART
03042347-01 CABLE: 1-WIRE BRIDGE GANTRY
03040917-01 CABLE: 1-WIRE CAT5 GANTRY -
TRAILING UNIT INT.
1 03050817S03 TRAILING-CABLE UNIT SIPLACE X-
SERIES 2PU
SPARE PART
12 03050823-01 CABLE SET TRAILING CABLE 2P U
23 03050934S03 TRAILING-CABLE UNIT SIPLACE X-
SERIES 2PG
SPARE PART
44 03050655S03 TRAILING-CABLE UNIT SIPLACE X-
SERIES 1P
SPARE PART
