MODEL TCM-X200 021 1-001 Key No. P AR T No. P AR T NAME Q’ ty REMARKS NOTE 245 RC-4 35 1 630 1 17 6086 BRA C K ET 1 696RC-1 10-351 35 2 630 1 16 8814 FI L TER ,NO IS E 1 ZN F3 696RC-1 10-352 35 3 630 1 16 3123 UNIT ,DRI …
MODEL TCM-X200
0211-001
244
200V 㔚Ḯㇱ 200V POWER SUPPLY SECTION
Fig. RC-4 200V 㔚Ḯ㧠 200V Power Supply 4
394
396
352
395
399
398
397
351
394
395
396
353
393
392
391
Fig.RC-4
TCM-X200
4797A
4797L
TCM-X300
TCM-X100
MODEL TCM-X200
0211-001
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
245
RC-4
351 630 117 6086 BRACKET 1 696RC-110-351
352 630 116 8814 FILTER,NOISE 1 ZNF3 696RC-110-352
353 630 116 3123 UNIT,DRIVER 1 FVR0.75C11S-2 696RC-110-353
391 630 000 7619 BOLT,HEX-SCT 2 696RC-110-391
392 411 141 2905 WASHER SPR 4 2 696RC-110-392
393 630 001 0213 WASHER 2 696RC-110-393
394 411 113 1400 SCR PAN 4X6 8 696RC-110-394
395 411 008 1706 WASHER SPR 4 8 696RC-110-395
396 411 119 2104 WASHER V 4X9X0.8 8 696RC-110-396
397 630 000 7756 BOLT,HEX-SCT 2 696RC-110-397
398 411 141 6705 WASHER SPR 5 2 696RC-110-398
399 630 001 0220 WASHER 2 696RC-110-399
MODEL TCM-X200
0103-001
246
100V 㔚Ḯㇱ 100V POWER SUPPLY SECTION
Fig. RE-1 100V 㔚Ḯ㧝 100V Power Supply 1
96
94
93
62
92
62
94
93
96
92
61
57
53
54
59
55
59
56
59
51
57
99
98
97
52
58
54
59
60
Fig.RE-1
4797L
TCM-X200
TCM-X300
4797A
