P-215-001e - 第147页
MODEL TIM-X100F/R 0302-002 Key No . P AR T No. P AR T NAME Q’ty REMARKS NOTE 145 V A-3 25 1 630 101 2810 P ANEL 1 750V A-210-251 25 2 630 100 9933 SUPPORT 1 750V A-210-252 25 3 630 095 2841 UNIT ,DRIVER 1 ASMD-L2,#SGDH-0…
MODEL TIM-X100F/R
0302-002
144
本体電装部 前側 ELECTRICAL SECTION-FRONT
Fig. VA-3 前面扉 左側 Front Door-Left
254
253
255
256
288
272
291
290
289
258
273
293
251
259
289
290
291
271
272
289
291
290
266
265
263
275
270
263
261
264
267
268
269
.
.
.
265
271
299
298
297
252
296
295
294
283
273
274
292
273
283
290
291
289
257
274
291
290
289
289
290
291
Fig.VA-3
TIM-X100-002
264
269
.
292
MODEL TIM-X100F/R
0302-002
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
145
VA-3
251 630 101 2810 PANEL 1 750VA-210-251
252 630 100 9933 SUPPORT 1 750VA-210-252
253 630 095 2841 UNIT,DRIVER 1 ASMD-L2,#SGDH-01AE-Y150
750VA-210-253
254 630 095 2841 UNIT,DRIVER 1 ASMD-Z2,#SGDH-01AE-Y150
750VA-210-254
255 630 105 9396 UNIT,DRIVER 1 ASMD-BPC,#SGDH-04AE-Y150
750VA-210-255
256 630 093 8661 UNIT,DRIVER 2 ASMD-CVL,ASMD-CVP,MR-C10A-UE
750VA-210-256
257 630 086 8340 RESISTOR,SPECIAL 1 750VA-210-257
258 630 054 5357 UNIT,POWER 2 G-L2,G-BPC,LPDE-1H01
750VA-210-258
259 630 089 6749 RAIL,WIRING 1 750VA-210-259
261 630 083 5397 CIRCUIT PROTECTOR 1 Q-BPC 750VA-210-261
263 630 116 3758 EM-CONTACTOR 5 KM-CVP,KM-CVL,KM-02A,KM-BPC,
KM-02B 750VA-210-263
264 630 083 5472 TERMINAL 9 750VA-210-264
265 630 083 5519 ACCESSORY,WIRING 2 750VA-210-265
266 630 098 2749 ACCESSORY,WIRING 1 750VA-210-266
267 630 083 5540 ACCESSORY,WIRING 1 750VA-210-267
268 630 083 5564 ACCESSORY,WIRING 1 750VA-210-268
269 630 095 2735 ACCESSORY,WIRING 1 750VA-210-269
270 630 000 1273 ACCESSORY,WIRING 1 750VA-210-270
271 630 000 1051 BRACKET,WIRING 2 750VA-210-271
272 630 050 5122 NAME PLATE,NOTICE 6 750VA-210-272
273 630 048 3833 MECH PARTS(MOUNTING BASES 11 750VA-210-273
274 630 099 6241 ACCESSORY,WIRING 6 750VA-210-274
275 630 105 6609 CIRCUIT PROTECTOR 1 Q-CV 750VA-210-275
288 411 162 1604 SCR PAN 3X20 4 750VA-210-288
289 411 043 5004 SCR PAN 4X8 19 750VA-210-289
290 411 008 1706 WASHER SPR 4 19 750VA-210-290
291 411 119 2104 WASHER V 4X9X0.8 19 750VA-210-291
292 411 140 7208 SCR FLT 4X6 6 750VA-210-292
293 411 051 1708 SCR TRS 4X6 11 750VA-210-293
294 630 000 7756 BOLT,HEX-SCT 4 750VA-210-294
295 411 141 6705 WASHER SPR 5 4 750VA-210-295
296 630 001 0220 WASHER 4 750VA-210-296
297 411 108 8704 NUT HEX 8 4 750VA-210-297
298 411 086 8208 WASHER SPR 8 4 750VA-210-298
299 411 141 4404 WASHER V 8X17X1.6 4 750VA-210-299
MODEL TIM-X100F/R
0302-002
146
本体電装部 前側 ELECTRICAL SECTION-FRONT
Fig. VA-4 前面扉 右側 Front Door-Right
354
353
355
366
392
368
391
391
391
351
367
393
366
390
389
393
367
352
365
362
361
359
358
359
361
365
391
390
389
357
391
368
392
390
389
390
389
389
391
390
389
367
393
356
388
394
397
398
399
395
396
Fig.VA-4
TIM-X100-002
360
363
.
364
360
363
.
390
