23.2.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙ(DGSD) 23.2.Device table(DGSD) 番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質 No. Drg.No. & Code No. QTY Description Rating Remarks Materials 1 DGSD0080 1 CAM ｶﾑ FE 2 DGSD0090 1 CAM ｶﾑ FE 3 DGSD0160 1 VALVE, AIR ﾊ…

100%1 / 237
x12
D
D
A
A
C
C
B
B
LOCTITE262
2.94N.m
ThreeBond1373B
LOCTITE222
LOCTITE222
3.92N.m
3.92N.m
32.34N.m
32.34N.m
32.34N.m
32.34N.m
64.68N.m
LOCTITE222
LOCTITE222
LOCTITE222
32.34N.m
32.34N.m
32.34N.m
32.34N.m
64.68N.m
LOCTITE222
23.2.デバイステーブル(DGSD)
23.2.Device table(DGSD)
23.2.デバイステーブル(DGSD)
23.2.Device table(DGSD)
23 - 6
CP-743E,CP-742E PARTS LIST
23.2.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙ(DGSD)
23.2.Device table(DGSD)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
1 DGSD0080 1 CAM ｶﾑ FE
2 DGSD0090 1 CAM ｶﾑ FE
3 DGSD0160 1 VALVE, AIR ﾊﾞﾙﾌﾞ ｴｱｰ OT
4 DGSD0170 1 VALVE, AIR ﾊﾞﾙﾌﾞ ｴｱｰ OT
5 DGSD0220 4 HOUSING ﾊｳｼﾞﾝｸﾞ FE
6 DGSD0230 2 HOUSING ﾊｳｼﾞﾝｸﾞ FE
7 DGSD0260 4 LEVER ﾚﾊﾞｰ FE
8 DGSD0440 6 HOUSING ﾊｳｼﾞﾝｸﾞ FE
9 DGSD0540 2 KEY ｷｰ FE
10 DGSD0550 8 PIN ﾋﾟﾝ FE
11 DGSD0560 12 COLLAR ｶﾗｰ PL
12 DGSD0570 4 COLLAR ｶﾗｰ FE
13 DGSD0580 8 COLLAR ｶﾗｰ FE
14 DGSD0630 2 SHAFT ｼｬﾌﾄ FE
15 DGSD0830 2 RETAINER, WIRING 押え 配線 FE
16 DGSD0842 1 RETAINER, WIRING 押え 配線 FE
17 H4395Z 12 BEARING, NEEDLE ﾍﾞｱﾘﾝｸﾞ ﾆｰﾄﾞﾙ TA2420Z FE
18 K5348K 4 CONTROLLER, SPEED ｺﾝﾄﾛｰﾗ ｽﾋﾟｰﾄﾞ AS3001F-08(ｼﾛ) OT
19 A4066R 4 ELBOW ｴﾙﾎﾞ KQ2L08-99 OT
20 Y30812 4 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2W08-99 OT
21 DGSD5030 1 CAM ｶﾑ FE
22 DGSD5040 1 CAM ｶﾑ FE
23 DGSD5050 1 CAM ｶﾑ FE
24 DGSD5060 1 CAM ｶﾑ FE
25 DGSD5160 2 ARM ｱｰﾑ FE
26 DGSD5170 2 ARM ｱｰﾑ FE
27 DGSD5182 2 BKT, CYLINDER BKT ｼﾘﾝﾀﾞ FE
28 DGSD5190 2 CYLINDER, AIR ｼﾘﾝﾀﾞ ｴｱｰ OT
29 DGSD5360 1 SHAFT ｼｬﾌﾄ FE
30 DGSD5370 1 SHAFT ｼｬﾌﾄ FE
31 DGSD5380 2 JOINT, KNUCKLE ｼﾞｮｲﾝﾄ ﾅｯｸﾙ FE
32 DGSD5390 2 PIN ﾋﾟﾝ FE
33 DGSD5400 2 KEY ｷｰ FE
34 Y3081B 4 UNION, ELBOW ﾕﾆｵﾝ ｴﾙﾎﾞ KQ2L10-04S OT
35 Y3069M 4 UNION ﾕﾆｵﾝ KQ2R08-10 OT
36 S1038H 4 CIR-CLIP ｻｰｸﾘｯﾌﾟ STW-22 FE
37 S1059T 4
SILENCER
ｻｲﾚﾝｻ AN203-02 OT
38 2 ELBOW ｴﾙﾎﾞ KQ2W08-02S OT
39 H3130A 6
PLUG
ﾌﾟﾗｸﾞ 1/4. OT
CP-743E,CP-742E PARTS LIST
23 - 7
23.2.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙ(DGSD)
23.2.Device table(DGSD)
23.2.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙ(DGSD)
23.2.Device table(DGSD)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考 材質
No. Drg.No. & Code No. QTY Description Rating Remarks Materials
40 H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M4X8L FE
41 H5296A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M4X40L FE
42 H5343A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M8X30L FE
43 H5346A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M8X45L FE
44 H5363A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴        
M10X40L FE
45 .
BOLT, HEX
ﾎﾞﾙﾄ 六角      M8X15L FE
46 N4046A
SCREW, HEX SOCKET SET
ﾈｼﾞ 六角穴止め       
M6X8L FE
47 W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M FE
48 W1025A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 8M/M FE
49 W1014A
WASHER, CONICAL
ﾜｯｼｬ 皿          M-8-H FE
50 W1015A
WASHER, CONICAL
ﾜｯｼｬ 皿          M-10-H FE
51 N1089A
NUT, HEX
ﾅｯﾄ 六角          M8 P=1.25 FE
52 W1011A
WASHER, CONICAL
ﾜｯｼｬ 皿          M-4-L FE
53 DCWM0330 1 NAMEPLATE, SOL 銘板 SOL Japanese(Rfe.31-7) OT
54 DCWM0530 1 NAMEPLATE, SOL 銘板 SOL English(Rfe.31-9) OT
55 DCWM0730 1 NAMEPLATE, SOL 銘板 SOL French(Rfe.31-11) OT
56 DCWM0340 1 NAMEPLATE, SOL 銘板 SOL Japanese(Rfe.31-7) OT
57 DCWM0540 1 NAMEPLATE, SOL 銘板 SOL English(Rfe.31-9) OT
58 DCWM0740 1 NAMEPLATE, SOL 銘板 SOL French(Rfe.31-11) OT
59 K5208A SCREW, TRUSS 小ﾈｼﾞ ﾄﾗｽ M4X6L FE
CP-743E,CP-742E PARTS LIST
23 - 8
23.2.ﾃﾞﾊﾞｲｽﾃｰﾌﾞﾙ(DGSD)
23.2.Device table(DGSD)
